1
Owner’s Manual
USB 3.1 Gen 1 USB-C™ to
DisplayPort Adapter with
Charging
Model: U444-06N-DP-C
USB Type-C and USB-C are trademarks of USB Implementers Forum
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Este manual esta disponible en español en la página de
Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de
Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена
на веб-сайте компании Tripp Lite по адресу: www.tripplite.com
17-10-006-933559-EN.indd 1 10/4/2017 5:27:07 PM
2
Package Contents
Product Features
• U444-06N-DP-C
• Owner’s Manual
• Supports USB DisplayPort Alternate Mode for
connecting a DisplayPort monitor via a USB-C port
• Supports 4K x 2K Ultra High Definition (UHD)
resolutions up to 3840 x 2160 (60 Hz)
• USB-C Power Delivery (PD) charging port charges
your device
• USB-C port supports power input up to 20V 3A
(60W)
• Plug and play; no software or drivers required
Optional Accessories
• P580-Series DisplayPort Cables
• U420-003 USB 3.1 Gen 1 USB-C Male/Male
Cable – 3 ft.
17-10-006-933559-EN.indd 2 10/4/2017 5:27:07 PM
3
Installation
1. Connect the adapter’s USB-C connector to
the USB-C port on your laptop, tablet or other
compatible device.
2. Connect the adapter’s DisplayPort to the monitor’s
DisplayPort using a DisplayPort cable (such as
Tripp Lite’s P580-Series DisplayPort cables).
3. Charge your device by connecting its USB-C charger
to the adapter’s USB-C port.
Input Connectors
USB USB-C (Male)
PD Charging USB-C (Female)
Output Connectors
DisplayPort DisplayPort (Female)
Environmental
Operating Temperature 32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C PD Charging Port Supports up to 20V 3A (60W) Input
Specifications
17-10-006-933559-EN.indd 3 10/4/2017 5:27:07 PM
4
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials
and workmanship for a period of three (3) years from the date of
initial purchase. TRIPP LITE’s obligation under this warranty is limited
to repairing or replacing (at its sole option) any such defective
products. To obtain service under this warranty, you must obtain a
Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned
to TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place
of purchase. This warranty does not apply to equipment, which has
been damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s) may
not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as
lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third
parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a chance
to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions
apply. See website for details.
17-10-006-933559-EN.indd 4 10/4/2017 5:27:07 PM
5
Warranty and Product Registration
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate this
equipment.
17-10-006-933559-EN.indd 5 10/4/2017 5:27:07 PM
6
WEEE Compliance Information for Tripp Lite Customers and
Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations, when
customers buy new electrical and electronic equipment
from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like
basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Use of this equipment in life support applications where failure of
this equipment can reasonably be expected to cause the failure
of the life support equipment or to significantly affect its safety or
effectiveness is not recommended. Do not use this equipment in
the presence of a flammable anesthetic mixture with air, oxygen or
nitrous oxide.
Tripp Lite has a policy of continuous improvement. Specifications are
subject to change without notice.
Warranty and Product Registration
17-10-006-933559-EN.indd 6 10/4/2017 5:27:07 PM
7
17-10-006-933559-EN.indd 7 10/4/2017 5:27:07 PM
817-10-006 93-3559_RevC
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
17-10-006-933559-EN.indd 8 10/4/2017 5:27:07 PM
