Tripp Lite TR-6 Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TR-6

6 outlet, 6-ft cord, 2420 joule Surge Suppressor - State of the art protection for every application

Highlights

6 outlets/6 ft. cord

2420 joule rating

$50,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

The TR-6 Surge Suppressor from Tripp Lite has 6 outlets and a 6-ft. cord with a space-saving right-angle plug. The unit has 2420 joules of surge

energy absorption to handle the strongest surges. Diagnostic LEDs alert the user to potential power problems. $50,000 Ultimate Lifetime Insurance

(USA and Canada Only). The Super Surge Alert comes with child safety covers and color-coded cord identifiers.

Applications

Personal computers, CAD/CAM/CAE workstations, network nodes, fileservers, point-of-sale terminals, audio/visual devices, and more.

Package Includes

TR-6 Surge Suppressor

Child Safety Covers

Color-coded cord identifiers

Instruction manual and Warranty information

Features

6 outlets with child safety covers

6-ft. cord with space-saving right-angle plug

$50,000 Ultimate Lifetime Insurance (USA and Canada Only) covers connected equipment -

Surge energy absorption: 2420 joules; 78,500 amps

15 amp circuit breaker

3 diagnostic LEDs indicate AC present, line fault & protection present

EMI/RFI noise filtering

Logical outlet spacing accommodates transformers without blocking remaining outlets

Keyhole supports for wall mounting

Recessed and lighted power switch

Color-coded cord identifiers

Specifications

OVERVIEW

Intended Application Home/Office

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 1800

Circuit Breaker (amps) 15

Outlet quantity / type 6 NEMA 5-15R

Transformer accommodation Holds up to 4 large transformer plugs

INPUT

Recommended Electrical

Service

120V (110-125V)

Input connection type NEMA 5-15P input plug

Input cord length (ft.) 6

Input cord length (m) 1.8

Voltage compatibility (VAC) 120

Maximum Surge Amps 97000

LEDS ALARMS & SWITCHES

Switches Two position red illuminated on/off power switch

Diagnostic LEDs PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)

SURGE / NOISE SUPPRESSION

AC suppression joule rating 2420

AC suppression response

time

< 1 ns

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

Clamping voltage (RMS) 140

AC suppression surge

current rating

78,500 amps

UL1449 let through rating 400V

Immunity Conforms to IEE 587 / ANSI C62.41

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 12.35

Shipping weight (kg) 5.6

Unit Dimensions (HWD/in) 1.75 x 3.5 x 9.5

Unit Dimensions (HWD/cm) 4.45 x 8.9 x 24.13

Shipping Dimensions

(HWD/in)

12.5 x 16.5 x 12.5

Shipping Dimensions

(HWD/cm)

31.75 x 41.9 x 31.75

Unit weight (lbs) 1.6

Unit weight (kg) .72

Material of construction Plastic

Integrated keyhole mounting

tabs

Keyhole mounting tabs enable wall mounting

Receptacle Color Gray

AC line cord color Gray

Style Strip

Outlets center to center

measurement

Distance between horizontal outlets = 44.20mm; Distance between vertical outlets = 39mm

Keyhole slot center to center

measurement

88.8mm

CERTIFICATIONS

UL1449 3rd Edition (AC

Suppression)

Tested to UL1449 3rd Edition by ETL

cUL / CSA (Canada) Approved for Canada by ETL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$50,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=124.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
