Tripp Lite PS7224-20T Manuel utilisateur

24-outlet Vertical Power Strip with 20A Circuit

Breaker and 15-ft. Cord with Locking L5-20P Plug

MODEL NUMBER: PS7224-20T

Description

Tripp Lite's PS7224-20T power strip offers 20 amp, 120V multi-outlet AC power distribution in a convenient 72 inch mountable housing with NEMA L5-20

locking input plug. Offers horizontal or vertical power distribution in rackmount, raceway and workbench applications. Includes 24 output receptacles with 2.795

inch center-to-center spacing, 15 ft AC line cord and lighted power switch with locking transparent cover to prevent accidental shutoff. Sturdy all-metal extruded

aluminum housing stands up to demanding network, laboratory or factory environments.

INPUT/OUTPUT: Input: NEMA L5-20P (twist lock)/Output: 22 NEMA 5-15R & 2 NEMA 5-20R

ELECTRICAL: 120V AC, 50/60Hz, 20A

FORMAT: 72 in. corded, mountable power strip

Features

Sturdy all-metal 72 inch corded strip format with 2.795 inch center-to-center outlet spacing

Included mounting hardware supports vertical or horizontal mounting in rack enclosures, raceways and more

Includes 22 NEMA 5-15R and 2 NEMA 5-20R output receptacles

Includes NEMA L5-20 twist-lock input plug connection

Ideal for horizontal or vertical raceway style power distribution in office, workbench, industrial, networking and telecom applications

Lighted power switch with locking transparent cover prevents accidental shutoff

20 amp electrical capacity with circuit breaker

120V AC, 50/60Hz electrical compatibility

Specifications

OVERVIEW

Intended Application Home/Office

Highlights

24 outlets

Convenient and safe covered,

on/off switch

20-amp circuit breaker

15 ft. cord with locking L5-20

input plug

72" length

Applications

Offers vertical or horizontal

multi-outlet power distribution in

rack enclosures, raceways,

desktops and more.

Package Includes

PS7224-20T

Mounting hardware

Instruction manual

1 / 3

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 2400

Circuit Breaker (amps) 20

Outlet quantity / type 2 NEMA 5-15/20R & 22 NEMA 5-15R

Outlet spacing 2.795 in.

INPUT

Nominal Input Voltage(s) Supported 120V AC

Recommended Electrical Service 20A 120V

Input connection type NEMA L5-20P

Input plug features Black

Input cord length (ft.) 15

Input cord length (m) 4.572

Input cord gauge, type 12/3 SJT

Voltage compatibility (VAC) 120

LEDS ALARMS & SWITCHES

Switches Lighted 2 position switch controls power to all outlets

Locking switch cover Transparent on/off switch cover prevents accidental turn-off

PHYSICAL

Unit Dimensions (HWD/in) 72 x 1.5 x 1.5

Unit Dimensions (HWD/cm) 183 x 3.8 x 3.8

Unit weight (lbs) 6.6

Unit weight (kg) 2.9964

Material of construction Aluminum

Mounting accessories included Includes mounting clips

Receptacle Color Black

AC line cord color Black

Style Bench/Cabinet Mount

Form factors supported Supports vertical or horizontal mounting in rack enclosures, raceways and a variety of other applications

Outlets center to center

measurement 72mm

CERTIFICATIONS

2 / 3

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

WARRANTY

Product Warranty Period (Worldwide) Lifetime limited warranty

Specifications are subject to change without notice. Photos may differ slightly from final products.

3 / 3
