Turbolock TL111PRO Manuel utilisateur
In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for
the latest user manuals and product materials. Version 1.0 2/26/19
www.turbolock.com
Customer Service: 855-850-8031
Section 1
Information & Safety Warnings 4
1.1 Introduction 4
1.2 Safety Warnings 4
1.3 End-of-Life Disposal 5
Section 2
Package Contents & Overview 6
2.1 Contents 6
2.2 Overview 6
2.3 Battery Information 7
2.4 Usage Overview 7
Section 3
Installation (Retrot) 8
3.1 Pre-Installation 8
3.2 Main Installation 10
Section 4
Installation (New) 12
4.1 Pre-Installation 12
4.2 Main Installation 16
Section 5
Using the Lock 18
Section 6
Keypad Passwords 18
6.1 Changing the Admin Password 18
6.2 Adding Keypad Passcodes 19
6.3 Delete a Single Passcode 19
6.4 Delete All Passcodes 20
6.5 Passcode Disguise 20
Section 7
Using the Passive Function 20
Section 8
Using the Mute Function 21
8.1 Activating Mute Mode 21
8.2 Deactivating Mute Mode 21
Section 9
The TurboLock Plus App 22
9.1 App Installation 22
9.2 Pairing 22
9.3 App Usage 23
9.4 Generating Keypad Passcodes 24
9.5 Managing User Passwords (E-Keys)
24
Section 10
Resetting the Lock 25
Section 11
Specications 26
Section 12
Maintenance 27
Section 13
Troubleshooting 27
Section 14
Warranty 29
14.1 Violation 29
14.2 Information 30
Table of Contents
4 TurboLock TL111 PRO
Section 1
Information & Safety Warnings
1.1 Introduction
This user manual will guide you through the functions and usage of your TurboLock TL111 PRO Bluetooth-enabled Smartlock. It is
important that you follow all instructions and regard all notes that appear throughout this manual. Consult this manual before you
attempt to use your lock. If you have questions not answered by this manual or are in need of repair or non-routine service, contact
customer service at 1-855-850-8031. Before contacting customer service, please have your purchase information ready as this may
be needed during the call. Please record this information below:
Date of Purchase:
Place of Purchase:
1.2 Safety Warnings
When reading this manual, note these icons:
Notes with this icon MUST be read, understood, and obeyed to prevent injury or damage.
Notes with this icon include relevant information.
General Precautions
• The lock shall only be used as described in this manual.
• Verify that all parts of the lock are accounted for. If any part is missing, contact customer service.
• If the battery compartment or surrounding parts are damaged, do not use the lock.
• Use only four AAA batteries. Do not mix old and new batteries or batteries from dierent brands.
• Never insert objects into the lock other than batteries as described in this manual.
• The lock is not a toy. Do not leave children unsupervised around the lock.
TurboLock TL111 PRO 5
• Use only the parts included in the original packaging or received from TurboLock.
• Verify all surfaces are at and level before beginning installation. Installation on doors or surfaces with any type of
deformity such as gaps or warping may cause the lock to malfunction or fail to operate entirely.
• Expected use is for standard doors made for buildings within the US.
• New batteries on average can deliver up to one full year of use before replacement is needed. Battery life varies by
usage.
• Replace the batteries after receiving the lock’s low battery notication.
• Never apply any cleaner directly to any part of the lock. Only use clean (or puried) water and mild cleaner on a soft,
non-abrasive cloth when cleaning.
• Potential Shock Warning: Do not allow water and/or liquids to get into the lock’s electric parts.
• Never submerge the lock or any of the lock’s components.
• Hanging objects on the lock is not recommended.
• The lock may be used with the TurboLock Plus app. The lock will function without the app but full functionality may
only be achieved when the app is used.
1.3 End-of-Life Disposal
This product must not be disposed of by incineration, landlling, or mixing with household trash. Improper disposal of the battery
contained within this product may result in the battery heating up, rupturing, or igniting which may cause serious injury. The
substances contained inside the battery present chemical risks to the environment. The recommended disposal for any TurboLock
TL111 PRO at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility.
Local regulations and laws pertaining to the recycling and disposal of certain types of batteries and/or products containing them
will vary according to country, state, and local governments. Please check laws and regulations corresponding to where you live in
order to properly dispose of the battery and/or unit. It is the user’s responsibility to dispose of their waste equipment properly with
accordance with local regulations and laws.
For additional information about where you should drop o your batteries or electronic waste, please contact your local or regional
waste-management oce, your household waste disposal service, or your point-of-sale.
1: Emergency Power Port
2: Outside Knob
3: Latch Assembly
4: Inside Screws
5: Inside Knob
6: Battery Compartment
7: Back Plate Cover
8: Mounting Screws
9: Back Plate
10: Power Cable
11: LED Indicators
12: Keypad
13: Key Hole
14: Reset Button
Battery Compartment
6 TurboLock TL111 PRO
Section 2
Package Contents & Overview
2.1 Contents
TL111 PRO Bluetooth-enabled Smartlock x 1
Outside Knob x 1
Inside Knob x 1
Latch Assembly x 1
Wood Screws x 6
Mounting Screws x 2
Inside Screws x 3
Keys x 2
Hex Key x 1
- Mounting screws may already be
inside the lock upon opening.
- Requires 4x AAA batteries (not included).
2.2 Overview
2
1
34
5
10
11
12
9
8
76
13
14
TurboLock TL111 PRO 7
2.3 Battery Information
The lock requires four standard or rechargeable ‘AAA’ batteries. New batteries should be installed as soon as possible after
receiving the rst low-battery warning (three sets of triple beeps). After that rst notication, the lock will only have enough power for
approximately 50 uses before the batteries are fully depleted. Low-battery notication will come from the lock itself.
2.4 Usage Overview
The easiest way to use the lock is via proximity. With the app open, tap the lock icon to unlock the door directly. In addition to this
method, the TL111 PRO provides other ways to open your door. Each time the lock engages and unlocks the door, regardless
of entry method, the door can only be opened while the backlight is still on and the lock is beeping. After it stops, the lock will
automatically engage again and lock the door.
Using the Admin Password
Use the keypad to enter the Admin Password, and then press ‘#’ to unlock the door.
For added security, the Admin Password must be changed from the manufacturer’s default after installation and initial testing.
See Section 6.
Using the Emergency Power Port
Supply power via the Emergency Power Port on the bottom of the lock. The backlight will turn on indicating the lock is receiving
power. Enter a password and then press ‘#’ to unlock the door as usual.
Using a User Passcode
Use the keypad to enter the passcode, then press ‘#’ to unlock the door.
User Passwords (eKeys) may have restricted access according to the app admin’s discretion.
Passive Function
After turning this function on, you can open the door directly, no password is needed.
• The TL111 PRO features a Mute Function. See Section 8.
• If a password has been entered wrong 5x in a row, regardless of the entry method, the lock will go into a 5-minute period
of inactivity where it cannot be used, except with the included physical key. This is a security feature designed to prevent
unwanted parties from using the lock.
8TurboLock TL111 PRO
Section 3
Installation (Retrot)
This section details installation steps needed if you are installing the TL111 PRO on a door with a single cutout already
made. Replacing an older xture with a newer one is known as a retrot. If your door has never had a lock or doorknob
installed or otherwise has no cutout, please skip to Section 4.
• For easier installation, have another person help to hold the lock.
• Remove all parts of any old lock before installing the TL111 PRO. In some cases, the old strike plate and/or box may be used.
• For your convenience, installation instructions are broken into segments. Read and follow the instructions for both Pre-
Installation and Main Installation.
• If your door happens to have two cut-outs, check the clearance between the two. Make sure there is enough distance so that
you may seal o any extra opening.
3.1 Pre-Installation
Part 1 - Disassemble the Lock
The TL111 PRO comes already
assembled. Before installation,
release the inside screws and
mounting screws to disassemble
the lock into six main parts: Outside
Knob x 1, Inside Knob x 1, Latch
Assembly x 1, Battery Compartment
x 1, Back Plate Cover x 1, and Back
Plate x 1.
You only need to loosen the inside
screws. Do not fully detach them.
Outside Knob
Latch Assembly
Inside Knob
Inside Screws x 3
Mounting Screws x 2
Back Plate Back Plate Cover
Battery Compartment
TurboLock TL111 PRO 9
Part 2 - Installing the Latch
KEEP DOOR OPEN AT ALL TIMES SHORTLY BEFORE, DURING AND SHORTLY AFTER INSTALLATION. If the lock is
incomplete or improperly installed, the lock and/or door may become stuck.
After nishing installation, be sure to use the door at least once to make sure all parts of the lock function correctly.
Step 1. Insert the latch into the hole and check it. The latch’s plate should sit ush against the edge of the door. (Fig. 1) If there’s
too much space behind the latch or if it’s sticking out from the door, the latch should be adjusted. If the latch needs
adjusting, continue on to Step 2; otherwise, go to Step 3.
Step 2. Hold the front of the latch and the square opening from both sides, pull or push to extend or retract the latch end as
needed. (Fig. 2) Insert the latch back into the door.
Step 3. Check the latch’s bolt and make sure the rounded side faces in. Add 2x Wood Screws and use a screwdriver (not
included) to secure them. (Fig. 3)
(Fig. 1) (Fig. 2) (Fig. 3)
Part 3 - Installing the Strike
In most cases, the existing strike plate and setup can be used. If you wish to use the one included with your lock, skip to Section
4.1, Part 3.
10 TurboLock TL111 PRO
3.2 Main Installation
Step 1. Start with the Outside Knob. Feed the power cable and tail piece through the square hole in latch. Thread the two pegs
through the smaller, round holes. If needed, have someone hold the door itself or hold the Outside Knob at against
the front of the door afterwards. (Fig. 4)
Do NOT force the cable’s connector end through any part of the lock. Damaging the connector may make the lock
unusable.
It’s highly recommended to leave the door open during installation.
Step 2. Align the back plate on the back of the door to make sure the slot is upward, and feed the power cable through the
center hole of back plate. Use the 2x mounting screws to fasten the back plate to the door. Make sure both screws are
tightened. (Fig. 5)
Step 3. Feed the power cable through the back plate cover, and cover it on the back plate part, then use the hex key to fasten
the inside screw at the bottom of back plate cover. (Fig. 6)
Tail Piece
(Fig. 4)
(Fig. 5)
2 x Mounting Screws
Slot is upward
Back Plate
(Fig. 6)
Inside Screw
Power Cable
Back Plate Cover
