TRENDnet 21000BASE-T Manuel utilisateur

28-Port 10/100/1000Mbps

Gigabit Ethernet

Web Smart Switch

with

2×1000BASE-T, 24×10/100BASE-TX ports

2 optional mini-GBIC ports

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with this user’s guide, may cause harmful interference to

radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case the user will

be required to correct the interference at his or her own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product

may cause radio interference, in which case the user may be required

to take adequate measures.

VCCI Warning

This is a product of VCCI Class A Compliance.

UL Warning

a) Elevated Operating Ambient Temperature- If installed in a closed

or multi-unit rack assembly, the operating ambient temperature of the

rack environment may be greater than room ambient. Therefore,

consideration should be given to installing the equipment in an

environment compatible with the manufacturer's maximum rated

ambient temperature (Tmra).

b) Reduced Air Flow- Installation of the equipment in a rack should

be such that the amount of air flow required for safe operation of the

equipment is not compromised.

c) Mechanical Loading- mounting of the equipment in the rack

should be such that a hazardous condition is not achieved due to

uneven mechanical loading.

d) Circuit Overloading- Consideration should be given to the

connection of the equipment to the supply circuit and the effect that

overloading of circuits might have on over current protection and

supply wiring. Appropriate consideration of equipment nameplate

ratings should be used when addressing this concern.

e) Reliable Earthing- Reliable earthing of rack-mounted equipment

should be maintained. Particular attention should be given to supply

connections other than direct connections to the branch circuit (e.g.,

use of power strips).

Ver. 1.00

TABLE OF CONTENT

About This Guide.................................................................................1

Purpose ............................................................................................1

Terms/Usage....................................................................................1

Introduction..........................................................................................3

Gigabit Ethernet Technology...........................................................3

Fast Ethernet Technology ................................................................4

Switching Technology .....................................................................5

VLAN (Virtual Local Area Network)..............................................6

Features............................................................................................6

Unpacking and Installation ..................................................................9

Unpacking........................................................................................9

Installation .......................................................................................9

Rack Mounting ..............................................................................10

Connecting Network Cable............................................................11

AC Power.......................................................................................11

Identifying External Components......................................................13

Front Panel.....................................................................................13

Rear Panel......................................................................................14

Understanding LED Indicators ..........................................................15

Power and System LEDs ...............................................................15

Ports 1~24 10/100M Status LEDs..................................................16

Ports 25~26 Gigabit Status LEDs..................................................16

Ports 27~28 mini-GBIC Status LEDs............................................17

Configuration.....................................................................................19

Installing the Web Management Utility.........................................19

Discovery List................................................................................20

Monitor List...................................................................................21

Device Setting................................................................................23

Toolbar...........................................................................................24

Configuring the Switch..................................................................25

Setup Menu....................................................................................28

Configuring Setup Setting..............................................................28

Port Settings...............................................................................28

VLAN Settings (Virtual Local Area Network)..........................30

Trunk Setting .............................................................................31

Mirror Setting.............................................................................31

Device Status .............................................................................32

Statistic.......................................................................................32

System Setting ...........................................................................34

Trap Setting................................................................................34

Set Password..............................................................................35

Backup Setting...........................................................................36

Reset Setting ..............................................................................37

Logout............................................................................................37

Technical Specifications....................................................................39

ABOUT THIS GUIDE

Congratulations on your purchase of the 24+4G-Port

10/100/1000Mbps Gigabit Ethernet Web Smart Switch. This device

integrates 1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and

10Mbps Ethernet network capabilities in a highly flexible package.

Purpose

This guide discusses how to install your 24+4G-Port

10/100/1000Mbps Gigabit Ethernet Web Smart Switch.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to your

24+4G-Port 10/100/1000Mbps Gigabit Ethernet Web Smart Switch,

and “switch” (first letter lower case) refers to other Ethernet switches.

INTRODUCTION

This chapter describes the features of the 24+4G-Port

10/100/1000Mbps Gigabit Ethernet Web Smart Switch and some

background information about Ethernet/Fast Ethernet/Gigabit Ethernet

switching technology.

Gigabit Ethernet Technology

Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the

same packet structure, format, and support for CSMA/CD protocol,

full duplex, flow control, and management objects, but with a tenfold

increase in theoretical throughput over 100-Mbps Fast Ethernet and a

hundredfold increase over 10-Mbps Ethernet. Since it is compatible

with all 10-Mbps and 100-Mbps Ethernet environments, Gigabit

Ethernet provides a straightforward upgrade without wasting a

company’s existing investment in hardware, software, and trained

personnel.

The increased speed and extra bandwidth offered by Gigabit Ethernet

is essential to coping with the network bottlenecks that frequently

develop as computers and their busses get faster and more users use

applications that generate more traffic. Upgrading key components,

such as your backbone and servers to Gigabit Ethernet can greatly

improve network response times as well as significantly speed up the

traffic between your subnets.

Gigabit Ethernet enables fast optical fiber connections to support

video conferencing, complex imaging, and similar data-intensive

applications. Likewise, since data transfers occur 10 times faster than

Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to

perform 10 times the number of operations in the same amount of time.

In addition, the phenomenal bandwidth delivered by Gigabit Ethernet

is the most cost-effective method to take advantage of today and

tomorrow’s rapidly improving switching and routing internetworking

technologies. And with expected advances in the coming years in

silicon technology and digital signal processing that will enable

Gigabit Ethernet to eventually operate over unshielded twisted-pair

(UTP) cabling, outfitting your network with a powerful 1000-Mbps-

capable backbone/server connection creates a flexible foundation for

the next generation of network technology products.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of

desktop computing applications are fueling the need for high

performance networks. A number of high-speed LAN technologies

have been proposed to provide greater bandwidth and improve

client/server response times. Among them, 100BASE-T (Fast

Ethernet) provides a non-disruptive, smooth evolution from the

current 10BASE-T technology. The non-disruptive and smooth

evolution nature, and the dominating potential market base, virtually

guarantees cost-effective and high performance Fast Ethernet

solutions.

100Mbps Fast Ethernet is a standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps Ethernet standard

with the ability to transmit and receive data at 100Mbps, while

maintaining the CSMA/CD Ethernet protocol. Since the 100Mbps

Fast Ethernet is compatible with all other 10Mbps Ethernet

environments, it provides a straightforward upgrade and takes

advantage of the existing investment in hardware, software, and

personnel training.
