Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: PS7224-20HW

24-outlet Vertical Power Strip with Hardwire Input and 20A Circuit Breaker

Highlights

AC input hardwired via knockout on unit

24 outlets

Ideal for applications requiring permanent installation

Description

Tripp Lite's PS7224-20HW Power Strip offers 20 amp multi-outlet AC power distribution in a convenient 72 inch hardwire cabinet. Includes knockout

panels to accept 3/4 in. conduit fittings for hardwire installation and 24 output receptacles with 2.795 inch center-to-center spacing. Ideal for

horizontal or vertical raceway style power distribution in office, workbench, industrial, networking and telecom applications.

INPUT/OUTPUT: Input: Hard-wire access via knockout panels that accept 3/4 inch conduit fittings

Output: 24 outlets total, 2 NEMA 5-15/20R (20A) and 22 NEMA 5-15R (15A)

ELECTRICAL: 120V AC, 50/60Hz, 20A (no circuit breaker)

FORMAT: 72 inch strip format with 24 outlets

Applications

Offers multiple outlet power distribution for a variety of applications, including office, workbench, industrial, networking, telecom and more.

Package Includes

PS7224-20HW

Instruction manual

Features

Versatile all-metal 72 inch format with outlets arranged in a single row

Knockout panels for 3/4 inch conduit fittings allow permanent hardwire installation

Ideal for horizontal or vertical raceway style power distribution in office, workbench, industrial, networking and telecom applications

24 outlets total, 2 NEMA 5-15/20R (20A) and 22 NEMA 5-15R (15A)

20 amp electrical capacity

120V AC, 50/60Hz electrical compatibility

Specifications

OVERVIEW

Intended Application Home/Office

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 2400

Circuit Breaker (amps) 20

Outlet quantity / type 22 NEMA 5-15R & 2 NEMA 5-15/20R

Outlet spacing 2.795 in.

INPUT

Nominal Input Voltage(s)

Supported

120V AC

Recommended Electrical

Service

20A 120V

Input connection type Hardwire

Input cord length (ft.) 15

Voltage compatibility (VAC) 120

PHYSICAL

Unit Dimensions (HWD/in) 72 x 1.5 x 1.5

Unit Dimensions (HWD/cm) 182.88 x 3.8 x 3.8

Material of construction Metal

Integrated keyhole mounting

tabs

Mount through housing supports bolt down installation to a variety of flat surfaces

Receptacle Color Almond

Style Bench/Cabinet Mount

Outlets center to center

measurement

101.60mm

CERTIFICATIONS

cUL / CSA (Canada) cUL

Approvals UL

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=201.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
