Trojan PACE 370 Manuel utilisateur

USER MANUAL

PACE 370

STATIONARY

CYCLE

6 KG

FLYWHEEL CARDIO

Visit facebook.com/trojanhealth

www.trojanhealth.co.za

www.instagram.com/trojanhealth

CAUTION

READ ALL PRECAUTIONS AND

INSTRUCTIONS IN THIS MANUAL

BEFORE USING THIS EQUIPMENT.

KEEP THIS MANUAL FOR

FUTURE REFERENCE.

INDEX

• Important Safety Instructions ________________________________ 3

• Pre Assembly Check List _____________________________________ 5

• Hardware & Tools List ________________________________________ 6

• Parts List ___________________________________________________ 8

• Exploded Drawing ___________________________________________ 10

• Assembly Steps _____________________________________________ 11

• Console Functions ___________________________________________ 14

• Exercise Instructions ________________________________________ 24

• Fitness Tips & Techniques ____________________________________ 26

• Conditioning Guidelines ______________________________________ 27

• Warm Up & Cool Down _______________________________________ 28

• Maintenance ________________________________________________ 29

• 2 Year Limited Warranty ______________________________________ 30

• Repairs Procedure ___________________________________________ 31

IMPORTANT SAFETY INSTRUCTIONS

It is the sole responsibility of the purchaser of Trojan products to read the owner’s manual, warning labels and

instruct all individuals, on proper usage of the equipment. Understanding each and every warning to the fullest

is important. If any of these instructions or warnings are unclear please contact Trojan Customer Services on

0861 TROJAN (0861 876526), within the Republic of South Africa. Customers residing outside South Africa

can contact us on +27 10 206 4405.

The equipment is only intended for home use and is not intended for commercial, institutional and/or studio

facilities use.

Contact Trojan with any questions regarding this classication. It is recommended that all users of Trojan be

informed of the following information prior to use.

HEALTH WARNING

• Before starting any exercise or conditioning program you should consult with your personal physician to

see if you require a complete physical exam. This is especially important if you are inactive, pregnant or

suffer from any illness.

• If at any time during exercise you feel faint, dizzy or experience pain, stop exercising immediately and

consult your physician.

• To avoid muscular pain and strain, begin each workout by stretching and warming up and end each session

by cooling down and stretching.

INSTALLATION

Trojan recommends that all equipment:

• Be secured to or set up on a solid, level surface to stabilise and eliminate rocking or tipping over

during training.

• Be set up inside your home away from moisture and dust (the equipment is not designed for outdoor use).

• Be set up with sufcient ventilation to ensure proper operation.

• Be set up with sufcient space around the equipment so that all exercises can be completed safely. It is

recommended that there should be at least 1 m of space around the equipment where access is required

to exercise.

PROPER USAGE

• Do not use the equipment in any way other than as designed or intended by the manufacturer. It is

imperative that Trojan equipment is used properly to avoid injury.

• Injuries may result from exercising improperly or excessively.

• Your Trojan equipment should only be used by 1 person at a time.

• Be careful to maintain your balance while using, mounting, dismounting or assembling your Trojan

equipment to avoid injury.

• Do not attempt to adjust the seat or handlebars while you are on your Trojan equipment.

• Servicing other than the procedures in this manual should be performed by an authorised service

representative only.

ACCESS CONTROL

• Trojan recommends that all tness equipment be used in a supervised area. It is recommended that

the equipment be located in an access controlled area. Control is the responsibility of the owner.

Keep children away from all equipment.

• Parents or other supervising adults must provide close supervision of children if the equipment is used

in the presence of children.

INSPECTION

• Do not use or permit use of any equipment that is damaged, or has worn or broken parts. For all Trojan

equipment use only replacement parts supplied by Trojan.

• Always make sure that all nuts and bolts are tightened prior to each use.

• Maintain labels and nameplates – do not remove labels for any reason. They contain

important information.

• Equipment maintenance – preventative maintenance is the key to smooth operating equipment. Please

ensure that you follow our maintenance tips to ensure the continued correct function of your

Trojan equipment.

• Before any use, examine all accessories approved for use with the Trojan equipment for damage or wear.

• Should your Trojan equipment appear damaged or worn, do not attempt to use or repair the

equipment yourself.

• Please contact our service department on 0861 TROJAN (0861 876526) to arrange a repair.

Customers residing outside South Africa can contact us on +27 10 206 4405.

OPERATING WARNINGS

• It is the purchaser’s responsibility to instruct all users as to the proper operating procedures of all

Trojan equipment.

• Keep children away from all moving parts. Parents must provide close supervision of children if the

equipment is used in the presence of children.

• Do not wear loose tting clothing or jewellery when using the equipment. It is also recommended that

users tie up long hair to avoid contact with moving parts.

• Ensure that anyone not using the equipment stays clear of the user, accessories and moving parts while

the machine is in operation.

USER WEIGHT LIMITATIONS

• This Trojan Pace 370 Stationary Cycle may not be used by persons weighing more than 110 kg.

SAVE THIS INSTRUCTION MANUAL FOR FUTURE USE AND REFERENCE.

If any of these instructions or warnings are unclear please contact Trojan Customer Services on

0861 TROJAN (0861 876526) within the Republic of South Africa or visit www.trojanhealth.co.za.

Customers residing outside South Africa can contact us on +27 10 206 4405.

IMPORTANT SAFETY INSTRUCTIONS

Console

Handlebar

Seat

Main Cover

Rear Stabiliser

Hand Pulse

Pedal

Front

Stabiliser

Adjustment

Knob

PRE ASSEMBLY CHECK LIST

Thank you for choosing the Trojan Pace 370 Stationary Cycle. We take great pride in producing this product

and hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to

its fullest. Yes, it’s a proven fact that a regular exercise program can improve your physical and mental health.

Too often, our busy lifestyles limit our time and opportunity to exercise. The Trojan Pace 370 Stationary Cycle

provides a convenient and simple method to begin your assault on getting your body in shape and achieving

a healthier lifestyle. Before reading further, please review the drawing below and familiarise yourself with the

parts that are labelled.

Read this manual carefully before using the Trojan Pace 370 Stationary Cycle.

Tension Control Automatic magnetic resistance (Auto tension)

Function Time / Distance / Speed / RPM / Calories / Body fat / Hand pulse / Pulse recovery /

Heart rate control

Set-up Size 840 mm (L) x 510 mm (W) x 1300 mm (H)

Weight of Flywheel 6 kg

User Weight 110 kg (maximum)

Programs 23 pre-set

HARDWARE & TOOLS LIST

INSTRUCTIONS FOR ASSEMBLY

• Before you start to assemble, please check the hardware packaging to make sure all parts are included.

• Basic tools, such as spanners will be provided for assembly.

#1 Main Frame

#5 Handlebar

#2 Front Stabiliser #3 Rear Stabiliser

#9 Left Pedal #10 Right Pedal#8 Saddle

#6 Console

#7 Seat Post

#4 Front Post

No. Description Drawing QTY

15 Carriage Bolt (M10 x 75 mm) 4

Curved Washer (Ø10 x Ø22 mm)

17 Domed Nut (M10) 4

18 Allen Bolt (M8 x 16 mm) 4

19 Curved Washer (M8 x 20 mm) 6

22 Allen Bolt (M8 x 20 mm) 2

11 Quick Release Knob 1

Allen Key (6 mm) 1

Spanner 1

HARDWARE & TOOLS LIST

6 mm

PARTS LIST

No. Description Qty

1 Main Frame 1

2 Front Stabiliser 1

3 Rear Stabiliser 1

4 Front Post 1

5 Handlebar 1

6 Console 1

7 Seat Post 1

8 Seat 1

9 Left Pedal 1

10 Right Pedal 1

11 Quick Release Knob 1

12 Washer (Ø8 x Ø17 mm) 5

13 Spring Washer (Ø8) 3

14 Nylon Locknut (M8) 5

15 Carriage Bolt (M10 x 75 mm) 4

16 Arc Washer (Ø10 x Ø22 mm) 4

17 Domed Nut (M10) 4

18 Allen Bolt (M8 x 16 mm) 4

19 Arc Washer (Ø8 x Ø20 mm) 6

20 Lower Pulse Wire 2

21 Upper Pulse Wire 2

22 Allen Bolt (M8 x 20 mm) 3

23 End Cap For Front Stabiliser 2

24 End Cap For Rear Stabiliser 2

25 Crank (L, R) 1, 1

26 Hand Pulse Sensor 2

No. Description Qty

27 Screw (M5 x 10 mm) 2

28 Foam Grip 2

29 End Cap For Handlebar 2

30 Self Tapping Screw (ST4 x 20 mm) 2

31 Washer (Ø4.2 x Ø12) 2

32 Grommet 1

33 Middle Console Wire 1

34 Lower Console Wire 1

35 Upper Console Wire 1

36 End Cap for Crank Cover 2

37 Axle for Flywheel 1

38 C-Clip 2

39 Bushing 1

40 Self Tapping Screw (ST5 x 15) 12

41 Magnet Assembly 1

42 Chain Cover (L, R) 1, 1

43 End Cap for Chain Cover 2

44 Powder Bushing 2

45 Self Tapping Screw 4

46 Hex Head Bolt (M8 x 105 mm) 1

47 Hex Head Bolt (M8 x 45 mm) 1

48 Spring For Idler 1

49 Idler Assembly 1

50 Powder Bushing 1

51 Sensor Bracket 1

52 Hex Head Bolt (M6 x 25 mm) 1

PARTS LIST

No. Description Qty

59 Spring For Magnet Assembly 1

60 Motor 1

61 Power Wire 1

62 Sensor Wire 1

63 Motor Wire 1

64 Belt-drive Wheel 1

65 Axle for Belt-drive Wheel 1

No. Description Qty

53 Hex Head Nut (M6) 2

54 French Nut 4

55 Belt 1

56 BB Parts 1 set

57 Hex Head Nut (M8) 1

58 Flywheel 1

EXPLODED DRAWING
