TRENDnet TEW-670AP Manuel utilisateur

TEW-670AP

rev: 04.27.2010

The 300Mbps Concurrent Dual Band Wireless N Access Point provides high

performance wireless n speed, coverage, and managed controls.

Concurrent Dual Band technology creates two separate wireless n networks at the

same time—one on the 2.4GHz frequency and the other on the less congested

5GHz frequency. Assign high bandwidth clients to the uncongested 5GHz

frequency and low bandwidth clients to the more common 2.4GHz frequency.

Multiple Input Multiple Output (MIMO) antenna technology reduces wireless dead

spots. Wi-Fi Protected Setup (WPS) integrates other WPS supported devices at the

touch of a button. Advanced features include 4 SSIDs per wireless band, access

filters for each SSID, WMM Quality of Service data prioritization, WPA2-RADIUS

encryption, and real-time bandwidth monitoring for each wireless band.

TEW-670AP(V1.0R)

300Mbps Concurrent Dual Band Wireless N Access Point

• IEEE 802.11n and IEEE 802.11a/b/g compliant

• Transmits simultaneous 2.4GHz and 5GHz Wireless Local Area Network (WLAN) signals (with separate default SSIDs)

• 1 x 10/100Mbps Auto-MDIX LAN port

• Functional Access Point and WDS m odes provide network flexibility

• High-speed data rates up to 300Mbps using an IEEE 802.11n connection

• 2 external antennas provide high-speed performance and expansive wireless coverage

• Advanced wireless security with 64/128-bit WEP, WPA/WPA2-RADIUS and WPA-PSK/WPA2-PSK

• Supports DHCP server and static DHCP settings

• Supports multiple SSIDs (up to 4 SSIDs per band)

• Monitor bandwidth allocation through Web based graphical interface

• User isolation support (AP mode) and MAC address filter controls

• Wi-Fi Protected Setup (WPS) integrates wireless clients quickly

• Wi-Fi Multimedia (WMM) QoS data prioritization

• Easy setup via Web browser using the latest versions of Internet Explorer, FireFox, and Safari

• Works with Windows, Linux, and Mac operating systems

• 3-year limited warranty

Features

Standards

LAN

WPS Button

WDS

Frequency

LED Indicator

Antenna

• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)

• Wireless: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

• 1 x 10/100Mbps Auto-MDIX port

• Wi-Fi Protected Setup (WPS) with other WPS compliant devices

• Enable/disable Wireless Distribution System support

• Power, 2.4GHz WLAN, 5GHz WLAN, WPS, Ethernet

• 2.412 ~ 2.484GHz • 5.150~5.250GHz; 5.725~5.825GHz (FCC) • 5.150~5.250MHz (ETSI)

• 2 x 3dBi fixed dipole antennas • 2 x 4dBi internal antennas

• OFDM: BPSK, QPSK, 16-QAM, 64-QAM • DBPSK, DQPSK, CCK

• 802.11a: up to 54Mbps • 802.11b: up to 11Mbps • 802.11g: up to 54Mbps • 802.11n: up to 300Mbps

• 64/128-bit WEP, WPA-PSK(TKIP)/WPA2-PSK(AES), WPA/WPA2-RADIUS Multiple SSID and SSID isolation support

• 802.11a: 13dBm (typical) • 802.11b: 16dBm (typical) • 802.11g: 13dBm (typical) • 802.11n: 13dBm (typical)

• 802.11a: -70dBm (typical) • 802.11b: -87dBm (typical) • 802.11g: -70dBm (typical) • 802.11n: -64dBm (typical)

• 2.4GHz : 1~11 (FCC), 1~13 (ETSI) • 5GHz : following local regulations

• Storage: -10°~ 70°C (14°F~158°F)

• 12V DC, 1A external power adapter

• 170 x 111 x 26mm (6.7 x 4.4 x 1in.)

Hardware

Wireless

SPECIFICATIONS

Temperature

Receiving Sensitivity

• Max. 85% (non-condensing)

Humidity

Channels

Certifications

Power Consumption

Data Rate

Power Adapter

Modulation

Dimension (L x W x H)

Security

Weight

Output Power

• CE, FCC

• 450mA (max)

• Operation: 0°~ 45°C (32°F~ 113°F)

• 230g (8oz)

• Multi-Language Quick Installation Guide

CONTACT INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTSNETWORKING SOLUTION

• TEW-670AP

• CD-ROM (User’s Guide)

• Cat. 5 Ethernet cable (1m / 3.2ft)

• Power adapter (12V, 1A)

TEW-649UB

TEW-664UB

Mini Wireless N Speed USB Adapter

300Mbps Dual Band Wireless N USB Adapter

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

1-888-326-6061

www.trendnet.com

TEW-671BR 300Mbps Concurrent Dual Band Wireless N Router

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TEW-670AP(V1.0R)

300Mbps Concurrent Dual Band Wireless N Access Point

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network

traffic, building materials and other conditions.

300Mbps Concurrent Dual Band

Wireless N Access Point

(TEW-670AP)

Laptop with Mini Wireless

N Speed USB Adapter

(TEW-649UB)

Modem

300Mbps Concurrent

Dual Band Wireless N Router

(TEW-671BR)

Workstation with 300Mbps

Dual Band Wireless N USB Adapter

(TEW-664UB)

2.4GHz Wireless n 5GHz Wireless n

Internet
