Tripp Lite TLP725 Manuel utilisateur

7-outlet, 25-ft cord, 1080 joule - Protect It! Surge

Suppressor

MODEL NUMBER: TLP725

Description

Tripp Lite's TLP725 surge suppressor offers economical AC surge suppression for protection of workstations, desktop PCs, telecom systems and other

sensitive electronics. AC surge suppression shields connected equipment from damage and performance problems due to transient surges. TLP725 offers 7

total outlets, 25 foot cord and diagnostic LEDs to warn of wiring problems and suppressor damage. AC suppression rated at 1080 joules shields equipment

from surges and line noise. Attractive white housing with keyhole mounting slots and 1 designated transformer plug outlet offer convenient protection of

desktop computer equipment and accessories. $25,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).`

PLUG/OUTLETS: Input: NEMA5-15P/Output: 7 NEMA5-15R/25 ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)

FORMAT: Corded multi-outlet strip with 1 transformer spaced outlet

SUPPRESSION: AC: 150V RMS Clamping/1080 joules/400V UL1449 Let-through Rating

Features

1080 joules AC surge suppression shields equipment from the strongest surges and line noise

7 AC outlets with 1 transformer plug outlet that doesn't block remaining outlets

25 foot AC line cable conveniently reaches distant outlets

Built-in power switch with integrated 15 amp circuit breaker offers power control and overload protection over all outlets

Fail-safe thermal fusing protects against fire and other damage in the event of an extreme, extended overvoltage or surge condition

Diagnostic LEDs confirm outlet grounding and surge suppression status

Attractive white housing with keyhole mounting slots allow versatile placement options

UL1449 3rd Edition Rated (400V all modes), UL1363 (Power Tap), cUL (Canada)

Exceeds IEEE 587 category A & B surge suppression specifications

$25,000 Ultimate Lifetime connected equipment insurance (USA, Puerto Rico and Canada only)

Highlights

7 outlets / 25-ft. cord

1080 joule rating

$25,000 Ultimate Lifetime

Insurance (USA, Puerto Rico &

Canada only)

Applications

Ideal for any desktop, network or

home computing application

requiring AC protection

Package Includes

TLP725 Surge Suppressor

Instruction manual and warranty

information

1 / 4

Specifications

OVERVIEW

Intended Application Home/Office

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 1800

Circuit Breaker (amps) 15

Outlet quantity / type 7 NEMA 5-15R

Transformer accommodation Supports 1 large transformer plug accessory without covering remaining outlets, accepts up to 4 transformers total

Outlet orientation Single row

INPUT

Nominal Input Voltage(s) Supported 120V AC

Recommended Electrical Service 120V (110-125V)

Input connection type NEMA 5-15P

Input cord length (ft.) 25

Input cord length (m) 7.62

Input cord gauge, type 14 gauge, SJT

Voltage compatibility (VAC) 120

Maximum Surge Amps 72000

LEDS ALARMS & SWITCHES

Switches Combination AC circuit breaker and illuminated on/off power switch

Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green) status

SURGE / NOISE SUPPRESSION

AC suppression joule rating 1080

AC suppression response time < 1 ns

Protection modes Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression

Clamping voltage (RMS) 150

UL1449 let through rating 400V

EMI / RFI filtering Up to 20 dB

DATALINE SURGE SUPPRESSION

2 / 4

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping Dimensions (HWD/in) 13.78 x 6.69 x 2.48

Shipping Dimensions (HWD/cm) 35.00 x 16.99 x 6.30

Shipping weight (lbs) 3.20

Shipping weight (kg) 1.45

Unit Dimensions (HWD/in) 1.32 x 2.05 x 11.69

Unit Dimensions (HWD/cm) 3.35 x 5.21 x 29.69

Unit weight (lbs) 3.04

Unit weight (kg) 1.38

Material of construction Plastic

Integrated keyhole mounting tabs Keyhole mounting slots enable wall mounting

Housing Color Light Gray

Receptacle Color Light Gray

AC line cord color Light Gray

Style Strip

Outlets center to center

measurement Distance between standard outlets = 29mm; Distance between last standard outlet and transformer outlet = 33mm

Keyhole slot center to center

measurement Distance between slots = 151mm; Distance between slot height = 24mm

CERTIFICATIONS

Additional International Approvals RoHS

UL1449 3rd Edition (AC

Suppression) UL1449 3rd EDITION

NOM (Mexico) NOM

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period (Worldwide) Lifetime limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $25,000 Ultimate Lifetime Insurance

3 / 4

Specifications are subject to change without notice. Photos may differ slightly from final products.
