TRENDnet TEG-224WS - DATA SHEETS Manuel utilisateur

TRENDnet's TEG-224WS 26-port 10/100/1000Mbps Web-Based

Smart Switch is the ideal Switch for network segmenting and

flexibility. It has 24 10/100Mbps and 2 10/100/1000Mbps Auto-

Sensing and Auto-MDIX ports. TEG-224WS supports web

browser configuration allowing Network Administrators to

configure speed, VLAN, QoS, Trunking and Mirroring down to the

port level. TRENDnet's TEG-224WS is powerful, easy-to-use and

enhances network security.

TEG-224WS

26-port 10/100/1000Mbps Gigabit

Web-Based Smart Switch

TEG-224WS

rev:02.17.2006

• 24 x 10/100Mbps Auto-negotiation MDIX Fast Ethernet Ports

• 2 x 10/100/1000Mbps Auto-negotiation, Auto-MDIX Gigabit Ports

• Full/Half duplex mode for each port (Full Duplex Mode only for Gigabit Ports)

• Store and Forward switching method

• Integrated address Look-Up Engine with 6K absolute MAC address table

• Supports 4Mbits RAM Data Buffering

• Extensive diagnostic LED's on the front panel

• IEEE 802.3x flow control for full-duplex mode

• Back pressure flow control for half-duplex mode

• Easy configuration the device from a Web browser

• Supports Port-Based VLAN and Port-Based IEEE 802.1p QoS

• Supports Trunking (gigabit ports) and Port Mirroring

• Support Port setting function allow user setting each port's speed, duplex mode, and flow control

• Standard 19” Rack-mount design

• 5-Years Warranty

FEATURES

BENEFITS

Easy Upgrade:

Ethernet workgroups are able to upgrade to Fast Ethernet by changing adapters and a hub without changing

switches.

Flexibility:

Easy management and configuration through Web browser

Performance:

Provides non-blocking high performance with internal switch controller.

Cost-Effectiveness:

The TEG-224WS presents Gigabit Ethernet at an affordable rate.

Network Media

Operating Temperature

Protocol

Topology

LAN Port

Address Table

Data RAM buffer

Power Consumption

Power Supply

Weight

Certifications

Humidity

Dimensions

Storage Temperature

• IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3x Full Duplex Flow Control

• Per Unit: Power, System

• Ethernet: UTP/STP Cat. 3, 4, 5, Fast Ethernet: UTP/STP Cat. 5 , Gigabit : UTP/STP Cat. 5, Cat 5E (Recommend)

• Per Fast Ethernet Port: Link/ACT, 100M (port 1~24)

• Per Gigabit Ethernet Port: Link/ACT, 1000M, 100M (port 25,26)

• 440 x 140 x 44 mm (17.32" x 5.5" x 1.73")

• -10° C~ 70° C (14° F~ 158° F)

• CSMA/CD

• Star

• 24 x 10/100Mbps Auto Negotiation, Auto-MDIX Fast Ethernet ports,

• 2 x 10/100/1000Mbps Auto Negotiation, Auto MDIX Gigabit ports

• 16 Watts. Max

• 6K entries per device

• 4Mbits per device

• Ethernet: 10/20Mbps – Half/Full-Duplex

• 4.7 lb

• 100-240V AC, 50/60Hz Internal Universal Power Supply

• 0° C~ 40° C (32° F~ 104° F)

• FCC Class A, CE Mark A, VCCI-A

• 10% ~ 90% (no-condensing)

Data Transfer Rate

Diagnostic LEDs

LAN Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

26-port 10/100/1000Mbps Gigabit Web-Based Smart Switch

TEG-224WS

RELATED PRODUCTS

TEG-S18TXE

TEG-S80TXD

TEG-224WS 26-Port 10/100/1000Mbps Gigabit Web-Based Smart

Switch(Rack Mount)

9-Port (8 10/100, 1 10/100/1000) Copper Gigabit Mini

Switch

8-Port Copper Gigabit Switch

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONS

SPECIFICATIONS

• Fast Ethernet: 100/200Mbps – Half/Full Duplex

• Gigabit Ethernet: 2000Mbps – Full Duplex
