Tripp Lite TLM626TEL15 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLM626TEL15

6 right-angle outlets, 15-ft cord, 1340 joules, all metal housing, RJ11 protection - Protect It! Surge Suppressor

Highlights

6 right-angle outlets / 15 ft. cord

1340 joule rating

Tel/DSL surge protection (1 line)

$75,000 Ultimate Lifetime Insurance (USA & Canada only)

Description

Tripp Lite's TLM626TEL15 surge suppressor offers complete AC and Tel/DSL line surge suppression for comprehensive protection of workstations,

personal computers, home stereos, televisions, VCRs, DVD players and other sensitive electronics. Heavy grade AC surge suppression shields

connected equipment from damage and performance problems due to transient surges. Set of RJ-11 telephone line suppression jacks protect a

single dialup modem, DSL modem, fax or phone line. TLM626TEL15 offers 6 right-angle outlets, a 15 foot power cord and diagnostic LEDs to warn

of wiring problems and suppressor damage. AC surge suppression rated at 1340 joules shields equipment from surges and line noise. Rugged metal

housing with 2 designated transformer plug outlets offers convenient protection of desktop computer equipment and accessories. $75,000 Ultimate

Lifetime Insurance (USA and Canada Only).

PLUG/OUTLETS: Input - 15 ft. AC line cord with NEMA 5-15P plug/Output - 6 NEMA 5-15R right-angle outlets

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)

FORMAT: Metal strip

SUPPRESSION: AC: 150V RMS Clamping/1340 joules/400V UL1449

Applications

Ideal for personal computers, TV/VCR/DVD, stereos and lamps/lighting

Package Includes

TLM626TEL15 surge suppressor

6 ft. RJ-11 phone cord

Instruction manual and warranty information

Features

6 right-angle outlets

15 ft. cord

Built-in RJ-11 jacks prevent surges from damaging your telephone/DSL/modem/fax equipment; 6 ft. telephone cord included

Surge suppression rating: 1340 joules

EMI/RFI noise filtering

15 amp resettable circuit breaker protects against overload

Diagnostic LEDs confirm suppressor "protection present" (green) and "grounded" (red) status

Convenient keyhole slots allow secure mounting on wall or desk

Can accommodate up to 2 transformers without blocking adjacent outlets

Rugged metal case provides extra safety and durability

Illuminated power switch

$75,000 Ultimate Lifetime Insurance (USA and Canada Only) covers connected equipment

Specifications

OVERVIEW

Intended Application Home/Office

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 1800

Circuit Breaker (amps) 15

Overload protection 15A resettable combo switch / circuit breaker

Outlet quantity / type 6 NEMA 5-15R

Transformer accommodation Supports 2 large transformers without covering adjacent outlets

Outlet orientation Single row of outlets

INPUT

Recommended Electrical

Service

120V (110-125V)

Input connection type NEMA 5-15P

Input cord length (ft.) 15

Input cord length (m) 4.57

Input cord gauge, type 14 gauge, SJT

Voltage compatibility (VAC) 120

Maximum Surge Amps 60000

LEDS ALARMS & SWITCHES

Switches Combination AC circuit breaker and 2 position on/off power switch

Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status

SURGE / NOISE SUPPRESSION

AC suppression joule rating 1340

AC suppression response

time

< 1 ns

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

Clamping voltage (RMS) 150

UL1449 let through rating 400V

EMI / RFI filtering Up to 20dB

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection

Details

1 line

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 2.5

Shipping weight (kg) 1.13

Unit Dimensions (HWD/in) 1.5 x 12.25 x 2.25

Unit Dimensions (HWD/cm) 3.81 x 31.12 x 5.72

Shipping Dimensions

(HWD/in)

2.25 x 15 x 6

Shipping Dimensions

(HWD/cm)

5.72 x 38.1 x 15.24

Unit weight (lbs) 1.8

Unit weight (kg) 0.82

Material of construction Metal

Integrated keyhole mounting

tabs

Keyhole slots enable mounting to a variety of surfaces

Receptacle Color Light Gray

AC line cord color Black

Style Strip

Form factors supported Supports floor / wall / desktop placement

Outlets center to center

measurement

Distance between standard outlets = 30.40mm; Distance between transformer and standard outlets = 45mm

Keyhole slot center to center

measurement

225mm

CERTIFICATIONS

Additional International

Approvals

Complies with RoHS (Restriction of Hazardous Substances Directive)

UL1449 3rd Edition (AC

Suppression)

UL1449 3rd EDITION

UL1363 (Power Tap) UL1363

FCC Part 68

(Communications)

FCC Part 68

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$75,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3295.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
