PURSUIT 320
STATIONARY CYCLE
PURSUIT 320
CARE INSTRUCTION AND ASSEMBLY MANUAL
INDEX PAGE
1. SAFETY INSTRUCTIONS 3
2. PRE ASSEMBLY CHECK LIST 5
3. HARDWARE LIST 6
4. ASSEMBLY STEPS 8
5. COMPUTER FUNCTIONS 11
6. FITNESS TIPS & TECHNIQUES 12
7. CONDITIONING GUIDELINES 13
8 . WARM -UP AND COOL-DOWN 14
9. FREQUENTLY ASKED QUESTIONS 15
10. PARTS LIST 16
11. EXPLODED DRAWING 17
12. TROJAN 1 YEAR WARRANTY 18
13. TROJAN REPAIRS PROCEDURE 20
10166-3
1. SAFETY INSTRUCTIONS
It is the sole responsibility of the purchaser of TROJAN products to read the owner’s manual, warning labels and instruct all
individuals, on proper usage of the equipment. Understanding each and every warning to the fullest is important. If any of these
instructions or warnings are unclear please contact Trojan Customer Services on 0861 876 526 (0861 Trojan), within the Republic of
South Africa.
The equipment is only intended for HOME USE and is NOT INTENDED FOR COMMERCIAL, INSTITUTIONAL AND/OR
STUDIO FACILITIES USE.
Contact TROJAN with any questions regarding this classification. It is recommended that all users of TROJAN be informed of the
following information prior to use.
HEALTH WARNING
• Beforestartinganyexerciseorconditioningprogramyoushouldconsultwithyourpersonalphysiciantoseeifyourequirea
completephysicalexam.Thisisespeciallyimportantifyouareovertheageof35orhaveneverexercised,arepregnantorsuffer
from any illness.
• Ifatanytimeduringexerciseyoufeelfaint,dizzyorexperiencepain,stopexercisingimmediatelyandconsultyourphysician.
• Toavoidmuscularpainandstrain,begineachworkoutbystretchingandwarmingupandendeachsessionbycoolingdownand
stretching.
ACCESS CONTROL
TROJAN recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be located in
an access controlled area. Control is the responsibility of the owner. Keep children away from all equipment. Parents or other
supervising adults must provide close supervision of children if the equipment is used in the presence of children.
INSTALLATION
TROJAN recommends that all equipment:
• Besecuredtoorsetuponasolid,levelsurfacetostabilizeandeliminaterockingortippingoverduringtraining.
• Besetupinsideyourhomeawayfrommoistureanddust(theequipmentisnotdesignedforoutdooruse).
• Besetupwithsufcientventilationtoensureproperoperation.
• Besetupwithsufcientspacearoundtheequipmentsothatallexercisescanbecompletedsafely.Itis
recommendedthatthereshouldbeatleast1mofspacearoundtheequipmentwhereaccessisrequiredtoexercise.
Fortreadmillsitisrecommendedthatyouhave2mofspacebehindtherunningdeck.
• Beinstalledbyourteamofinstallers.
PROPER USAGE
• Donotusetheequipmentinanywayotherthanasdesignedorintendedbythemanufacturer.Itisimperativethat
TROJAN equipment is used properly to avoid injury.
• Injuriesmayresultfromexercisingimproperlyorexcessively.
• YourTROJANequipmentshouldonlybeusedbyonepersonatatime.
• Becarefultomaintainyourbalancewhileusing,mounting,dismounting,folding,unfoldingorassemblingyourTROJAN
equipment to avoid injury.
• Donotattempttoadjustanyseats/pads/pulleysetc.whileyouareonyourTROJANequipment.
• Servicingotherthantheproceduresinthismanualshouldbeperformedbyanauthorizedservicerepresentativeonly.
• DANGER:Alwaysunplugthepowercordbeforecleaninganyequipmentpoweredbyelectricity.
10166-4
INSPECTION
• Donotuseorpermituseofanyequipmentthatisdamagedorhaswornorbrokenparts.ForallTROJANequipmentuseonly
replacement parts supplied by TROJAN.
• Alwaysmakesurethatallnutsandboltsaretightenedpriortoeachuse.
• Cablesandbeltsposeanextremeliabilityifusedwhenfrayed.Alwaysreplaceanycableatrstsignofwear.
• Routinelyinspectallaccessoryclipsthatjoinattachmentstothecablesandreplaceattherstsignofwear.
• Maintainlabelsandnameplates–donotremovelabelsforanyreason.Theycontainimportantinformation.
• Equipmentmaintenance–Preventativemaintenanceisthekeytosmoothoperatingequipment.Pleaseensurethatyou
follow our maintenance tips to ensure the continued correct function of your TROJAN equipment.
• Beforeanyuse,examineallaccessoriesapprovedforusewiththeTROJANequipmentfordamageorwear.
• ShouldyourTrojanequipmentappeardamagedorworndonotattempttouseorrepairtheequipmentyourself.
Please contact our service department on 0861 876 526 (0861 Trojan) to arrange a repair.
OPERATING WARNINGS
• Itisthepurchaser’sresponsibilitytoinstructallusersastotheproperoperatingproceduresofallTROJANequipment.
• Keepchildrenawayfromallmovingpartsandawayfromallstrengthequipment.Parentsmustprovideclosesupervisionof
children if the equipment is used in the presence of children.
• Donotwearloosettingclothingorjewellerywhenusingtheequipment.Properfootwareshouldbewornatalltimes.
It is also recommended that users tie up long hair to avoid contact with moving parts.
• Ensurethatanyonenotusingtheequipmentstaysclearoftheuser,accessoriesandmovingpartswhilethemachineisin
operation.
USER WEIGHT LIMITATIONS
• ThisTROJAN PURSUIT 320maynotbeusedbypersonsweighingmorethan110kg.
ELECTRICAL SAFETY
• Keepthepowercordawayfromheatedsurfaces.
• Neverusetheequipmentifthepowercableorplugisfrayedordamaged.
• Neverusetheequipmentifthecord,equipmentorsurroundingoorareaiswetordamp.
• Allelectricalproductsmustbegrounded.Thisproductissupplierwiththenecessarygroundingconnections.
Do not modify the plug provided with the product. If the plug will not fit into the power outlet, have a proper outlet installed by
a qualified electrician.
SAVE THIS INSTRUCTION MANUAL FOR FUTURE USE AND REFERENCE
If any of these instructions or warnings are unclear please contact Trojan Customer Services on 0861 876 526 (0861 Trojan), within
the Republic of South Africa or visit www.trojanhealth.co.za.
SAFETY INSTRUCTIONS
10166-5
2. PRE ASSEMBLY CHECK LIST
ThankyouforchoosingtheTROJAN PURSUIT 320.Wetakegreatprideinproducingthisqualityproductandhopeit
willprovidemanyhoursofqualityexercisetomakeyoufeelbetter,lookbetterandenjoylifetoitsfullest.
Yes,itisaprovenfactthataregularexerciseprogramcanimproveyourphysicalandmentalhealth.Toooften,ourbusy
lifestyleslimitourtimeandopportunitytoexercise.TheTROJAN PURSUIT 320 provides a convenient and simple
method to begin your assault on getting your body in shape and achieving a healthier lifestyle.
Before reading further, please familiarise yourself with the parts that are labelled.
Read this manual carefully before using the TROJAN PURSUIT 320 .
HAND PULSE SENSOR
TENSION CONTROL
SEAT
PEDAL
WHEEL
REAR STABILIZER
FRONT STABILIZER
ADJUSTING KNOB
COMPUTER
HANDLES
10166-6
3. HARDWARE LIST
1. Thesepartsareallthepartsyouneedtoassemblethismachine.Beforeyoustarttoassemble,pleasecheckthehardware
packingtomakesuretheyareincluded.
10166-7
PART DESCRIPTION Q’TY
62 Main Frame 1
22/23/20 FrontStabilizerwith2TransportationWheelCaps 1set
2/5/3/1 Handlebar with 2 Hand Pulses, 2 Foam Grips, 2 Plugs 1set
15/9/11 Front Post with Middle Section Sensor Wire,Tension Knob with Cable 1set
18 Front Post Decoration Cover 1
32 Seat Post 1
7 Monitor with Sensor Wire 1
29/30/31 Seat with 3 Washers, 3 Nuts 1set
65/23/64 RearStabilizerwith2LevelingCaps 1set
54 Bellows 1
Instruction Manual 1
HARDWARE LIST
PART DESCRIPTION Q’TY SKETCH
63 Cap Nut M8 4
27 Spring Washer 4
28 Curved Washer 4
21 Carriage Bolt M8*75mm 4
36R Pedal (R) 1
36L Pedal (L) 1
13R/13L Pedal strap (R/L) 2pcs
14 Wing Nut 1
12 Sleeve 13*8*12.5mm 1
71 Allen Wrench 1
70 Universal Wrench 1
34 Seat Knob 1
69 Clamp Decoration Cover 1
10166-8
4. ASSEMBLY STEPS
Instructions for assembly
• Unpackthecartonandusingthepartslistcheckthatallpartsareaccountedfor.
• Donotdisposeofthepackagingmaterialuntilassemblyiscompleted.
• AnAllenWrenchisprovidedforuseinassembly.
STEP 1
• AttachtheRearStabilizer(65),whichincludes2
LevelingCaps(64),totherearcurvebracketofMain
Frame (62), using 2 Carriage Bolts (21), 2 Curved
Washers (28), 2 Spring Washers (27) and 2 Cap
Nuts (63).
• AttachtheFrontStabilizer(22),whichincludes2
Transportation Wheel Caps (20), to front curve
bracketofMainFrame(62),using2CarriageBolts
(21), 2 Curve Washers (28), 2 Spring Washers (27)
and 2 Cap Nuts (63).
Note:YoucanusetheEndCaps64tolevelthebike.
STEP 2
• Removethe3pre-assembledM8NylonLocknuts
(31) and 3 pre-assembled M8 Flat Washers (30)
from the Seat (29).
• AttachtheSeat(29)tothetriangleseatbracketof
the Seat Post (32), secure with 3 Washers (30) and 3
NylonLocknuts(31).
Note:The3M8NylonLocknuts(31)and3M8Flat
Washers (30) are pre-assembled at the factory.
• SlidetheSeatPostDecorationCover(45)ontothe
Front Post (15).
• SlidetheBellows(54)ontotheSeatPost(32).
• InserttheSeatPost(32)intotheSeatPostMounting
Tube of the Main Frame (62).
• AfterassemblingtheSeatPost,youcanadjustthe
seat to the desired position.
10166-9
STEP 3
• Removethe4pre-assembledAllenHeadBolts(26),4
Spring Washers (27) and 4 Curved Washers (28) from
Front Post Mounting Tube of the Main Frame (62).
• FromthebottomendofFrontPost(15),slidetheFront
Post Decoration Cover (18) onto the Front Post (15).
• ConnecttheSensorWire(25)tothesocketofMiddle
Section Sensor Wire (9).
• ConnecttheLeadHeadoftheTensionCable(11)to
theCbracketonthebottomTensionCable(24).Follow
steps in figure A1-A4.
• SlidetheFrontPost(15)ontotheFrontPostMounting
Tube of the Main Frame (62) and secure using 4 Allen
Head Bolts (26), 4 Spring Washers (27) and 4 Curved
Washers (28).
• PulltheFrontPostDecorationCover(18)tothe
bottom of Front Post (15).
STEP 4
• AttachthethreadofHandlebar(2),whichhas2Hand
Pulses, to the welded clamp on the Front Post (15) and
secure it with Spacer (12), Clamp Decoration Cover
(69) and Wing Knob (14).
ASSEMBLY STEPS
CAUTION: Ensure that cables are not damaged
during assembly or when tightening screws
CAUTION: Ensure that cables are not damaged
during assembly or when tightening screws
10166-10
STEP 5
• Removethe4pre-assembledScrews(23)from
the Monitor (7).
• ConnecttheplugoftheMiddleSectionSensor
Wire (9) to the top section Sensor Wire which
comes from Monitor (7).
• Attachthemonitor(7)tothetopMonitorBracket
on the Front Post (15) with 4 Screws (23).
• AttachtheplugoftheHandPulseWire(6)tothe
jackoftheMonitor(7).
STEP 6
• AttachthePedalStraps(13R/13L)tothePedals
(36R/36L).
Note: The end with 4 adjustable holes must be set
outwards.
• ThePedals(36R/36L)andCrankArms(61)are
markedwith“R”&“L”(rightandleft).Connect
eachPedal(36R/36L)tothematchingCrankArm
(61).
Note: Therightpedal“R”shouldbethreadedon
clockwise.Theleftpedal“L”shouldbethreadedon
counter-clockwise.
ASSEMBLY STEPS
Recheck
all bolts and nuts are
tightened securely
before using the machine
CAUTION: Ensure that cables are not damaged
during assembly or when tightening screws
