Tripp Lite N48LSS-16X16 Manuel utilisateur

Owner’s Manual

Spine-and-Leaf Singlemode

MPO/MTP Panels, 1U

Models: N48LSS-16X16, N48LSS-32X32

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Este manual está disponible en español en la página de Tripp Lite: tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com

Русскоязычная версия настоящего руководства представлена на веб-сайте компании

Tripp Lite по адресу: tripplite.com

Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: tripplite.com

WARRANTY REGISTRATION

automatically entered to win an ISOBAR®

surge protector in our monthly drawing!

tripplite.com/warranty

The N48LSS-16X16 and N48LSS-32X32 1U network panels are designed for spine-and-leaf architecture, which replaces

a standard MPO/MTP-to-LC cross-connect with MPO/MTP ports and helps eliminate significant rack clutter. Spine ports in

the front of the panel mate with a spine switch, and leaf ports in the rear mate with a leaf switch. Main components of the

panels are shown below:

Step 1: Extend the front and back side brackets, and secure the side screws.

Main Components

Installation

Spine Ports

Leaf Ports

Door

Front Wire

Manager

Back Wire

Manager

Installation

Step 2: Remove screws, rotate the front and back wire manager, and then tighten the screws.

Step 3: Mount the panel into an EIA-standard 19-inch rack, and secure the screws.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

21-06-215 • 93-3F51_RevA

Limited Lifetime Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for its

lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its sole discretion.

Service under this Warranty can only be obtained by your delivering or shipping the product (with all shipping or delivery charges prepaid) to: Tripp Lite,

1111 W. 35th St., Chicago, IL 60609. Seller will pay return shipping charges.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT.

SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT

PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE

LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND

CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these

devices for any specific application.

Product Registration

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE

Tripp Lite product!*

*No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support

equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from

actual products.

Network Mapping

Warranty and Product Registration

Spine-and-Leaf MPO/MTP Panel

Leaf

Leaf 1

Spine 1

Spine 2

Spine 3

Spine 4

Leaf 2

Leaf 3

Leaf 4

Leaf 16

Leaf

Ports

Spine

Ports

Spine
