Tripp Lite Data Shield DB25-ALL Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: DB25-ALL

Network Surge Suppressor - Essential protection for data and communication lines

Highlights

Complete serial port (DB25) surge protection

Protects against the effects of electrostatic discharge, faulty wiring and

lightning

Lifetime product warranty

Heavy duty grounding lead

Description

Tripp Lite's DB25-ALL offers dataline surge suppression for any DB25 serial port, regardless of cable configurations. Connects and protects all 25

pins plus D shell chassis for universal protection of any DB25 application. User configurable for use with male or female captive DB25 port.

Convenient DB25 input and output connects directly to the protected port, obtaining a ground outlet from the computer chassis. Surge suppression

is handled with balanced arrays of high-speed avalanche diodes that divert excess energies created by electrostatic discharges, faulty wiring or

lightning away from network interface connections. Tripp Lite network surge suppressors reduce blown interface connections, garbled transmissions,

system lock-ups and hard equipment failure by safely shunting dataline surges to ground. Lifetime warranty.

SUPPRESSION: Reversible DB9 m/f jacks, protects pins 1-25 and chassis, 18V clamping

Applications

Ideal for the protection of data terminals, data communications equipment, PCs, printers, modems and more.

Package Includes

DB25-ALL dataline protector

Instruction manual and warranty information

Features

DB25 protects 25 pin serial connections for dataline surge suppression of data terminal, data communications equipment and PCs, printers,

modems and more

Reversible for use with male or female captive DB25 ports

Offers protection on all 25 data lines, plus D shell chassis

Surge suppression utilizing high speed avalanche diodes divert excess energies on the network to ground

Lifetime product warranty

Specifications

OVERVIEW

Intended Application Computer Networking

OUTPUT

Output volt amp capacity

(amps)

340 amps

INPUT

UPS input connection type DB25

Recommended Electrical

Service

120V, 230V

Input cord length (ft.) No Cord

SURGE / NOISE SUPPRESSION

Clamping voltage (RMS) 18V

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Additional Dataline Protection 1-25 & Chassis

PHYSICAL

Style In-Line

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=159.
