TRENDnet TE100-S1616V Manuel utilisateur

TRENDnet's unique 16-port 10/100Mbps N-way VLAN Switch has

an optional fiber optic and BNC (10Base-2) module that makes this

switch flexible enough for mid-sized companies and branch offices

to meet their high bandwidth requirements. The TE100-S1616V

supports both 10/100Mbps speed and half-/full-duplex modes on

the same port. Additionally, it features programmable

reconfiguration for half-duplex and full-duplex modes. By using

standard auto-negotiation, it provides a cost-effective way of

integrating 10Mbps segments with 100Mbps Fast Ethernet

networks, ideal for extending the distance between two 100Mbps

network segments. Supporting Virtual Local Area Net-working

(VLAN), the TE100-S1616V is powerful and easy-to-use in

reducing unnecessary broadcast traffic, segment the network, and

enhance network security.

TE100-S1616V

16-port 10/100Mbps N-way VLAN Switch

Complies with IEEE 802.3 10Base-T, IEEE 802.3µ

100Base-TX/FX standards

16 10/100Mbps auto-negotiation and auto-sensing ports

Supports four Port-based VLAN

Programmable reconfiguration for half- and full-duplex

modes

Store-and-forward packet switching

Half- and full-duplex operation for all UTP and fiber ports

Supports 1,024 MAC address

Auto-learning of network configuration

Push button uplink port (shared) for easy expansion

Optional fiber module port (multi-mode SC-type) or

10Base-2 BNC module

Plug and Play

Front panel port status LEDs

EIA-19 rack mountable

5 Year Warranty

FEATURES BENEFITS

Easy Upgrade:

Expandability:

Flexibility:

Cost Effective:

Performance:

Ethernet workgroups are able to

upgrade to Fast Ethernet by changing

adapters and a hub without changing

switches.

Expand the connection up to 2km with

optional fiber module or optional BNC

module (10Mbps thin coax cable).

Port-based VLAN reduces broadcast

traffic and enhance network security.

Provides non-blocking high

performance with internal switch

controller.

The TE100-S1616V presents

10/100Mbps of Fast Ethernet at an

affordable rate.

TE100-S1616V (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

NETWORKING SOLUTIONS

TE100-S1616V

16-port 10/100Mbps N-way VLAN Switch

TE100-S1616V

16-port 10/100Mbps N-way VLAN Switch

Standards:

• IEEE 802.3 10Base-T, IEEE 802.3m 100Base-TX/

100Base-FX, ANSI / IEEE 802.3 N-way

auto-negotiation

Forwarding Rate:

• 14,880pps for 10Mbps, 148,800pps for 100Mbps

Switching Method:

• Store-and-forward

Cabling:

• 10Base-T: 2-pair UTP CAT 3, 4, 5 up to 100m (328ft),

• 100Base-TX: 2-pair UTP CAT 5 up to 100m (328ft.),

• 100Base-FX: 62.5/125 multi-mode fiber optic

cable up to 2,000m (6,560ft.)

Diagnostic LEDs:

• Per Unit: Power, Uplink, Module Enable (3 LEDs),

• Per Port: 100Mbps/TX, 10Mbps/RX,

Full-duplex/Collision (3 LEDs)

Power:

• Internal universal power supply

(100-240VAC, 50-60Hz, 25Watts max.)

Dimensions:

• 443 x 203 x 44 mm (17.4 x 8 x 1.7 inches)

Weight:

• 2.68 kg (5.9 lbs.)

Temperature:

• Operating: 0° to 40° C (32° to 104° F)

• Storage: -25° to 70° C (-13° to 158° F)

Humidity:

• 10 % to 90 % non-condensing

Certifications:

• FCC, UL, CE, VCCI Class A

PRODUCT INFORMATION

TE100-S2424V: 24-port 10/100Mbs N-way VLAN

Switch

TE100-S1616V: 16-port 10/100Mbs N-way VLAN

Switch

TE100-SVFXM: SC-type Fiber Slide-in Module for

TE100-S1616V/S2424V

TE100-SVBM: BNC Slide-in Module for TE100-

S1616V/S2424V

TE100-SVF45M: VF-45 Fiber Slide-in Module for

TE100-S1616V/S2424V

TE100-S1616: 16-port 10/100Mbps N-way Switch

TE100-S2424: 24-port 10/100Mbps N-way Switch

TE100-SFXM: SC-type Fiber Slide-in Module for

TE100-S1616/S2424

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
