Tripp Lite SmartRack SRW6U Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model Number: SRW6U

SmartRack 6U Wall-Mount Rack Enclosure Cabinet

Highlights

Designed for VoIP closets and education environments where equipment

needs to be secure and out of the way

6U with adjustable front vertical rackmount rails

Locking, reversible front door and locking, removable side panels

Fully assembled for quick installation

Meets all enclosure requirements towards PCI DSS (Payment Card Industry

Data Security Standard) Compliance

Description

Tripp Lite’s SRW6U Wall Mount Rack Enclosure Cabinet is the ideal storage solution for standard rackmount equipment in applications with limited

floor space such as wiring closets, POS stations and offices. Constructed with a sturdy wall mounting bracket and steel frame, it can accommodate

up to 140 lbs. of equipment in 6U of rack space. Adjustable vertical mounting rails with square holes accommodate all standard 19-inch rack

equipment.

The SRW6U features a perforated lockable front door and side panels, assuring generous airflow to keep equipment operating safely. The side

panels are removable for easy access to equipment, and the front door is reversible. The top and bottom panels of the enclosure include convenient

cable routing ports. The SRW6U ships fully assembled and comes with a 5-year manufacturer’s product warranty.

Applications

IT network environments with limited floor space, VoIP closets, and classrooms where equipment needs to be secure and out of the way of

students.

Package Includes

SRW6U Wallmount Rack Enclosure

(12) M6 screws

(12) M6 cage nuts

(12) M6 washers

(2) Keys

Owner's Manual

Features

6U wall-mounted enclosure

Ideal for VoIP wiring closets and education venues that require security

Adjustable mounting depths up to 17" by 2 front vertical rackmount rails

Ventilated front door and side panels for increased airflow

Locking, reversible front door

Locking, removable side panels

Fully assembled for quick installation

Meets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) Compliance

Specifications

PHYSICAL

Installed whole system

maximum rack depth (inches)

16.5

Installed whole system

maximum rack depth (cm)

41.9

Installed whole system

minimum rack depth (inches)

Rack Height 6U

Shipping Dimensions

(HWD/in)

17.5" x 26.5" x 20.5"

Shipping Dimensions

(HWD/cm)

44.45 x 67.31 x 52.07

Shipping weight (lbs) 32

Shipping weight (kg) 14.5

Unit Dimensions (in.) EXTERNAL DIMENSIONS: 14.5" x 23.63" x 17.5" (HWD)

Unit weight (lbs) 29

Unit weight (kg) 13

Unit Dimensions (cm) 36.83 x 60.02 x 44.45

Color Black

Style Wall Mounted

Weight Capacity - Stationary

(lbs)

200

Weight Capacity - Stationary

(kg)

90.7

Cable Access Hole

Measurement (inches)

9.812 x 2.35 (l x w)

SPECIAL FEATURES

Grounding lug Front and Back door frames

CERTIFICATIONS

Certifications EIA-310-E

NOM (Mexico) Tested to NOM (Mexico)

Approvals RoHS

WARRANTY

Product Warranty Period

(Worldwide)

5-year limited warranty

Related Items

Optional Products

Related Model Description Qty.

SRFANWM Wall-Mount Roof Fan Kit, 120V (2 high-performance fans; 5-15P plug) 1

SRSHELF2P1U 1U Cantilever Fixed Shelf (40 lb / 18 kg capacity; 12-in. / 305 mm depth.) 1

UPSHDEARKIT Heavy-Duty Mounting Ear Kit - Supports 2U cabinets up to 65 lb / 29 kg from front

vertical rails in 4-post or 2-post racks and enclosures. )

SRSWITCH Magnetic Door Switch Kit for front and rear doors; requires ENVIROSENSE 1

SRCASTER Heavy-Duty Rolling Caster Kit (Includes 4 casters. Casters are included with 48/42/25U

enclosures.)

SRCAGENUTS Square Hole Hardware Kit (Includes 50 M6 screws and washers.) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

http://www.tripplite.com/sku/SRW6U.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
