3.1 Special Instruction for Use
■The equipment shall only be used in an area of not more than pollution degree 2, as defined
in IEC/EN 60664-1.
■The equipment shall be installed in an enclosure that provides a degree of protection not less
than IP 54 in accordance with IEC/EN 60079-7.
■Transient protection shall be provided that is set at a level not exceeding 140 % of the peak
rated voltage value at the supply terminals to the equipment.
■Care shall be taken not to allow layers of dust to form on the graphic panel in a way that
might cause the accumulation of static charges.
4 Technical features
4.1 Technical Data
TX104 TX107 TX110
Touchscreen technology Resistive
Display/backlight TFT Color /
LED
Colors 64 K
Brightness 200 Cd/m² typ.
Resolution 480 × 272 800 × 480 1024 × 600
Diagonal (inches) 4,3”widescreen (16:9) 7’’ widescreen (16:9) 10.1’’ widescreen (16:9)
Dimming Yes
CPU ARM Cortex - A8 – 300 MHz ARM Cortex - A8 – 1 GHz
Operating system Linux 3.12
Flash 2 GB 4 GB 4 GB
SD card slot No
RAM 256 MB DDR 512 MB DDR 512 MB DDR
Serial port 1× DB 9 (sofware configurable as RS232, RS485 or RS422)
Ethernet port 1 × 10/100 Mbit
USB Host port 1 × USB 2.0, max. 500 mA
Power supply DC Power Connector - AWG24 wire size - R/C Terminal Blocks (XCFR2), Female pitch 5.08
mm, torque 4.5 lb-in. 3 conductor 1,5 mm² wire size minimum, DC
Real time clock Yes
RTC backup Supercapacitor
Recipe memory Flash
Operating voltage 24 VDC (10…32 VDC)
Current consumption (at 24 VDC) 0.25 A 0.30 A 0.38 A
Weight 0.4 kg 0.6 kg 1 kg
Input protection Automatic
Accuracy RTC (at 25 °C) < 100 ppm
NOTE
For applications requiring compliance with EN 61131-2 and specifically in reference to 10 ms
voltage dips, the minimum power supply voltage is 18 VDC.
