Tripp Lite PS-415-HG-OEM Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: PS-415-HG-OEM

4-outlet Medical-Grade Power Strip for Use in Patient-Care Areas

Highlights

Designed to be installed on any mobile cart, IV pole, etc.

Tested to UL 1363A to supply power to plug-connected components of a

movable equipment assembly that is rack-, table- or pedestal-mounted

4 hospital-grade receptacles and hospital-grade plug

15-ft. cord

Two 15-amp resettable circuit breakers

Description

Tripp Lite's PS-415-HG-OEM Power Strip is designed to be installed on any mobile cart, diagnostic equipment, instrument, IV pole, etc. It is

designed to supply power to plug-connected components of a movable eqiupment assembly that is rack-, table- or pedestal-mounted. Features 4

output receptacles, 15-ft. AC power cord and two built-in resettable circuit breakers that control power to all outlets and protect against overloads.

Switchless design prevents accidental shutoff. Optional-use keyhole mounting tabs and flanges.

PLUG/OUTLETS: NEMA 5-15P-HG hospital-grade plug and 4 NEMA5-15R-HG hospital-grade receptacles

ELECTRICAL: 120V AC, 50/60Hz, 15A

FORMAT: All-metal corded multi-outlet strip

Applications

Mobile carts, IV poles and other UL 1363A certified usages.

Can be used in Patient Care Areas, when properly mounted.

Package Includes

PS-415-HG-OEM Power Strip

Owner's manual and warranty information

Features

Versatile power distribution strip designed to be installed on any mobile cart, IV pole, etc.

Meets UL 1363A to supply power to plug-connected components of a movable equipment assembly that is rack-, table- or pedestal-mounted

4 x NEMA 5-15R-HG hospital-grade output receptacles

15-ft. AC cord with integrated, molded NEMA5-15P-HG hospital-grade plug

Rugged all-metal housing withstands years of use without breakage

15A electrical capacity with two built-in resettable circuit breakers

120V, 50/60Hz

Optional-use keyhole mounting tabs and flanges

Switchless design prevents accidental shutoff

Specifications

OVERVIEW

Model Type For Patient-Care Areas

OUTPUT

Frequency compatibility 50 / 60 Hz

Circuit Breaker (amps) 15

Overload protection 2 x 15amp breakers (1 line, 1 neutral)

Outlet quantity / type 4 NEMA 5-15R-HG

Outlet orientation Single row of 4

INPUT

Recommended Electrical

Service

15A, 120V

Input connection type NEMA 5-15P-HG

Input cord length (ft.) 15

Input cord length (m) 4.572

Input cord gauge, type 14 gauge, SJT

Voltage compatibility (VAC) 120

LEDS ALARMS & SWITCHES

Switches No power switch

PHYSICAL

Shipping weight (lbs) 3.55

Shipping weight (kg) 1.61

Unit Dimensions (HWD/in) 8.65 x 2.5 x 1.5

Unit Dimensions (HWD/cm) 21.97 x 6.35 x 3.81

Shipping Dimensions

(HWD/in)

15 x 6 x 3.55

Shipping Dimensions

(HWD/cm)

38.1 x 15.24 x 9.02

Unit weight (lbs) 2.25

Unit weight (kg) 1.02

Material of construction Metal

Integrated keyhole mounting

tabs

Keyhole mounting tabs and flanges enable mounting to a variety of surfaces

Receptacle Color White

AC line cord color White

Outlets center to center

measurement

Inner outlets = 32.5mm

Keyhole slot center to center

measurement

Distance between keyhole tabs = 127mm; Distance between end tabs = 207.45mm

CERTIFICATIONS

Approvals TUV tested to UL 1363A

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3720.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
