Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: S065-42I

42-inch Internal SCSI U320 5-Drive LVD Ribbon Cable with Terminator (6xHD68 M)

Highlights

Premium cabling

Description

Introducing Tripp Lite's internal ribbon SCSI Ultra320 5-drive LVD/SE cable with an active mode-conditioning T-type crimped on terminator. LVD/SE

multi-mode termination enables backward compatibility to legacy single ended devices. The terminator will sense if the bus is running LVD or SE and

terminate appropriately. This cable measures 42 inches in length from master to drive #5 and is UL rated with premium brand cabling. Meets the

latest SCSI specification of ANSI (American National Standards Institute). For 3-Drive Connection, see S063-31I, or, for Round Version cables, see

S073-31I and S075-42I. Tripp Lite warrants this product to be free from defects in materials and workmanship for life.

System Requirements

U320/U160 SCSI HBA (host bus adapter card)

Any internal SCSI drive or device requiring HD68M interface

Package Includes

42-in. Internal U320 SCSI Ribbon Cable 6Conn 68Pin 5Drive with Terminator

Features

Length (master to drive 5): 42 inches

Supports transfer speeds up to 320Mbps

Connect up to 5 drives or internal devices

HD68 male connectors

Cable includes active mode conditioning terminator T-type LVD/SE terminator with local chip (ART IDC type)

SCSI U320 cables include active multi-mode terminators which compensate for fluctuations in the host adapter

Constructed with premium brand twist and flat brand cable

UL rated cable

All Tripp Lite SCSI products, regardless of the SCSI generation, meet the latest specifications of ANSI

Tripp Lite offers a complete line of internal and external solutions for SCSI/RAID and fibre channel ranging from the very latest Ultra 320 to

legacy SCSI-1 and every combination in between

Tripp Lite warrants this product to be free from defects in materials and workmanship for life

Specifications

OVERVIEW

Drives Supported 5

Intended Application Connecting Drives

Model Type SCSI Ultra320 Flat Ribbon

INPUT

Cable Length (in.) 42

PHYSICAL

Color Gray

Style Ribbon & Internal Cables

CONNECTIONS

Connector A

INTERNAL HD68 (MALE)

Connector B

HD68 (MALE)

Number of Connectors 6

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

SCSI Cables S063-31I 31-inch Internal SCSI U320 3-Drive LVD Ribbon Cable with Terminator

(4xHD68 M)

SCSI Cables S450-010 6-ft. SCSI Ultra2/U160/U320 LVD Cable

(HD68 M/M w/thumbscrews)

SCSI Cables S454-006 6-ft. SCSI Ultra2/U160/U320 LVD Cable

(Offset-VHDCI-M/HD68M)

SCSI Cables S456-006 6-ft. SCSI Ultra2/U160/U320 LVD Cable

(Offset-VHDCI M/M w/thumbscrews)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2358.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
