TRENDnet TEG-S80TXE - Copper Gigabit Switch Manuel utilisateur

TEG-S80TXE Gigabit Ethernet Switch consists of eight

10/100/1000Mbps Gigabit Ethernet ports with Auto-negotiation

and Auto-MDIX features. Users can connect Server(s) to the

Gigabit port(s) to increase network performance or cascade

Copper Gigabit Switches together to create high-bandwidth

Gigabit backbones. The TEG-S80TXE provides simple migration,

scalability and flexibility to handle new applications and data

types, making it a highly reliable and cost effective solution for

high-speed network connectivity.

TEG-S80TXE(c1)

8-Port 10/100/1000Mbps Gigabit Switch

TEG-S80TXE

rev:08.24.2006

• 8 x 10/100/1000Mbps Auto-Negotiation, Auto-MDIX Gigabit Ethernet Ports

• Full/Half-duplex transfer mode for 10/100Mbps, Full-Duplex mode for 1000Mbps

• Store-and-Forward switching method

• Wire-speed reception and transmission

• IEEE 802.3x flow control for full-duplex mode

• Back pressure flow control for half-duplex mode

• Integrated address Look-Up engine, supports 4K MAC addresses

• Operates and maximizes packet filtering and forwarding rate

Provides 144kbyte RAM data buffering

Sturdy metal housing

Diagnostic LEDs

Plug & Play

5-Year Warranty

•

FEATURES

Diagnostic LEDs

Network Media

Data Rate

Protocol

Topology

Interface

Power Consumption

Power Supply

Dimensions (WxDxH)

Temperature

Certifications

Weight

Humidity

• IEEE 802.3 10Base-T

• 8K entries per device

• IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T

• Power, Link/ACT, 100Mbps, 1000Mbps

• 450 g (15.2 oz)

• Operating: 10 % ~ 90 %

• Storage: 5% ~ 90% (non-condensing)

• thernet: 2-pair UTP Cat. 3,4,5, up to 100m

• Gigabit Ethernet: 4-pair UTP Cat. 5, 5e,6, up to 100m

• Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)

• Gigabit Ethernet: 2000Mbps (Full-Duplex)

• 7.5 Watts (max)

• 7.5V DC, 1.5A External Power Adapter

• CSMA/CD

• Star

• 8 10/100/1000Mbps Auto-MDIX RJ-45 Ports

• 144KB per Device

• 171 x 98 x 28mm (6.73 x 3.86 x 1.1 inch)

• Operating: 0° ~ 40° C (32° ~ 104° F)

• FCC,CE

Data RAM Buffers

Filtering Address Table

Standards

Hardware

• Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)

• Fast Ethernet: 2-pair UTP Cat. 5, up to 100m

• Storage: -10° ~ 70° C (14° ~ 158° F)

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

8-Port 10/100/1000Mbps Copper Gigabit Switch

TEG-S80TXE(c1)

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-310-891-1100

Fax: 1-310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONS

SPECIFICATIONS

Server with 10/100/1000Mbps

Gigabit PCI Adapter

(TEG-PCITXR)

10/100Mbps Multi-Port

Print Server

(TE100-P21)

1000Mbps

Advanced Pan & Tilt

Internet Camera Server

(TV-IP400)

Workstation with

10/100Mbps PCI Adapter

(TE100-PCIWN)

Notebook with

10/100/1000Mbps

Gigabit PC Card

(TEG-PCBUSR)

Printer

8-Port 10/100/1000Mbps

Gigabit Switch

(TEG-S80TXE)

RELATED PRODUCTS

TEG-PCITXR

TEG-PCBUSR

TEG-S50TXE 5-Port 10/100/1000Mbps Copper Gigabit Switch

32-bit 10/100/1000Mbps Copper Gigabit PCI Adapter

32-bit Gigabit CardBus PC Card

• Multi-Language QIG

• TEG-S80TXE

PACKAGE CONTENTS
