Tripp Lite PDUMH20HVNET Manuel utilisateur
Single-Phase Switched PDU, 3.2-3.8kW 16/20A
200-240V, 1U Horizontal Rackmount, 8 C13 outlets,
C20 inlet with L6-20P and C20 cables
MODEL NUMBER: PDUMH20HVNET
Description
Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring
with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical
conditions and remotely monitor output power consumption. PowerAlert interface supports remote control and
custom notification of user-specified conditions via email, secure web, SNMP, Telnet or SSH interface.
Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined
power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is
first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in
amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch
breakers trip.
Features
16/20A 200/208/230/240V Switched Power Distribution Unit / PDU with built-in web/network interface (Agency derated to 16A continuous)
C20 inlet; 8.5 ft. / 2.6m C20 power cable with L6-20P plug adapter
8 switched C13 outlets
1U horizontal rackmount form factor
Supports power-on, power-off or reboot of each outlet on a real-time or programmable basis
Enables reboot of locked equipment, custom power-on/power-off sequences, load-shedding of optional loads and disabling unused outlets
Network interface provides PDU control and data regarding input voltage, frequency and loading information
Digital display reports load level information in amps
Supports user-specified alarm notification thresholds
In-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4 optional SRSWITCH
door sensors
DHCP/Manual configuration support
10/100 Mbps auto-sensing
Highlights
Switched 16/20A 200-240V PDU,
1U Horizontal Rackmount format
Reports voltage, frequency &
loading information via ethernet
interface
Visual current meter, reversible
housing
C20 inlet; 8.5ft / 2.6m C20 input
cable with L6-20P adapter
8 C13 switched outlets with cord
retention brackets
Temperature, humidity and
contact-closure monitoring
options
Applications
Ideal for power distribution in
datacenters, computer rooms
and network closets
Package Includes
Rackmount PDU
Rack mounting brackets
1 / 4
Real-time clock backup maintains the time of day and date even if the PDU is unpowered
Tiered access privileges allow an administrator and a guest to login via web browser
Alert notifications via email or SNMP traps offer immediate event notification
Firmware upgrade ability supports future product enhancements
Supports HTTP, HTTPS, PowerAlert Network Management System, SMTP, SNMPv1, SNMPv2, Telnet, SSH, FTP, DHCP, BOOTP, NTP protocols
Fully compatible with FREE PowerAlert Network Management System / NMS Software
1U horizontal rack installation supported in 2 or 4 post racks with included mounting brackets
Mounting brackets support wall-mount and under-counter installation in many applications
Included cord retention brackets
TAA Compliant Version Available - Order Tripp Lite PDUMH20HVNETAA
Specifications
OVERVIEW
PDU Type Switched
OUTPUT
Output Capacity Details 3.3kW (208V input), 3.5kW (220V input), 3.7kW (230V input), 3.8kW (240V input), 3.2kW (200V input); 20A
maximum (Agency de-rated to 16A continuous)
Frequency compatibility 50 / 60 Hz
Output nominal voltage 200-240V nominal, single phase
Overload protection Outlets are arranged in a single unbreakered load bank
Outlet quantity / type 8 C13 outlets
Outlet Type IEC-C13
Customized load management
receptacles Each outlet is individually controllable via remote interface
INPUT
PDU Input Voltage 200; 208; 220; 230; 240
Maximum Input Amps (A) 20
Maximum Input Amps (A) Details Agency de-rated to 16A continuous
PDU Plug Type NEMA L6-20P; IEC-320 C20
Input cord length (ft.) 8.5
Input cord length (m) 2.6
Phase Single-Phase
LEDS ALARMS & SWITCHES
Switches n/a
Front panel LEDs 8 power availability LEDs confirm power off/on status for each built-in outlet
2 / 4
PHYSICAL
Shipping Dimensions (HWD/in) 5.3 x 20.7 x 23.2
Shipping Dimensions (HWD/cm) 13.5 x 52.6 x 37.6
Shipping weight (lbs) 14.2
Shipping weight (kg) 6.4
Unit Dimensions (HWD/in) 1.75 x 17.3 x 14.8
Unit Dimensions (HWD/cm) 2.87 x 43.9 x 37.6
Unit weight (lbs) 9
Unit weight (kg) 4.1
Material of construction Steel
Style Rackmount
Form factors supported 1U rackmount. Includes mounting accessories for 2-4 post racks
PDU Form Factor Horizontal (1U, 2U, etc)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
COMMUNICATIONS
SNMP compatibility Yes, pre-installed SNMPWEBCARD provides remote monitoring via web, telnet, and SNMP management systems.
Remote management gives user ability to turn connected loads on or off individually
CERTIFICATIONS
TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDUMH20HVNETAA
Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), ), CE (IEC 60950), (RoHS compliant)
WARRANTY
Product Warranty Period (Worldwide) 2-year limited warranty
Related Items
Optional Products
Model Number Description Qty.
WEXT3-PDU-HVNET 3-Year Extended Warranty - For Switched PDUs ending with HVNET 1
3 / 4
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/PDUMH20HVNET.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
4 / 4
