Tripp Lite TLP1008TEL Manuel utilisateur
Protect It! 10-Outlet Surge Protector, 8 ft. Cord with
Right-Angle Plug, 2395 Joules, Tel/DSL Protection,
Black Housing
MODEL NUMBER: TLP1008TEL
Description
Perfect for your home or office workstation, the TLP1008TEL Protect It!® 10-Outlet Surge Protector features a surge protection rating of 2395 joules to defend
your sensitive electronic components against even the strongest surges and spikes.
Because residential power outlets have three wires—hot line (H), neutral (N) and ground (G)—the TLP1008TEL protects all three, covering the two protection
modes: full normal mode (H-N) and common mode (N-G/H-G). It also filters out electromagnetic interference (EMI) and radio frequency interference (RFI) that
can disrupt your electronics and inflict hardware damage or data loss.
Your devices plug into 10 NEMA 5-15R outlets, four of which are widely spaced to accept bulky transformers without blocking adjacent outlets. Sliding safety
covers block accidental contact with unused outlets. RJ11 jacks allow connection of telephone/fax/modem equipment, which is also protected from surges.
An integrated 15A circuit breaker protects all outlets and shuts down connected equipment in case of overload. Diagnostic LEDs confirm your wall outlet is
properly grounded and your connected equipment is protected.
The eight-foot AC power cord allows the TLP1008TEL to reach distant outlets, while its right-angle NEMA 5-15P plug allows furniture and equipment to be
placed flush against the wall to save space in your workstation. Keyhole slots incorporated into the bottom panel provide convenient wall or desk mounting
options for the black plastic housing.
Features
2395-Joule Surge Protection for Home or Office Electronics
Protects your computer, printer, scanner, router, modem and other small home electronics against even the strongest surges and spikes
Recommended for any desktop, network or home electronics application requiring AC line protection
Full normal mode (H-N) and common mode (N-G/H-G) line surge suppression
Filters out disruptive EMI/RFI line noise that can cause equipment damage or data loss
Exceeds IEEE 587 Category A and B surge suppression specifications
Highlights
10 NEMA 5-15R outlets,
including 4 for bulky transformers
2395-joule surge protection rating
Filters out threatening EMI/RFI
line noise
15A resettable circuit breaker
prevents dangerous overloads
8 ft. AC power cord with
right-angle NEMA 5-15P plug
Package Includes
TLP1008TEL Protect It! 10-Outlet
Surge Protector, Black Housing
RJ11 telephone cable, 6 ft.
Owner’s manual
1 / 4
10 Outlets Accept Wide Range of Electronic Devices
10 NEMA 5-15R AC outlets accept most computers and peripherals
4 widely spaced outlets accommodate bulky transformers without blocking other outlets
Sliding safety covers block accidental contact with unused outlets
Telephone/DSL Protection
RJ11 jacks (1 input/2 output) protect phone/fax/modem equipment from surges and spikes
Built-in splitter protects 2 devices sharing one line
6 ft. RJ11 telephone cable included
Premium Safety Features
On/off switch provides one-touch control over connected equipment
Integrated 15A circuit breaker shuts down outlets in case of power overload
Diagnostic LEDs confirm grounding and protection status at a glance
Conforms to current UL 1449 3rd Edition safety standards
Fits Effortlessly Into Your Workstation
8 ft. AC power cord with right-angle NEMA 5-15P plug allows furniture and equipment to be placed flush against the wall
Keyhole slots on bottom panel provide convenient wall or desk mounting options
Black plastic housing designed for long life
Backed by Tripp Lite’s Ultimate Lifetime Insurance
$150,000 Ultimate Lifetime Insurance covers any connected components damaged by power surge (U.S., Canada and Puerto Rico only)
Specifications
OUTPUT
Frequency Compatibility 50 / 60 Hz
Output Receptacles (10) 5-15R
Output (Watts) 1800W
Circuit Breaker (amps) 15A
Overload Protection 15A resettable circuit breaker
Transformer Accommodation Supports 4 large transformer plug accessories without covering remaining outlets, accepts up to 8 transformers total
Outlet Safety Covers Includes built-in sliding outlet safety covers
Outlet Orientation Two rows of outlets, including 4 widely spaced for transformers
Right-Angle Outlets No
INPUT
Nominal Input Voltage(s) Supported 120V AC
2 / 4
Recommended Electrical Service 120V (110-125V)
Input Connection Type NEMA 5-15P
Input Plug Features Space-saving right angle input plug
Input Cord Length (ft.) 8
Input Cord Length (m) 2.44
Input Cord Gauge Type 14 gauge, SJT
Voltage Compatibility (VAC) 120
Maximum Surge Amps 120000
Right-Angle Plug Yes
USER INTERFACE, ALERTS & CONTROLS
Switches Combination AC circuit breaker and two-position on/off power switch
Diagnostic LED Details Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
SURGE / NOISE SUPPRESSION
AC Suppression Joule Rating 2395
AC Suppression Response Time < 1 ns
Protection Modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping Voltage (RMS) 150
UL1449 Let Through Rating 400V - UL Verified
EMI / RFI Filtering Up to 40dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection Details 1 line
Cable (Coax) Protection No
Network (Ethernet) Protection No
PHYSICAL
Shipping Dimensions (hwd / in.) 14 x 7.75 x 2.25
Shipping Dimensions (hwd / cm) 35.56 x 19.69 x 5.72
Unit Dimensions (hwd / in.) 12 x 5.25 x 2
Unit Dimensions (hwd / cm) 30.48 x 13.33 x 5.08
Unit Weight (lbs.) 2
Unit Weight (kg) 0.91
Material of Construction Plastic
3 / 4
Integrated Keyhole Mounting Tabs Keyhole mounting tabs enable wall mounting
Housing Color Black
Receptacle Color Black
Color (AC Line Cord) Black
Outlets Measurement (Center to
Center) Between Standard Outlets = 28.4mm; Between Standard and Transformer Outlets = 56.8mm
Keyhole Slot Mounting
Measurement (Center to Center) 108mm
CERTIFICATIONS
UL1449 3rd Edition (AC
Suppression) UL1449 3rd Edition
UL1363 (Power Tap) UL1363
UL497A (Communications) UL497A
FCC Part 68 (Communications) FCC Part 68
cUL / CSA (Canada) cUL
Industry Canada (Communications) Industry Canada
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period (Worldwide) Lifetime limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico) $150,000 Ultimate Lifetime Insurance
© 2017 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
4 / 4
