Tripp Lite SR2POST Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SR2POST

45U 2-Post SmartRack Open Frame Rack - Organize and Secure Network Rack Equipment

Highlights

45U 2-post open frame rack

Black aluminum with round threaded and numbered mounting holes

Toolless button holes to accept PDUs or cable managers

Description

SmartRack 2 post open frame racks are ideal for space constrained or cost conscious 19-inch rack mount applications. Multiple units can be bolted

together side by side.

Features

Supports 800lbs of rackmount equipment

Textured powder coat finish

Heavy Duty Aluminum construction

Numbered mounting positions

Bolt down provisions

Self squaring design

Black finish

Easy assembly

Specifications

PHYSICAL

Installed whole system

maximum rack depth (inches)

4.8

Installed whole system

maximum rack depth (cm)

12.19

Installed whole system total

rack space height (rack

spaces)

45U

Shipping weight (lbs) 29

Shipping weight (kg) 13.15

Shipping Dimensions

(HWD/in)

7 x 3 x 85

Shipping Dimensions

(HWD/cm)

17.78 x 7.62 x 215.9

Unit weight (lbs) 29

Unit weight (kg) 13.15

Unit Dimensions (cm) 213.36 x 51.56 x 12.07

Unit Dimensions (in) 84 x 20.3 x 4.75 (14" total depth with support base)

Color Black

Weight Capacity - Stationary

(lbs)

800

Weight Capacity - Stationary

(kg)

362.9

CERTIFICATIONS

NOM (Mexico) Tested to NOM (Mexico)

Approvals EIA-310-D, IEC 60297-3-100, DIN 41494, RoHS

WARRANTY

Product Warranty Period

(Worldwide)

5-year limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

KVM Switches &

Accessories

B019-000 KVM Switch Accessories - 2-Post Rackmount Bracket for B020,B021,

B040, and B070 Consoles and KVM Consoles

KVM Switches &

Accessories

B020-U08-19-IP Console KVM Switch - 8-Port NetDirector 1U Rackmount Console IP

KVM Switch w/17" LCD

KVM Switches &

Accessories

B021-000-17 Rackmount Console - 1U Rackmount Console with 17" LCD 1

KVM Switches &

Accessories

B040-008-19 NetController 19" VGA Console KVM Switch - 8 Port 1

KVM Switches &

Accessories

B040-016-19 NetController 19" VGA Console KVM Switch - 16 Port 1

Patch Panels N252-012 12-Port Cat6 Patch Panel

568B

Patch Panels N252-024 24-Port Cat6 Patch Panel

568B

Patch Panels N252-048 48-Port Cat6 Patch Panel

568B

Rack Accessories SRBOLTDOWN Bolt-Down Kit (Secures included stabilizing brackets or optional

stabilizing plates to facility floor.)

Rack Accessories SRCABLEDUCT1U 1U Horizontal Cable Manager (Finger duct with cover.) 1

Rack Accessories SRCABLEDUCTVRT 6-ft. (1.8 m) Vertical Cable Manager (Double finger duct with cover;

toolless mounting.)

Rack Accessories SRCABLELADDER 10-ft. x 1-ft. (3 m x 0.3 m) Cable Ladder (Includes 2 sections; requires

SRCABLETRAY.)

Rack Accessories SRCABLERING1U 1U Horizontal Cable Manager (Flexible ring type.) 1

Rack Accessories SRCABLERING2U 2U Horizontal Cable Manager (Flexible ring type.) 1

Rack Accessories SRCABLERINGVRT 6-ft. (1.8 m) Vertical Cable Manager (Flexible ring type; toolless

mounting.)

Rack Accessories SRFAN3U 3U Fan Panel, 120V (3 high-performance fans; 210 CFM; 5-15P plug.) 1

Rack Accessories SRSCREWS Threaded hole hardware kit - 50 each #12-24 screws 1

Rack Accessories SRSHELF2P 2U Cantilever Fixed Shelf (60 lb / 27 kg capacity; 18-in. / 457 mm

depth.)

Rack Accessories SRXFAN3U 3U Fan Panel, 230V (3 high-performance fans; 210 CFM; C14 inlet.) 1

Rack Accessories UPSHDEARKIT Heavy-Duty Mounting Ear Kit (Supports 2U cabinets up to 65 lb / 29 kg

from front vertical rails in 4-post or 2-post racks and enclosures. )

Rackmount Consoles B021-000-19 Rackmount Console - 1U Rackmount Console with 19" LCD 1

Rackmount Consoles B021-000-19-SH Rackmount Console - 1U Short-Depth Rackmount Console with 19"

LCD

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3208.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
