TYAN S1832DL Manuel utilisateur
Tyan
S1832DL
Tiger 100
Motherboard User’s Manual
Revision 2.20
Copyright © Tyan Computer Corporation, 1999. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective companies including, but not limited to the
following.
AMI BIOS is a trademark of American Megatrend Incorporated.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium II, Pentium III, Celeron, Xeon are trademarks of Intel Corporation.
S1832 Tiger 100 is a trademark of TYAN Computer Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.
PRINTED IN USA.
Table of Contents
1. Introduction.......................................................................4
Overview..................................................................... 4
Icons........................................................................... 5
Hardware Specifications/Features................................. 6
Software Specifications.................................................7
Technical Support......................................................... 8
Returning Merchandise for Service................................ 8
2. Board Installation..............................................................10
Unpacking....................................................................10
Precautions.................................................................. 10
Installation Steps...........................................................11
What is a Jumper.......................................................... 12
Map of Motherboard Jumpers....................................... 13
Picture of Motherboard Features................................... 14
Setting Jumpers............................................................ 15
Mounting the Motherboard in the Chassis....................... 19
Installing Memory......................................................... 19
Installing the CPU & Cooling Fan.................................. 23
Connecting IDE & Floppy Drives.................................. 30
Connecting the Power Supply........................................ 32
Installing Add-on Cards................................................ 33
Connecting PS/2, Serial, Parallel & USB Devices.......... 34
Frequently Asked Questions.......................................... 35
3. BIOS Configuration...........................................................38
Main Setup...................................................................39
Advanced CMOS Setup................................................44
Chipset Setup............................................................... 49
Power Management Setup............................................ 55
Plug and Play Setup..................................................... 59
Peripheral Setup........................................................... 64
Supervisor and User Security.........................................68
Language Utility........................................................... 69
Flash Writer Utility........................................................ 69
4. System Resources.............................................................70
Beep Codes................................................................. 70
Troubleshooting System Problems.................................. 71
Displayed Error Messages............................................ 72
Appendix 1 - CPU Retention Module Options.....................74
Appendix 2 - Glossary........................................................... 76
http://www.tyan.com
4
Chapter 1
Introduction
Overview
The S1832DL Tiger 100 is a quality, high performance mainboard designed for
dual Intel Pentium II or Pentium III microprocessors. This mainboard utilizes
the Intel 440BX AGPset and can support CPU speeds of 233MHz through
500MHz, and host bus speeds of 66MHz to 100MHz.
TheS1832DLmainboard,withbuilt-inAGPslot,provideshighperformance
capabilities that are ideal for a wide range of demanding applications such as
CAD, CAM, CAE, desktop publishing, 3D animation, and video production.
This integrated system board achieves high reliability with numerous features
and yet is small enough to be supported in an ATX form factor. Some of the
features included are onboard dual channel PCI PIO, Bus Master IDE and
UltraDMA/33, onboard floppy controller, and onboard high speed I/O.
Flexibility and expandability have been designed into the Tiger 100. With I/O
and drive controller support built onboard, the one AGP slot, five PCI and two
ISA slots (one shared, seven usable slots) are free for numerous add-on
expansion cards.
Remember to take a look at TYAN Computer’s web site located at
chapter 1
Introduction
http://www.tyan.com
5
INTRO
http://www.tyan.com. There you can find information on all of TYAN’s
products along with detailed FAQs for trouble-shooting, distributors list,
drivers, and BIOS setting explanations.
Icons
In order to help you navigate this manual and set up your system, we have
added several icons to our format.
This icon alerts you to particularly important details regarding
the setup or maintenance of your system. This icon often
appears next to information that may keep you from damaging
your board or system. While we will often point out the most
vital paragraphs in a chapter, you should always read every word in the text.
Failing to do so can lead to exasperation and expense.
Wherever possible, we have included step-by-step instructions
for setting up your system, which are indicated by this icon.
However, it is in your best interest to read an entire section (and
perhaps the entire manual) before you begin to fiddle with your
motherboard.
While we have alerted you to potential dangers in several places
in the manual with this icon, these warnings should not be
regarded as the whole of your safety regimen. Never forget that
computers are electrical devices, and are capable of delivering a
shock. Prevent damage to yourself and to your board: always ensure that your
system is turned off and unplugged whenever you are working with it, and that
you are equipped with a static safety device.
!
important!
procedure
1.
2.
3.
warning
http://www.tyan.com
6
Chapter 1
Introduction
Hardware Specifications/Features
Processor Information •Two SEC slots (Slot One type).
•66to100MHzBIOSselectablebus
support.
•PentiumII,P-III233-600MHz.
•Supports Celeron CPU (single only).
Chipset Information •Intel440BXAGPset.
•IntelPIIX4e controller.
•National 309 Super I/O chipset.
Voltage and Power •ATX power supply connector.
Information •+12VpowersourceforDCfans
onboard.
•3.3VDRAM support.
•Utilizes GTL+ bus to reduce power
consumption and EMI.
Main Memory •Up to 1024MB onboard.
•Four 168-pin DIMM sockets.
•Supports100MHz SDRAM with
SPD.
System Management •NationalLM79 and LM75
ASICs with onboard alarm for
monitoring temperature, supply
voltages, and fan speed.
•System Manager software
•Chassis intrusion detection capable.
Expansion Slots •One32-bit AGPslot.
•Five 32-bit PCI Bus Master slots.
•Two16-bit ISA slots.
•One shared, seven usable slots.
http://www.tyan.com
7
INTRO
Physical Dimensions •ATX design.
•12inchesx9.8inches.
•Requires Intel Venus compatible I/O
shield.
BIOS Information •AMI Plug and Play flash BIOS.
•DeepGreen, EnergyStar, ACPI,
Year 2000,and PC98compliant.
•Soft power-down, multiple boot
options.
•Win98/NT5ready, DMI 2.0
compliant.
•PCI2.1,APM 1.1compliant.
Disk Drive & System I/O •Two PCIbus mastering EIDE
channels.
•SupportsEIDE CD-ROMs.
•PIO Mode 3 & 4 (up to 17MB/sec
DTR).
•UltraDMA/33 bus mastering mode
(up to 33MB/sec DTR).
•Support for two floppy drives (up to
2.88MB).
•Two serialports (16550 UARTs).
•OneECP/EPP parallelport.
•OneSerial IR (InfraRed) I/O interface port.
•Two USBrev 1.2 (universal serial
bus) connectors.
•One PS/2 mouse connector.
•One PS/2 keyboard connector.
Software Specifications
OS •Operates with MS-DOS, Windows
3.x,Windowsfor WorkGroups 3.x,
Windows 95, Windows 98, Windows
NT,OS/2, NovellNetware, andSCO Unix.
http://www.tyan.com
8
Chapter 1
Introduction
Technical Support
If a problem arises with your system, you should turn to your dealer for help
first. Your system has most likely been configured by them, and they should
have the best idea of what hardware and software your system contains.
Hence, they should be of the most assistance. Further, if you purchased your
system from a dealer near to you, you can actually bring your system in to
them to have it serviced, instead of attempting to do so yourself (which can
have expensive consequences).
If your dealer is unable to assist you,
1) try our web page: http://www.tyan.com
2) technical support phone line: (510) 440-8808
3)ore-mailaddress: [email protected]
Returning Merchandise for Service
During the warranty period, contact your distributor or system vendor FIRST
for any product problems. This warranty only covers normal customer use and
does not cover damages incurred during shipping or failure due to the
alteration, misuse, abuse, or improper maintenance of products.
For Resellers Only:
A receipt or copy of your invoice marked with the date of purchase is required
before any warranty service can be rendered. You can obtain service by calling
the manufacturer for a Return Merchandise Authorization (RMA) number. The
RMA number should be prominently displayed on the outside of the shipping
carton and the package should be mailed prepaid, or hand-carried to the
manufacturer. TYAN will pay to have the board shipped back to you.
http://www.tyan.com
9
INTRO
This page intentionally left blank.
http://www.tyan.com
10
Chapter 2
Board Installation
chapter 2
Board Installation
!
important!
Unpacking
The mainboard package should contain the following:
·S1832DLmainboard
·One40-pinIDE&34-pinfloppycablepack
·User’s manual
·Two CPU retention modules
·One Tyan System Management & Driver CD
Precautions
What’sthe firstthingIshoulddo?
The first thing you should do is read this user’s manual. It contains important
information which will make configuration and setup much easier.
Here are some precautions you should follow when installing your
motherboard:
(1) Groundyourselfproperlybeforeremovingyourmotherboard
fromthe antistatic bag. Unplug the power from your computer
and then touch any metal part on the computer case. (Or wear a
grounded wrist strap.)
(2) Holdthemotherboardbyitsedgesanddonottouchthebottomof
Autres manuels pour S1832DL
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels TYAN Carte mère
TYAN
TYAN Tiger K8W S2875 Manuel utilisateur
TYAN
TYAN S8253 Manuel utilisateur
TYAN
TYAN S1832DL Manuel utilisateur
TYAN
TYAN S5510 Manuel utilisateur
TYAN
TYAN Tomcat i845GV S2198 Manuel utilisateur
TYAN
TYAN TOMCAT I7210 Manuel utilisateur
TYAN
TYAN TITAN TURBO AT-2 Manuel utilisateur
TYAN
TYAN TRINITY GC-SL Manuel utilisateur
TYAN
TYAN TOMCAT H1000S Manuel utilisateur
TYAN
TYAN S7012 Manuel utilisateur
TYAN
TYAN TIGER GC-SL Manuel utilisateur
TYAN
TYAN Tiger i7525 Manuel utilisateur
TYAN
TYAN THUNDER K7 Instructions d'installation et d'utilisation
TYAN
TYAN S8020 Manuel utilisateur
TYAN
TYAN TRINITY 371 Manuel utilisateur
TYAN
TYAN Tomcat i875P S5102 Manuel utilisateur
TYAN
TYAN TOMCAT I815T Manuel utilisateur
TYAN
TYAN THUNDERBOLT Manuel utilisateur
TYAN
TYAN S7103 Manuel utilisateur
TYAN
TYAN S8032 Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
