Model #: TLP712B

Protect It! Surge Suppressor

Highlights

7 outlets / 12-ft. cord

1000 joule rating

$25,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TLP712B surge suppressor offers economical AC surge suppression for protection of workstations, desktop PCs, telecom systems and

other sensitive electronics. AC surge suppression shields connected equipment from damage and performance problems due to transient surges.

TLP712B offers 7 total outlets, 12 foot cord and diagnostic LED to confirm surge suppression in present. AC suppression rated at 1000 joules shields

equipment from surges and line noise. Attractive black suppressor housing with keyhole mounting slots and 1 designated transformer plug outlet

offer convenient protection of desktop computer equipment and accessories. Lifetime warranty with $25,000 Ultimate Lifetime Insurance (USA,

Puerto Rico & Canada Only).`

PLUG/OUTLETS: Input: NEMA5-15P/Output: 7 NEMA5-15R/12 ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)

FORMAT: Corded multi-outlet strip with 1 transformer spaced outlet

SUPPRESSION: AC: 150V RMS Clamping/1000 joules/330V UL1449 Let-through Rating

Applications

Ideal for any desktop, network or home computing application requiring AC protection

Package Includes

TLP712B Surge Suppressor

Instruction manual and warranty information

Features

1000 joules AC surge suppression shields equipment from the strongest surges and line noise

7 AC outlets with 1 transformer plug outlet that doesn't block remaining outlets

12 foot AC line cable conveniently reaches distant outlets

Built-in power switch with integrated 15 amp circuit breaker offers power control and overload protection over all outlets

Fail-safe thermal fusing protects against fire and other damage in the event of an extreme, extended overvoltage or surge condition

Diagnostic LED confirms surge suppression in present

Attractive black suppressor housing with keyhole mounting slots allow versatile placement options

UL1449 Rated (330V all modes), UL1363 (Power Tap), cUL (Canada)

Exceeds IEEE 587 category A & B surge suppression specifications

Lifetime warranty with $25,000 Ultimate Lifetime connected equipment insurance (USA, Puerto Rico & Canada Only)

Specifications

OVERVIEW

Intended Application Home/Office

SYSTEM OVERVIEW

Voltage compatibility 120V AC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity

(amps)

Output watts 1800

Outlet quantity / type 7 NEMA 5-15R

Outlet orientation Single row

Transformer accommodation Supports 1 large transformer plug accessory without covering remaining outlets, accepts up to 4 transformers

total

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 12 ft.

Input cord length (m) 3.7

Recommended Electrical

Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green) status

Switches Combination AC circuit breaker and 2 position red illuminated on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule rating 1000 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

UL1499 let through rating 330V - UL Verified

EMI / RFI filtering Up to 20 dB

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 1.8

Shipping weight (kg) 0.8

Shipping Dimensions

(HWD/in)

2.2 x 5.75 x 14.9

Shipping Dimensions

(HWD/cm)

5.6 x 14.6 x 37.8

Unit weight (lbs) 1

Unit weight (kg) 0.5

Unit Dimensions (HWD/in) 1.5 x 2.13 x 11.25

Unit Dimensions (HWD/cm) 3.8 x 5.4 x 28.6

Material of construction Plastic

Integrated keyhole mounting

tabs

Keyhole mounting slots enable wall mounting

Receptacle Color Black

AC line cord color Black

Style Strip

CERTIFICATIONS

Additional International

Approvals

RoHS

UL1449 1998 Rev. (AC

Suppression)

UL1449

NOM (Mexico) NOM

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$25,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3614.
