TEW-310APB
2.4 GHz Wireless Access Point + Bridge
User's Guide
Rev. 050302
CONTENTS
1.Package Contents
2.Introduction
3.Wireless Basics
4.Getting Started
5.Using the Configuration Utility
6.Troubleshooting
7.Networking Basics
8.Technical Specifications
9. Contacting Technical Support
3
4
7
10
12
20
25
44
46
1. Package Contents
TEW-310APB Enhanced 2.4GHz Wireless Access Point
Power Supply 5V DC, 2.0A
Manual on CD
Quick Installation Guide
Ethernet Cable
Note: Using a power supply with a different voltage rating than the one
included with the TEW-310APB will cause damage and void the warranty for
this product.
If any of the above items are missing, please contact your reseller.
Computer with Windows, Macintosh, or Linux-based operating system
with an installed Ethernet adapter
Internet Explorer or Netscape Navigator version 4.0 or above, with
JavaScript enabled
System Requirements
Contents
3
Fig. 1.1
2. Introduction
TEW-310APB Wireless Access Point is an enhanced 802.11b high-
performance, wireless access point. It is an ideal way to extend the reach and
number of computers connected to your wireless network.
Unlike most 802.11b access points, the TEW-310APB is capable of data
transfer speeds up to 22 Mbps (compared to the standard 11 Mbps) when used
with other TRENDnet products such as the TEW-301PC PCMCIA CardBus
Adapter and TEW-303PI Wireless PCIAdapter.
After completing the steps outlined in the Quick Installation Guide
(included in your package) you will have the ability to share information and
resources, such as files and printers, and enjoy the freedom that wireless
networking delivers.
The TEW-310APB is compatible with most popular operating systems,
including Macintosh, Linux and Windows, and can be integrated into a large
network. This Manual is designed to help you connect the Access Point and the
TRENDnet 2.4GHz Wireless Adapters into a network in Infrastructure mode.
Please take a look at the Getting Started section in this manual to see an
example of an Infrastructure network using the TEW-310APB.
This manual provides a quick introduction to wireless technology and its
application as it relates to networking. Please take a moment to read through
this manual and get acquainted with wireless technology.
Connections
Reset Button: Press
this button to reset all
configurations back to
factory result settings.
Ethernet Port (RJ-45):
Supports 10/100Mbps. Use
Ethernet cable to connect
this port to another ethernet.
Power Adapter Receptor
Diversity Antenna
4
Fig. 2.1
Up to 2X Faster than regular 802.11b Products - high-speed wireless
data transfer rates up to 22Mbps. With twice the data rate and capacity,
the TEW-310APB delivers media rich content such as digital images,
videos, and MP3 files much faster than standard 802.11b networks
Fully 802.11b Compatible Fully compatible with the IEEE 802.11b
standard and interoperable with all existing 802.11b compliant devices
Improved Performance Up to 20% faster data transfer rates on standard
802.11b networks
Stronger Network Security with 256-bit WEP Encryption Supports
64/128/256-bit WEP encryption for higher level of security for your data
and wireless communication than encryption found in existing 802.11b
products
Built-in DHCP Server If enabled, it will automatically assign IP addresses
to wireless clients in a temporary network.
Web-based interface for Managing and Configuring Easy-to-use
interface independent of the operating system
4 Different Operation Modes Capable of operating in one of four different
operation modes to meet your wireless networking requirements: Access
Point, AP-to-AP Bridging, AP-to-Multipoint Bridging, and Wireless Client.
Features and Benefits
5
LED Indicators
LED stands for Light-Emitting-Diode. The TEW-310APB has three LEDs:
Power - Solid red light indicates receiving power
TX/RX (Wireless Network) - Solid green light indicates
wireless connection enabled, blinking green indicates
wireless network activity
Link (Ethernet Port) - Solid green light indicates good
Ethernet connection on the RJ-45 port, blinking green
indicates Ethernet port activity
Power
TX/RX
Link
6
Fig. 2.2
3. Wireless Basics
TRENDware wireless products are based on industry standards to provide
easy-to-use and compatible high-speed wireless connectivity within your home,
business or wherever a wireless network is available. Strictly adhering to the IEEE
standard, the TRENDware wireless family of products will allow you to access the
data you want, when and where you want it. No longer will you be limited to one
location or forced to run new wiring through your home or office. You will be able to
enjoy the freedom that wireless networking delivers.
A wireless local area network (WLAN) is a cellular computer network that
transmits and receives data with radio signals instead of wires. Wireless LANs are
used increasingly in both home and office environments, and public areas such as
airports, coffee shops and universities. Innovative ways to utilize WLAN technology
are helping people to work and communicate more efficiently. Increased mobility
with the absence of cabling and other fixed infrastructure have proven to be
beneficial for many users.
Wireless users can use the same applications they use on a wired network.
Wireless adapter cards used on laptop and desktop systems, support the same
protocols as Ethernet adapter cards. For most users, there is no noticeable
functional difference between a wired Ethernet desktop computer and a wireless
computer equipped with a wireless adapter other than the added benefit of the ability
to roam within a wireless-cell. Under many circumstances, it may be desirable for
mobile network devices to link to a conventional Ethernet LAN in order to use
servers, printers or an Internet connection supplied through the wired LAN. A
Wireless Access Point (AP) is a device used to provide this link.
People use wireless LAN technology for many different purposes.
Mobility - Productivity increases when people have access to data in any
location within the operating range of the WLAN. Management decisions based
on real-time information can significantly improve worker efficiency.
Low Implementation Costs WLANs (Wireless Local Area Networks) are easy
to set up, manage, change and relocate. Networks that frequently change, both
physically and logically, can benefit from WLANs ease of implementation.
WLANs can operate in locations where installation of wiring may be impractical.
Installation Speed and Simplicity - Installing a wireless LAN system can be
fast and easy and can eliminate the need to install cable through walls and
ceilings.
7
Network Expansion - Wireless technology allows the network to go where
wires cannot go.
Reduced Cost-of-Ownership - While the initial investment required for
Wireless LAN hardware might be higher than the cost of wired LAN
hardware, overall installation expenses and life-cycle costs will be
significantly lower. Long-term cost benefits are greatest in dynamic
environments requiring frequent moves, adds, and changes.
Scalability - Wireless Local Area Networks (WLANs) can be configured in a
variety of topologies to meet the needs of specific applications and
installations. Configurations are easily changed and range from peer-to-peer
networks suitable for a small number of users to full infrastructure networks
of thousands of users that allow roaming over a broad area.
TRENDware Wireless Family of LAN products include:
2.4GHz Wireless LAN PCI Network Adapter (TEW-301PC)
2.4GHz Witrless LAN CompactFlash Network Adapter (TEW-302CF)
2.4GHz Wireless LAN PCI Adapter (TEW-303PI)
2.4GHz Wireless LAN USB Network Adapter (TEW-304UB)
Wireless Access Point + Wireless Bridge (TEW-310APB)
Wireless Internet Router/Access Point (TEW-311BRP)
Standards - Based Technology
The IEEE802.11b standard-based technology assures that the TRENDware
Products are interoperable with existing compatible 2.4GHz wireless
technology. This means you will be able to transfer large files quickly or even
watch a movie in MPEG format over your network without noticeable delays. The
technology works by using multiple frequencies in the 2.4GHz range at speeds
up to 22Mbps. TRENDware products will automatically sense the best possible
connection speed to ensure the greatest speed and range possible with the
technology.
Installation Considerations
Designed to go up to 1,312 feet (400 meters) outdoors and up to 328 feet (100
meters) indoors, the TRENDware TEW-310APB lets you access your network
with your laptop computer from virtually anywhere. Keep in mind,
However,that the number, thickness, and location of walls, ceilings or other
8
objects that the wireless signal must pass thru may limit range. Typical ranges
vary depending on the types of materials and any background RF (radio
frequency) noise in your home or business. The key to maximizing range is to
follow these basic guidelines:
1. Keep the number of walls and ceilings between the wireless Access
Point and your receiving device to a minimum - Each wall or ceiling can
reduce your TRENDnet Wireless product's range from 3-90 feet (1-30
meters.) Position your Access Points, Internet Routers, and computers
so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between Access Points, Internet Routers, and
computers. Awall that is 1.5 feet thick (.5 meters), at a 45-degree angle
appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks
over 42 feet (14 meters) thick! Try to make sure that the Access Points
and Adapters are positioned so that the signal will travel straight through
a wall or ceiling for better reception.
3. Building Materials make a difference - A solid metal door or aluminum
studs may have a negative effect on range. Try to position Access
Points, and computers with wireless adapters so that the signal passes
through drywall or open doorways and not other materials.
4. Make sure that the device's antenna is positioned for best reception by
using the software signal strength tools included with your product.
5. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical
devices or appliances that may generate extreme RF noise.
For the average home, signal range should not be an issue. If you experience
low or no signal strength in areas of your home that you wish to access, consider
positioning the Access Point in a location directly between the computers with
wireless adapters. Additional Access Points can be connected to provide better
coverage in rooms where the signal does not appear as strong as desired.
Using radio frequency (RF) technology, WLANs (Wireless LocalArea Networks)
transmit and receive data over the air, minimizing the need for wired
connections. Thus, WLANs combine data connectivity with user mobility, and,
through simplified configuration, enable movable LANs.
9
4. Getting Started
For the price of a single IP Address from your Broadband Internet Service
provider you can share the Internet with all the computers on your local network,
without sacrificing speed or security, using TRENDware networking products.
An Infrastructure network contains an Access Point. The Infrastructure
Network example shown on the below contains the following TRENDnet
network devices:
WirelessAccessPoint (TEW-310APB) (DHCPenabledat default)
Ethernet Broadband Router (TW100-S4W1CA) (DHCPenabledat default)
Notebook computer with a wireless adapter (TEW-301PC)
Desktop computer with a wireless adapter (TEW-303PI)
Cable modem or DSL Modem
DHCP stands for Dynamic Host Configuration Protocol. It is a protocol
for assigning dynamic IP addresses “automatically”.With a DHCP-
capable gateway/router, there is no need to manually assign an IP
address to each computer in the network.
Right out of the box, with its default settings, the TEW-310APB will
automatically connect with other TRENDnet products.
Please note: If you have a DHCP-capable router, please configure
the TEW-310APB to disable its DHCP Server and enable its DHCP
Client
If you need to assign IP Addresses to the computers on the network,
please remember that the IP Address for each computer must be in
the same IP Address range as all the computers in the network, and
the Subnet mask must be exactly the same for all the computers in the
network.
For example: If the first computer is assigned an IP Address of
192.168.0.2 with a Subnet Mask of 255.255.255.0, then the second
computer can be assigned an IP Address of 192.168.0.3 with a Subnet
Mask of 255.255.255.0, etc.
IMPORTANT: If computers or other devices are assigned the same IP
Address, one or more of the devices may not be visible on the network.
IP ADDRESS
10
Autres manuels pour TEW-310APB
4
Table des matières
Autres manuels TRENDnet Point d'accès sans fil
TRENDnet
TRENDnet TEW-230APB Manuel utilisateur
TRENDnet
TRENDnet TEW-453APB - 108Mbps Wireless Super G HotSpot Access... Manuel utilisateur
TRENDnet
TRENDnet TEW-310APBX Manuel utilisateur
TRENDnet
TRENDnet TEW-410APBplus Manuel utilisateur
TRENDnet
TRENDnet TEW-814DAP Manuel utilisateur
TRENDnet
TRENDnet TEW-735AP Manuel utilisateur
TRENDnet
TRENDnet TPL-210AP Manuel utilisateur
TRENDnet
TRENDnet TEW-636APB Manuel utilisateur
TRENDnet
TRENDnet TPL-110AP - 125Mbps 802.11g Wireless Powerline Access... Manuel utilisateur
TRENDnet
TRENDnet TEW-740APBO Manuel utilisateur
TRENDnet
TRENDnet TEW-825DAP(V1) Manuel utilisateur
TRENDnet
TRENDnet TEW-740APBO2K Manuel utilisateur
TRENDnet
TRENDnet TEW-821DAP Manuel utilisateur
TRENDnet
TRENDnet TEW-637AP - 300Mbps Wireless Easy-N-Upgrader Manuel utilisateur
TRENDnet
TRENDnet TEW-753DAP Manuel utilisateur
TRENDnet
TRENDnet TEW-AP100plus Manuel utilisateur
TRENDnet
TRENDnet TPL-410AP Manuel utilisateur
TRENDnet
TRENDnet TEW-410APBplus Manuel utilisateur
TRENDnet
TRENDnet TEW1750ACV2 Manuel utilisateur
TRENDnet
TRENDnet TEW-510APB Manuel utilisateur
Manuels Point d'accès sans fil populaires d'autres marques
D-Link
D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur
Ubiquiti
Ubiquiti NanoStation NSM2 Manuel utilisateur
Cisco
Cisco Aironet 1550 Series Manuel utilisateur
Aruba
Aruba IAP-335 Manuel utilisateur
Advantek Networks
Advantek Networks AWN-AP-54MR Manuel utilisateur
IP-COM
IP-COM AP355 Manuel utilisateur
