Tripp Lite N806-10M Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: N806-10M

10M (33-ft.) 10Gb Duplex MMF 50/125 OM3 LSZH Patch Cable, (SC/SC) - Aqua

Highlights

Designed for 10-Gig Ethernet applications...OM3 rated

Backward compatible with existing 50/125 fiber

Max 10Gb distance of 300 meters @850nm

Low-Smoke, Zero Halogen (LSZH) Aqua jacket

Description

Tripp Lite introduces it's new OM3 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, for use with 10Gb Ethernet applications. These new

technology, 50/125um, SC/SC Fiber Optic cables, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with

performance rivaling that of Single mode cable, at a much reduced cost. LOMMF cable allows 10Gb serial transmission over extended distances in

the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution.

LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers.

Applications

For use with 10-Gigabit Ethernet equipment

Package Includes

10 meter Duplex Multimode 50/125 Aqua OM3 Fiber Patch Cable, SC/SC

Features

10 Meter (33ft) SC/SC 10Gig, OM3 rated

10gb Ethernet speed to 300 meters @850nm

Use with VCSEL and LED laser light sources

High-Speed, High-Bandwidth, Low-Cost

Backward compatible with legacy LAN's

Ideal for Fibre Channel (SAN) applications

IEEE 802.3ae and TIA LOMMF compliant

Specifications

OVERVIEW

Clad Diameter 125um

Core Diameter 50um

Fiber Type 50/125 LOMMF

Number of Fibers 2

Intended Application Computer Networking (Fiber)

INPUT

Cable Length (m) 10

PHYSICAL

Color Aqua

Style Fiber Optic

CONNECTIONS

Connector A

Connector B

Number of Connectors 4

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Fiber Optic Cables &

Adapters

N806-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable

(SC/SC) - Aqua

Fiber Optic Cables &

Adapters

N806-15M 15M (50-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (SC/SC) -

Aqua

Fiber Optic Cables &

Adapters

N816-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable

(LC/SC) - Aqua

Fiber Optic Cables &

Adapters

N816-10M 10M (33-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable

(LC/SC) - Aqua

Fiber Optic Cables &

Adapters

N816-15M 15M (50-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable

(LC/SC) - Aqua

Fiber Optic Cables &

Adapters

N820-03M 3M (10-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable

(LC/LC) - Aqua

Fiber Optic Cables &

Adapters

N820-10M 10M (33-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (LC/LC) -

Aqua

Fiber Optic Cables &

Adapters

N820-15M 15M (50-ft.) 10Gb Duplex MMF 50/125 LSZH Patch Cable, (LC/LC) -

Aqua

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2997.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
