Tripp Lite DMPDS3255CF Manuel utilisateur

Owner’s Manual

Portable Digital Signage

Stand for 32" to 55" Screens

Model: DMPDS3255CF

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Este manual está disponible en español en la página de Tripp Lite: tripplite.com

Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com

Русскоязычная версия настоящего руководства представлена на веб-сайте компании

Tripp Lite по адресу: tripplite.com

Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: tripplite.com

WARRANTY REGISTRATION

automatically entered to win an ISOBAR®

surge protector in our monthly drawing!

tripplite.com/warranty

CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR

PROPERTY DAMAGE MAY OCCUR!

75x75 / 100x100 /

200x100 / 200x200 /

300x200 / 300x300 /

400x400

55"

MAX 110 lb.110 lb.

(50 kg)(50 kg)

RATEDRATED

Safety Instructions

Warranty and Product Registration

Note: Read the entire instruction manual before you start assembly and installation.

WARNING

• Do not begin the installation until you have read and understood the instructions and warnings contained in this

manual. If you have any questions regarding any of the instructions or warnings, please visit tripplite.com/support.

• This mount was designed to be installed and utilized ONLY as speciﬁed in this manual. Improper installation of this

product may cause damage or serious injury.

• This product should only be installed by someone of good mechanical ability, with basic building experience and a full

understanding of this instruction manual.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not over-tighten. Over-tightening screws can damage the items, greatly reducing their

holding power.

• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal

injury.

5-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of

5 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the

product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO

EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED

WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE;

AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied

warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not

apply to you. This warranty gives you speciﬁc legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since

individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or ﬁtness of these devices for

any speciﬁc application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite

product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to change without notice. Photos and illustrations may differ slightly from actual

products.

Component Checklist

IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts

are missing or faulty, visit tripplite.com/support for service.

Package P

Package M

(x1)

(x2)

(x4)

(x2)

M-A

M5x14

(x4)

M-F

(x4)

M-G

(x8)

M-H

(x8)

M-B

M6x14

(x4)

M-C

M6x30

(x4)

M-D

M8x30

(x4)

M-E

M8x50

(x4)

Assembly

1Assembling the Stand

When the stand is on an uneven surface, use the included rubber pads Dto balance it.

Assembly

2a-1

2a-2

Attaching the Display to the Stand

VESA 75x75/100x100/100x150/200x100/

200x200/300x200/300x300

M-G

M-A M-B M-EM-D

M-C

M-F M-F M-F M-F

M-H

Assembly

VESA 400x400

M-G

M-EM-B M-C

M-D

M-H

Assembly

3Moving the Stand

Two people are recommended

for moving the stand while a

display is attached to it.

Assembly

Maintenance

Check at regular intervals (at least every 3 months) to make sure the display is secure and safe to use.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

21-02-280 • 93-3DD6_RevA
