Tripp Lite B007-008 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model Number: B007-008

KVM Switch - 8-Port 1U Rackmount KVM Switch with On-Screen Display

Highlights

Ultra-compact--occupies only 1U rack space

Does not require software or complicated setup--simply plug and play

Can be placed virtually anywhere (no AC power required)

Adapts to rack, stack under-monitor or desktop applications

Rackmount hardware included

Description

Tripp Lite's 8-port KVM Switch is the optimal solution for controlling up to 8 computers from one keyboard, mouse and monitor. Multiple KVM

switches can be cascaded together in order to control up to 512 computers. Easily switch ports using the On Screen Display (OSD), keyboard hot

key commands, or push buttons. Also supports ultra-high 180MHz video resolutions up to 1920 x 1440 pixels without noticeable degradation.

Innovative design adjusts to either rackmount or stacking installation... rackmount hardware included. Compatible with all major operating systems

except Mac and Sun. Constructed of heavy-duty steel housing.

System Requirements

PS/2 mouse and keyboard

PS/2 or USB computer (B015-000 PS/2 to USB adapter required for USB computers)

1 P753-Series PS/2 KVM cable kit for each connected computer

Compatible with all major operating systems except Mac and Sun

Package Includes

8-Port KVM Switch (rackmount ready)

Interlocking feet (for non-rackmount applications).

Optional AC power adapter

User manual

Features

Control up to 8 computers from a single keyboard, mouse, and monitor

Control up to 512 computers by cascading additional B007-008 KVM switches

Includes hardware for 1U mounting in a 19 in. rack

Supports video resolutions up to 1920 x 1440

Supports VGA, SVGA, or Multisync monitor

No software or complicated set-up procedures required

Swith between ports via OSD, pushbuttons, or keyboard hot key commands

Includes autoscan feature

Password security ensures that only authorized people have access to the connected computers

Keyboard and mouse emulation for dependable computer boot-up; works on all operating systems

Compatible with most mice, including scrolling mice

2 LEDs per port: one indicating the computer is connected and powered-on, and the other indicating the computer has the KVM focus

Compatible with all major operating systems except Mac and Sun

Constructed of heavy-duty steel housing

Specifications

OVERVIEW

# Of Users 1

Console No

Port Control Push Buttons, Hotkeys, OSD

Max CPU 512

PC/Server VGA; USB; PS/2

Product Rear View B007-008-rear.pdf

Cat5 KVM Switch No

IP Remote Access YES WITH B051-000

UPC ASSIGNMENT

Unit Carton UPC# 037332043573

PHYSICAL

Color Black

Style 1U Rackmount

LCD Monitor (in.) Not Applicable

LCD Monitor (cm) Not Applicable

ENVIRONMENTAL

BTUs 50Hz, 8.9 / 60Hz, 8.5

CONNECTIONS

Ports 8

WARRANTY

Product Warranty Period

(Worldwide)

1-year limited warranty

Related Items

Required Products

Related Model Description Qty.

P753-006 6-ft. KVM Switch PS/2 (3-in-1) Cable Kit for B007-008 1

Optional Products

Related Model Description Qty.

B013-330 KVM Switch Accessories - KVM Console Extender Kit 1

B015-000 USB Adapters - USB to PS/2 Adapter 1

B021-000-17 Rackmount Console - 1U Rackmount Console with 17" LCD 1

B051-000 KVM Switch Accessories - IP Remote Access Unit 1

P753-010 10-ft. KVM Switch PS/2 (3-in-1) Cable Kit for B007-008 1

P753-015 15-ft. KVM Switch PS/2 (3-in-1) Cable Kit for B007-008 1

U219-000-R USB to PS/2 Adapter

(USB A Male to 2x Mini-Din6 female)

WEXT-KVM-A1 1-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1

WEXT-KVM-A2 2-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1

WEXT-KVM-A3 3-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1

WEXT-KVM-A4 4-Year Warranty Extension - For select KVM Switches (see specific models for eligibility) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

http://www.tripplite.com/sku/B007-008.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
