TRENDnet TE100-S16Eplus Manuel utilisateur

TRENDnet's TE100-S16E high performance auto-sensing

NWay switch is designed specifically to boost your network

performance by eliminating network congestions and

unnecessary network traffics. Each of the 16 ports on the

Switch, not only provides dedicated bandwidth, but also

negotiates between 10Mbps and 100Mbps network speeds.

With it's compact size, the TE100-S16E can be installed

anywhere in the network and is the ideal solution for today's

bandwidth-hungry network.

TE100-S16E

16-port 10/100Mbps NWay Fast Ethernet Compact Switch

BENEFITSFEATURES

Easy Upgrade:

Expandability:

Flexibility:

Performance:

Ethernet workgroups are able to

upgrade to Fast Ethernet by changing

adapters and hubs without changing

switches.

Simple expansion can be done by

unlinking two or more switches with all

ports supporting 200Mbps in full-

duplex mode.

The NWay ports automatically

negotiate between 10Base-T and

100Base-TX network speeds as well

as between half- and full-duplex

modes.

Dedicated bandwidth on each port

providing top performance at an

affordable price.

Compliant with IEEE 802.3 10Base-T, IEEE 802.3µ 100Base-TX

standard

16 UTP/STP RJ-45 10/100Mbps NWay auto-sensing ports

Store and forward packet switching

Half- and full-duplex operation for each port

802.3 flow control for full duplex connection and back pressure

flow control for half-duplex connection.

Auto-learning of network configuration

Built-in 8K entries per device for Filtering Address Table

512KB per device RAM buffer.

MDI-II uplink port (shared with port 1) for easy expansion

Broadcast Storm Protection

5-Year Warranty

TE100-S16E (03-08-2005)

TRENDnet

TRENDware, USA

What's Next in Networking

RELATED PRODUCT

To Order Please Call:

1-888-326-6061

TE100-S16E: 16-port 10/100Mbps NWay Fast Ethernet

Compact Switch

TE100-S16: 16-port 10/100Mbps NWay Switch

TE100-S2424: 24-port 10/100Mbps NWay Switch (Rack Mount)

TE100-SFXM: SC-Type Fiber Slide-in Module for TE100-

S1616/S2424/S16

TE100-S1616V: 16-port 10/100Mbps NWay VLAN Switch

TE100-S2424V: 24-port 10/100Mbps NWay VLAN Switch

TE100-SVFXM: SC-Type Fiber Slide-in Module for TE100-

S1616V/S2424V

NETWORKING SOLUTIONS

SPECIFICATIONS

Standards:

• IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, ANSI / IEEE

802.3 NWay auto-negotiation

Data Transfer Rate:

• 10/100Mbps (20/200Mbps in full-duplex mode)

Protocol:

• CSMA/CD

Connectors:

• 16 UTP/STP RJ-45

Network Cables:

• 10BASE T: 2-pair UTP Cat. 3,4,5; EIA/TIA- 568 100-ohm STP

• 100BASE-TX: 2-pair UTP Cat. 5; EIA/TIA-568 100-ohm STP

Diagnostic LED's:

• Power, 10 Link/Act, 100Link/Act, FDX, COL

Power:

• External AC Adapter DC 5V, 5A, 25 Watts Max.

Dimensions:

• 184x 124 x 44 mm / 7.2" x 4.9" x 1.7" (L x W x H)

Weight:

• 848g (1.87lbs)

Temperature:

• Operating.: -10° to 50° C (14° to 122° F)

• Storage: -10° to 70° C (14° to 158° F)

Humidity:

• Operating: 10 to 90% (non-condensing)

• Storage: 5 to 90% (non-condensing)

Certifications:

• FCC, CE, VCCI

TE100-S16E

16-port 10/100Mbps NWay Fast Ethernet Compact Switch

TE100-S16E

16-port 10/100Mbps NWay Fast Ethernet Compact Switch

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
