Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: DWM2342M

Full-Motion Wall Mount for 23" to 55" Flat-Screen Displays

Highlights

Can be used to increase available desk/table space in office applications

Fits most flat-panel displays from 23” to 55”

Convenient one-touch display adjustment for easy view optimization

Equipped with a bubble level for accurate display leveling

Wide range of motion with -10° to +10° tilt and 90° swivel capability

Supports up to 110 lbs.

5-year warranty

Description

Tripp Lite’s VESA-compliant DWM2342M Full-Motion Flat-Screen Wall Mount offers full-motion articulation and can free up valuable space in your

workstation by allowing you to effortlessly reposition your display at any time, even after installation. Its sleek design features convenient one-touch

display adjustment with tilt and swivel capabilities and fits most 23- to 55-inch flat-panel displays. Its durable, all-metal frame with scratch-resistant,

powder-coat finish withstands the stress of repeated use and blends easily into any décor. It comes with all necessary mounting hardware and

supports weights of up to 110 lbs. A built-in bubble level enables accurate display leveling. For peace of mind, the DWM2342M comes backed by a

5-year warranty.

Package Includes

DWM2342M Full-Motion Flat-Screen Wall Mount

Mounting Hardware

Owner’s Manual

Specifications

OVERVIEW

Display Mount Type Standard

Mounting Location Wall

PHYSICAL

Unit weight (lbs) 18.10

Unit weight (kg) 8.21

Color Black

Display Size (in.) 23 - 55

Display Size (cm) 58.42 - 139.70

VESA Pattern (mm) 50x75; 100x100; 200x200; 300x300; 400x400; 500x400

Motion Full Motion

Degrees of Motion -10/+10, 90 Swivel

Min/Max Arm Extension (in.) 5.51 min to 19.29 max

Min/Max Arm Extension (cm) 140 min to 490 max

Maximum Weight Capacity

(lbs)

110

Maximum Weight Capacity

(kg)

49.8

FEATURES/SPECIFICATIONS

Tools Necessary Yes

Cord Management No

WARRANTY

Product Warranty Period

(U.S. & Canada)

5-year limited warranty

Related Items

Optional Products

Related Model Description Qty.

TLP31SAT 3 outlet - 2 fixed outlets, 1 rotating power outlet and rotating coax, Direct plug-in, 1080

Joules, 1-line gold coaxial - Surge Suppressor

P502-006 6-ft. SVGA/VGA Monitor Gold Cable with RGB Coax (HD15 M/M) 1

P504-006-SM 6-ft. SVGA/VGA Compact RGB Coax Monitor Cable with Audio ( HD15 M/M, 3.5mm

M/M )

B130-101-WP-1 VGA over Cat5 ( RJ45 Type ) Extender Wallplate Kit ( Transmitter + Receiver ) 1

P560-006 6-ft. DVI Dual Link TMDS Cable (DVI-D M/M) 1

B140-101-WP DVI over Cat5 Passive Extender Wallplate Kit 1

B140-1A1-WP DVI over Cat5 Active Extender Wallplate Kit 1

P568-006-RA2 6-ft. High Speed HDMI Gold Cable with Right-Angle Connectors 1

P568-006-SW 6-ft. High Speed HDMI Gold Cable with Swivel Connectors 1

N042-001-WH White Keystone Faceplate - dual outlet 1

B125-101-60-WP HDMI over Dual Cat6 60Hz Wallplate Extender Kit 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=5531.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
