TE100-S5
TE100-S8
V1
Quick Installation Guide
English 1
1. Before You Start
2. Hardware Installation 2
3. LEDs 3
1
Technical Specifications 4
Troubleshooting 5
Table of Contents
Version 06.30.2010
1. Before You Start
!
!Cat.5 or Cat.5e network cable
!The power outlet should be within 1.82 meters (6 feet) of the switch
!Visually inspect the DC power jack to make sure that it is securely connected to
the power adapter
!Make sure that there is proper heat dissipation and adequate ventilation around
the switch
!Do not place heavy objects on the switch
Computer with a network adapter installed
Package Contents
!
!Multi-Language Quick Installation Guide
!PowerAdapter (5V DC, 800mA)
TE100-S5/TE100-S8
System Requirements
1
2. Hardware Installation
2
1. Connect the PowerAdapter to the
TE100-S5/TE100-S8 and then to a power
outlet.
2. Connect a Cat.5 or Cat.5e RJ-45 network
cable from the computer to an available
Ethernet port on the TE100-S5/TE100-S8.
3
3. LEDs
Power
Green:Powerison
NotIlluminated:Powerisoff
Link/ACT
Green (Solid):
Connection for the port is 100/200(half/full)
or 10/20(half/full)
Green (Blinking):
Activity is occurring
Not Illuminated:
No activity is detected
4
Network Media
Standard
Interface
Diagnostic LED
Power Consumption
PowerAdapter
1.0Gbps Forwarding Capacity
Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)
Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)
Ethernet: Cat. 5 up to 100m
Fast Ethernet: Cat. 5, 5e, 6 up to 100m
IEEE 802.310Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Flow Control
Star
1.6Gbps Forwarding Capacity
100 x 78 x 31mm
(3.9 x 3 x 1.2 inches) 154 x 110 x 33mm
(6 x 4.3 x 1.3 inches)
Power, Link/ACT
5 10/100MbpsAuto-MDIX
RJ-45 ports 8 10/100MbpsAuto-MDIX
RJ-45 ports
384Kbits per device 512Kbits per device
4.5 watts (max)
2.8 watts (max)
128g (4.5oz.) 225g (8oz.)
5V DC 800mAexternal power adapter
Technical Specifications
Data Rates
Switch Fabric
Topology
Filtering Table 2K entries per device
Buffer Memory
Dimension
Weight
Temperature
Humidity
Certification
0° ~ 50° C (32° ~ 122° F)
Max. 90% (non-condensing)
CE, FCC
TE100-S5 TE100-S8
1.After connecting the Switch to a power outlet, the LEDs do not turn on.
1. Check the connection of the power adapter to the TE100-S5/TE100-S8 and the
power outlet.
2. Check that the power outlet is receiving power.
2.After I connect my computers to the Switch, I am unable to share files.
Check the LEDs on the Switch. Make sure the Link/ACT LED is on.
2. Check the network cable. The minimum length of the cable is 1.5 meters and
the maximum length of the cable is 100 meters.
3. Disable any software firewall program.
4. Verify that you have file sharing enabled. Please contact your Operating
System support for more information.
3.After I connect my computers to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple computers. You
need to get an Internet router such as the TW100-S4W1CA.
4. Where is the uplink port located on the Switch?
Since all the ports on the Switch areAuto-MDIX, any of the ports can be used as
an uplink port.
If you still encounter problems or have any questions regarding the
TE100-S5/TE100-S8, please contact TRENDnet'sTechnical Support Department.
1.
Troubleshooting
5
6
Limited Warranty
TE100-S5/TE100-S8 - 3 Years Limited Warranty
AC/DC PowerAdapter, Cooling Fan and Power Supply carry a 1 year limited warranty
TRENDnet warrants its products against defects in material and workmanship, under normal
use and service, for the following lengths of time from the date of purchase.
If a product does not operate as warranted during the applicable warranty period, TRENDnet
shall reserve the right, at its expense, to repair or replace the defective product or part and
deliver an equivalent product or part to the customer. The repair/replacement unit's warranty
continues from the original date of purchase.All products that are replaced become the
property of TRENDnet. Replacement products may be new or reconditioned.TRENDnet
does not issue refunds or credit. Please contact the point-of-purchase for their return policies.
TRENDnet shallnotberesponsibleforanysoftware,firmware,information,ormemorydataof
customer contained in, stored on, or integrated with any products returned to TRENDnet
pursuanttoanywarranty.
Therearenouserserviceablepartsinsidetheproduct. Donotremoveorattempttoservicethe
productbyanyunauthorized servicecenter. Thiswarrantyis voidedif (i)the producthas been
modifiedorrepairedbyanyunauthorizedservicecenter,(ii)theproductwassubjecttoaccident,
abuse, or improper use (iii) the product was subject to conditions more severe than those
specifiedinthemanual.
Warranty service may be obtained by contacting TRENDnet within the applicable warranty
period and providing a copy of the dated proof of the purchase. Upon proper submission of
requireddocumentationa ReturnMaterialAuthorization(RMA) numberwillbeissued.AnRMA
number is required in order to initiate warranty service support for all TRENDnet products.
ProductsthataresenttoTRENDnetforRMAservicemusthavetheRMAnumbermarkedonthe
outsideofreturnpackagesandsenttoTRENDnetprepaid,insuredandpackagedappropriately
forsafeshipment.CustomersshippingfromoutsideoftheUSAandCanadaareresponsiblefor
return shipping fees. Customers shipping from outside of the USAare responsible for custom
charges,includingbutnotlimitedto,duty,tax,andotherfees.
7
WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT TRENDNET'S
OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE
EXCLUSIVEANDARE IN LIEU OFALLOTHER WARRANTIES, EXPRESSED OR IMPLIED,
EITHERINFACTORBYOPERATIONOFLAW,STATUTORYOROTHERWISE,INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME
FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION
MAINTENANCEORUSEOFTRENDNET'SPRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXISTORWASCAUSEDBYCUSTOMER'SORANYTHIRDPERSON'SMISUSE,NEGLECT,
IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR
MODIFY, ORANY OTHER CAUSE BEYONDTHE RANGE OF THE INTENDED USE, OR BY
ACCIDENT,FIRE,LIGHTNING,OROTHERHAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO
EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN
CONTRACTORTORT(INCLUDINGNEGLIGENCE),FORINCIDENTAL,CONSEQUENTIAL,
INDIRECT,SPECIAL,ORPUNITIVEDAMAGESOFANYKIND,ORFORLOSSOFREVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER
FINANCIALLOSSARISINGOUTOFORINCONNECTIONWITHTHESALE,INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE
POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR,
REPLACEMENT,ORREFUNDOFTHEPURCHASEPRICEPAID,ATTRENDNET'SOPTION.
THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY
REMEDYPROVIDEDHEREINSHALLFAILOFITSESSENTIALPURPOSE.
GoverningLaw:ThisLimitedWarrantyshallbegovernedbythelawsofthestateofCalifornia.
SomeTRENDnetproductsincludesoftwarecodewrittenbythirdpartydevelopers.Thesecodes
aresubjecttotheGNUGeneralPublicLicense("GPL")orGNULesserGeneralPublicLicense
("LGPL").
Go to or Download section and look for
the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are
distributed WITHOUT WARRANTY and are subject to the copyrights of the developers.
TRENDnet does not provide technical support for these codes. Please go to
or for specific terms of
eachlicense.
http://www.trendnet.com/gpl http://www.trendnet.com
http://www.gnu.org/licenses/gpl.txt http://www.gnu.org/licenses/lgpl.txt
PWP05202009v2
