TRENDnet TK-205K - PS/2 KVM Switch Manuel utilisateur

TK-205K

Quick Installation Guide

Table of Contents

Version 02.08.2006

Deutsch .....................................................................................................

Specifications ............................................................................................

Troubleshooting .........................................................................................

1. Bevor Sie anfangen ...........................................................................

2. Installation .........................................................................................

3. Bedienung .........................................................................................

1. Bevor Sie anfangen

Deutsch

Anwendung

Systemanforderungen

PS/2-Tastatur

PS/2-Maus

VGA-kompatibler Monitor

Windows XP/2000/ME/98SE, Unix und Linux

TK-205

KVM-Kabel (zwei)

Anleitung zur Schnellinstallation

Packungsinhalt

PC 1 PC 2

LCD Monitor

2-Port PS/2

KVM Switch

(TK-205K)

PS/2 Keyboard PS/2 Mouse

Cable Cable

Deutsch

2. Installation

Hinweis: Der PS/2-KVM-Umschalter TK-205 benötigt weder spezielleTreiber

noch eine eigene Software.

1. Schalten Sie alle Computer und

Peripheriegeräte aus und trennen

Sie alle Stromversorgungskabel

ab.

3. Verbinden Sie die Computer über

die KVM-Kabel mit dem KVM-

Umschalter.

4. Schalten Sie die miteinander

verbundenen Computer

nacheinander ein und warten Sie,

bis die Computer vollständig

hochgefahren sind.

2. Verbinden Sie die gemeinsam

genutzte Tastatur, den Monitor und

die Maus mit dem Konsolen-Port

des KVM-Umschalters.

Ihre Installation ist beendet!

Deutsch

Hinweis: Um von einem Computer zum anderen zu wechseln, können Sie die

Drucktasten auf dem Gerät oder Tastenkombinationen verwenden.

3.1 Drucktasten

3.1 The Push Buttons

Drücken Sie auf die entsprechende

Taste, um den gewünschten PC

auszuwählen.

3. Bedienung

3.2 Tastenkombinationen

Eine Tastenkombination setzt sich aus drei Tasten zusammen:

Tastenkombination = ScrLk (ROLLEN) + ScrLk (ROLLEN) +

Befehlstaste(n)

Sobald Sie die ScrLk-Taste (ROLLEN-Taste) gedrückt haben, müssen Sie die

Taste innerhalb von 2 Sekunden nochmals drücken. Innerhalb der nächsten 2

Sekunden müssen Sie dann eine Befehlstaste drücken. Wenn Sie innerhalb

von 2 Sekunden keine Taste drücken, wird die Tastenkombination nicht

wirksam.

Deutsch

Befehl Tastenkombination Beschreibung

Schnellübersicht für den TK-205

PC auswählen

Unmittelbar darunter

liegender PC-Kanal

Unmittelbar darüber

liegender PC-Kanal

Autoscan

Autoscan beenden

ScrLk ScrLk X

+ +

(x ist eine Zifferntaste. x = 1 oder 2,

entsprechend der Kanalnummer des PC)

ScrLk ScrLk

+ + (Pfeil nach

oben)

ScrLk ScrLk

+ + (Pfeil nach

unten)

ScrLk ScrLk

+ + S

Press any key on keyboard

Wählt den aktiven PC-Kanal aus.

Wählt den unmittelbar darunter

liegenden Kanal eines verbundenen

PC aus.

Wählt den unmittelbar darüber

liegenden Kanal eines verbundenen

PC aus.

Fragt für die schnelle Durchsicht der

Bildschirmanzeigen automatisch alle

Kanäle ab.

Beendet die automatische Abfrage.

ScrLk ScrLk

+ + (key)

Die Darstellung der Tastenkombination

bedeutet, dass Sie die einzelnen tasten nicht gleichzeitig, sondern

hintereinander drücken sollen.

Vereinbarung zu Tastenkombinationen:

Computer Connections 2

Cable Interface (all male)

KVM Cable 2 Sets of 1.2M (4ft) KVM Cables

Console Connectors

(all female)

Mouse: PS/2 6-pin Mini Din

Keyboard: PS/2 6-pin Mini Din

Monitor: VGA/SVGAHDB 15-pin

To Console:

1 x VGA/SVGAHDB 15-pin

To PC:

1 x PS/2 Mouse 6-pin Mini Din

1 x PS/2 Keyboard 6-pin Mini Din

1 x VGA/SVGAHDB 15-pin

Port Selection Push Button or Hot-Key Commands

Auto-Scan Interval 10 seconds

Keyboard State Saved and restored

Power Supply Bus-Powered

Dimensions 95 x 65 x 30 mm (3.7 x 2.6 x 1.2 in.)

Weight 85g (3oz)

0º ~ 40ºC (32º ~104º F)Operating Temperature

-20º ~ 60ºC (-4º ~ 140º F)Storage Temperature

0%~80%, Non-Condensing

Humidity

CE, FCCCertifications

Specifications

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may cause

undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FORANY RADIO OR TV INTERFERENCE

CAUSED BY UNAUTHORIZED MODIFICATIONS TOTHIS EQUIPMENT. SUCH MODIFICATIONS

COULD VOID THE USER’SAUTHORITY TO OPERATE THE EQUIPMENT.

Troubleshooting

Waste electrical and electronic products must not

be disposed of with household waste. Please

recyclewherefacilitiesexist. CheckwithyouLocal

AuthorityorRetailerforrecyclingadvice.

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

Where is the AC adapter? I did not find one in the box.

I have the KVM switch connected properly, but my keyboard and mouse don't

work. Please make sure your PS/2 ports are working properly by testing it with

another mouse or keyboard. Once you confirm that the PS/2 ports are functional,

please reboot your computers, and try to use the KVM switch again.

Can I connect or disconnect the KVM cables while the computers are turned

on? Yes, you can connect or disconnect the KVM cables while the computers are

turned on, because the interface is Hot-Pluggable.

Will the KVM switch remember the keyboard settings between computers?

Yes, the KVM switch will remember the keyboard settings when switching

between your computers. (i.e.: Caps lock, Num key, etc.)

How do I switch from one computer to another with the KVM switch?

Because the TK-205 KVM switch supports Hot-Key commands, you can use

Hot-Key commands to switch between 2 computers.

The TK-205 does not require anAC adapter. It draws power from your

computer's keyboard port.As long as your KVM switch is connected to the

keyboard port, it will receive the necessary power to function.

If you still encounter problems or have any questions regarding the TK-205K, please

contact Trendnet's Technical Support Department.

Limited Warranty

TRENDnet warrants its products against defects in material and

workmanship, under normal use and service, for the following lengths of

time from the date of purchase.

TK-205K - 2 Year Warranty

If a product does not operate as warranted above during the applicable

warranty period, TRENDnet shall, at its option and expense, repair the

defective product or part, deliver to customer an equivalent product or

part to replace the defective item, or refund to customer the purchase

price paid for the defective product. All products that are replaced will

become the property of TRENDnet. Replacement products may be new

or reconditioned.

TRENDnet shall not be responsible for any software, firmware,

information, or memory data of customer contained in, stored on, or

integrated with any products returned to TRENDnet pursuant to any

warranty.

There are no user serviceable parts inside the product. Do not remove

or attempt to service the product by any unauthorized service center.

This warranty is voided if (i) the product has been modified or repaired

by any unauthorized service center, (ii) the product was subject to

accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within

the applicable warranty period for a Return Material Authorization (RMA)

number, accompanied by a copy of the dated proof of the purchase.

Products returned to TRENDnet must be pre-authorized by TRENDnet

with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT

OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE

REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR

REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES

ARE EXCLUSIVE AND ARE IN LIEU OFALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER

PERSON TO ASSUME FOR ITANY OTHER LIABILITY IN

CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR

USE OF TRENDnet'S PRODUCTS.

TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS

TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED

DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE

BEYOND THE RANGE OF THE INTENDED USE, OR BYACCIDENT,

FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENTALLOWED BY LAW

TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY

LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING

NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,

SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT

OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION

OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY

TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE

PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR

DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of

the state of California.

AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 Year

Warranty
