Tripp Lite U444-06N-HD-AM Manuel utilisateur
1
Quick Start Guide
USB 3.1 Gen 1 to
HDMI Alternate Mode
Adapter – White
Model: U444-06N-HD-AM
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $50 value!
www.tripplite.com/warranty
15-06-112-933482-EN.indd 1 6/19/2015 9:33:12 AM
2
Product Features
• Supports USB DisplayPort Alternate Mode for
transmitting audio/video signals to an HDMI
monitor via the USB Type-C™ (USB-C™) port on
your smartphone, tablet, Ultrabook or computer
• Plug-and-Play adapter; no drivers required
• Supports Ultra High Definition (UHD) 4Kx2K video
resolutions up to 3840 x 2600 (60Hz)* or
3840 x 2160 (24/25/30Hz)
• Supports up to 36-bit Deep Color (12-bits per
channel)
• Supports per-lane data transfer rates of 5.4Gbps
(HBR2), 2.7Gbps (HBR) and 1.62Gbps (RBR)
• USB 3.1 Gen 1 supports data transfer rates up to
5Gbps
• Compatible with USB Type-C devices that support
USB DisplayPort Alternate Mode
*3840 x 2600 @ 60Hz supported in Single Stream Transport
(SST) mode only. Additional monitors cannot be connected
using Multi Stream Transport (MST) mode.
USB Type-C™ and USB-C™ are trademarks of USB
Implementers Forum.
15-06-112-933482-EN.indd 2 6/19/2015 9:33:12 AM
3
System Requirements
System Requirements
Package Contents
• USB Type-C (USB-C) device that supports USB
DisplayPort Alternate Mode
• HDMI-enabled monitor
1. Connect the adapter’s USB Type-C connector to
the USB Type-C port on your smartphone, tablet,
Ultrabook or computer.
2. Connect the adapter’s HDMI port to a monitor
using an HDMI cable (such as Tripp Lite’s
P568-Series cables).
3. The video image will appear on the add-on
monitor. Customize how video is displayed on
the add-on monitor using your device’s display
settings.
• U444-06N-HD-AM
• Quick Start Guide
15-06-112-933482-EN.indd 3 6/19/2015 9:33:12 AM
4
Specifications
Connectors
USB USB Type-C (Male)
Display HDMI (Female)
Video
Maximum Resolutions 3840 x 2600 (60Hz)*,
3840 x 2160 (24/25/30Hz)
Color Depth 36-bit Deep Color
(12-bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14° to 176°F (-10° to 80°C)
Storage Humidity 5% to 90% RH,
Non-Condensing
Power Requirements
External Power Supply No
*3840 x 2600 @ 60Hz supported in Single Stream Transport
(SST) mode only. Additional monitors cannot be connected
using Multi Stream Transport (MST) mode.
15-06-112-933482-EN.indd 4 6/19/2015 9:33:12 AM
5
Warranty and Product Registration
1-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects
in materials and workmanship for a period of one (1) year
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Some states do not permit limitation
or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
15-06-112-933482-EN.indd 5 6/19/2015 9:33:12 AM
6
Warranty and Product Registration
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
15-06-112-933482-EN.indd 6 6/19/2015 9:33:12 AM
7
Warranty and Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to
operate this equipment.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
15-06-112-933482-EN.indd 7 6/19/2015 9:33:12 AM
8
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
15-06-112 93-3482_Rev A
15-06-112-933482-EN.indd 8 6/19/2015 9:33:16 AM
