TYAN TIGERCUB ATX Manuel utilisateur

What’s New?

We have added a glossary to our manuals and have expanded our

installation guide. We think you will find both more thorough, and

thoroughly helpful. Our simple but accurate glossary explanations make

it possible for the most novice of end users to understand the technical

jargon that pops up in these pages. The numerous pictures in the step-

by-step installation guide make it easy for you to put together your

system without help from technical support personnel.

Don’t like an explanation? Want to see terms explained that we left out?

Have any other comments? Visit the TYAN web page and let us know

about it at www.tyan.com/html/contacts.html

Table of Contents

1. Introduction...........................................................................4

Overview........................................................................4

Icons.............................................................................. 5

Hardware Specifications/Features................................... 6

Software Specifications...................................................8

Technical Support...........................................................8

Returning Merchandise for Service................................9

Trademarks..................................................................9

2. Board Installation..............................................................10

Unpacking....................................................................10

Installation....................................................................10

Setting Jumpers.............................................................25

3. Onboard Resource Settings..............................................26

Quick Reference for Jumpers........................................26

Map of Motherboard Jumpers....................................... 27

Soft Power Connector.................................................. 31

Speaker Connector Installation...................................... 31

Hardware Reset Switch Connector Installation...............31

External SMI............................................................... 32

Chassis Intrusion Alarm Connector................................ 32

CMOS RTC.................................................................32

Flash EEPROM........................................................... 33

Hardware CMOS & Password Reset............................33

RAM Installation.......................................................... 33

Cache Memory.............................................................34

Frequently Asked Questions..........................................35

4. BIOS Configuration...........................................................38

Introduction to Setup.....................................................38

Main Setup Menu......................................................... 42

Standard CMOS Setup..................................................44

BIOS Features Setup....................................................48

Chipset Features Setup................................................. 52

Power Management Setup............................................ 57

PnP/PCI Configuration................................................. 61

Integrated Peripherals...................................................64

Password Setting..........................................................67

Flash Writer Utility........................................................67

5. System Resources.............................................................70

POST Messages.......................................................... 70

Glossary.......................................................................74

http://www.tyan.com

Chapter 1

Introduction

chapter 1

Introduction

Overview

The S1694SA/L Tigercub is a quality, high performance mainboard

designed for Intel Celeron and Pentium II microprocessors. This

mainboard utilizes the Intel 440EX AGPset and supports CPU speeds

of 233MHz through 333MHz and a host bus speed of 66MHz.

The Tigercub mainboard, with built-in AGP slot, provides high perfor-

mance capabilities that are ideal for a wide range of demanding appli-

cations such as CAD, CAM, CAE, desktop publishing, 3D animation,

and video production.

This integrated system board achieves high reliability with numerous

features and yet is small enough to be supported in a Micro ATX form

factor. Some of the features included are onboard dual channel PCI

PIO, Bus Master IDE and UltraDMA/33, onboard floppy controller,

and onboard high speed I/O.

Flexibility and expandability have been designed into the Tigercub. With

I/O and drive controller support built onboard, optional sound controller

http://www.tyan.com

INTRO

onboard, the one AGP slot, two PCI and two ISA slots (one shared,

four usable) are free for add-on expansion cards.

Remember to take a look at TYAN Computer’s web site located at

http://www.tyan.com. There you can find information on all of TYAN’s

products along with FAQs, distributors list, drivers, and BIOS setting

explanations.

Icons

In order to help you navigate this manual and set up your system, we

have added several icons to our format.

This icon alerts you to particularly important details regard-

ing the setup or maintenance of your system. This icon

often appears next to information that may keep you from

damaging your board or system. While we will often point out the most

vital paragraphs in a chapter, you should always read every word in the

text. Failing to do so can lead to exasperation and expense.

Wherever possible, we have included step-by-step instruc-

tions for setting up your system, which are indicated by

this icon. However, it is in your best interest to read an

entire section (and perhaps the entire manual) before you begin to

fiddle with your motherboard.

While we have alerted you to potential dangers in several

places in the manual with this icon, these warnings should

not be regarded as the whole of your safety regimen.

Never forget that computers are electrical devices, and are capable of

delivering a shock. Prevent damage to yourself and to your board:

always ensure that your system is turned off and unplugged whenever

you are working with it, and that you are equipped with a static safety

device.

important!

procedure

warning

http://www.tyan.com

Chapter 1

Introduction

HardwareSpecifications/Features

Processor Information sOne SEC slot (Slot One type).

sPentium II 233-333MHz.

sSupports Celeron CPUs.

sOne VRM component installed

onboard.

sOnboard CPU fan header.

Chipset Information sIntel 440EX AGPset.

sIntel PIIX4 controller.

sITE 8679 Super I/O chipset.

Voltage and Power sATX power supply connector.

Information s+12V power source for DC fan

onboard.

s3.3V DRAM support.

sUtilizes GTL+ bus to reduce power

consumption and EMI.

sPower recovery after interrupt.

sWindows 95 soft power down.

Main Memory sUp to 512MB EDO or SDRAM

onboard.

sTwo 168-pin DIMM sockets.

sEDO and SDRAM (with SPD)

support (3.3V).

System Management sWake-on LAN 3-pin header for

remote booting by system

administrator (ATX 2.01 compliant

power supply required).

sOptional National LM81 ASIC to

monitor voltage, temperature, and fan

speed.

sChassis intrusion detection capable

(with LM81).

http://www.tyan.com

INTRO

sIntel LANDesk Client Manager

software and/or Intel LANDesk

Server Manager software (with LM81

installed).

Expansion Slots sOne 32-bit AGP slot (supports 1X

and 2X).

sTwo 32-bit PCI bus master slots.

sTwo 16-bit ISA slots.

sOne shared PCI/ISA slot, four

usable.

Physical Dimensions sSmaller than MicroATX design.

s9.6 inches x 7.1 inches.

sDouble row ATX connectors.

BIOS Information sAward Plug and Play flash BIOS.

sDeep Green, Energy Star, PC98,

Year 2000 compliant.

sMultipleboot options.

Disk Drive & System I/O sTwo PCI bus mastering EIDE

channels.

sSupports EIDE CD-ROMs.

sPIO Mode 3 & 4 (up to 17MB/sec

DTR).

sUltraDMA/33 bus mastering mode

(up to 33MB/sec DTR).

sSupport for two floppy drives

(2.88MB & 3 Mode support).

sTwo serial ports (16550 UARTs).

sOne ECP/EPP parallel port.

sOne IR (InfraRed) I/O interface port.

sTwo USB rev 1.2 ports.

sOne PS/2 mouse port.

sOne PS/2 keyboard port.

http://www.tyan.com

Chapter 1

Introduction

Creative Sound sOPTi 82C933 chip.

(optional) sSound Blaster Pro, Ad Lib, Windows

95compatible.

sMicrosoft PC97 compliant.

sPnP 3D stereo sound with 64-bit

software wavetable.

Warranty s3 year manufacturer’s warranty.

SoftwareSpecifications

OS sOperates with MS-DOS, Windows

3.x, Windows for WorkGroups 3.x,

Windows 95, Windows 98, Windows

NT, OS/2, Novell Netware, Solaris,

and SCO Unix.

Information presented in this publication has been carefully checked for

reliability. However, no responsibility is assumed for inaccuracies. The

information contained in this document is subject to change without

notice.

Technical Support

If a problem arises with your system, you should turn to your dealer for

help first. Your system has most likely been configured by them, and

they should have the best idea of what hardware and software your

system contains. Hence, they should be of the most assistance. Further,

if you purchased your system from a dealer near to you, you can

actually bring your system in to them to have it serviced, instead of

attempting to do so yourself (which can have expensive conse-

quences). If your dealer is unable to assist you,

try our web page, http:// www.tyan.com

user newsgroup, alt.comp.periphs.mainboard.tyan

technical support phone line, (510) 440-8808

or e-mail address [email protected]

http://www.tyan.com

ReturningMerchandiseforService

During the warranty period, contact your distributor or system vendor

FIRST for any product problems. This warranty only covers normal

customer use and does not cover damages incurred during shipping or

failure due to the alteration, misuse, abuse, or improper maintenance of

products.

For Resellers Only:

A receipt or copy of your invoice marked with the date of purchase is

required before any warranty service can be rendered. You can obtain

service by calling the manufacturer for a Return Merchandise Authori-

zation (RMA) number. The RMA number should be prominently

displayed on the outside of the shipping carton and the package should

be mailed prepaid, or hand-carried to the manufacturer. TYAN will pay

to have the board shipped back to you.

Trademarks

EliteBIOS is a trademark of Award Software Incorporated.

Windows is a trademark of Microsoft Corporation.

IBM, PC, AT, PS/2 are trademarks of IBM Corporation.

INTEL, Pentium II, Celeron are trademarks of Intel Corporation.

S1694SA/L Tigercub is a trademark of TYAN Computer Corporation.

All other trademarks are the property of their respective companies.

Disclaimer

Information presented in this publication has been carefully checked for

reliability. However, no responsibility is assumed for inaccuracies. The

information contained in this document is subject to change without

notice.

INTRO

http://www.tyan.com

Chapter 2

Board Installation

chapter 2

Board Installation

Unpacking

The mainboard package should contain the following:

·S1694SA/L Tigercub mainboard

·One 40-pin IDE cable

·One 34-pin floppy cable

·User’s manual

·One CPU retention module

·Creative/Ectiva sound CD (optional, includes installation guide).

·One LANDesk CD (optional)

Installation

You are now ready to install your mainboard. The mounting hole

pattern of the S1694SA/L matches the Micro ATX system board

specifications. The S1694SA/L will fit in a Micro ATX or a standard

ATX chassis.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TYAN Carte mère

TYAN

TYAN Tsunami S1846S Manuel utilisateur

TYAN

TYAN THUNDER K7 Manuel utilisateur

TYAN

TYAN THUNDER N3600B Manuel utilisateur

TYAN

TYAN S5372-LH Manuel utilisateur

TYAN

TYAN THUNDER I7520, D, R, RD Manuel utilisateur

TYAN

TYAN TRINITY I875P Manuel utilisateur

TYAN

TYAN Tiger i7501 Manuel utilisateur

TYAN

TYAN M4881 Manuel utilisateur

TYAN

TYAN Tiger MP S2460 Manuel utilisateur

TYAN

TYAN TOMCAT I II Manuel utilisateur

TYAN

TYAN THUNDER LE Manuel utilisateur

TYAN

TYAN S5565 Manuel utilisateur

TYAN

TYAN Thunder 100 S1836 Manuel utilisateur

TYAN

TYAN S8253 Manuel utilisateur

TYAN

TYAN TOMCAT I7221A Manuel utilisateur

TYAN

TYAN Thunder n3600QX Manuel utilisateur

TYAN

TYAN THUNDER N6650W Manuel utilisateur

TYAN

TYAN TOMCAT I875P Manuel utilisateur

TYAN

TYAN TOMCAT I875PF Manuel utilisateur

TYAN

TYAN TOMCAT N3400B Manuel utilisateur

TYAN

TYAN S5547 Manuel utilisateur

TYAN

TYAN THUNDER K8HR Manuel utilisateur

TYAN

TYAN TEMPEST I5000PT Manuel utilisateur

TYAN

TYAN TRINITY I845E Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
