TRENDnet TDM-C500 Manuel utilisateur

Features

1 x 10/100Mbps Auto-MDIX RJ-45 port

1 x RJ-11 port

1 x USB 2.0 Type B-port (male) for alternate Ethernet connection

On / off power button

Diagnostic LEDs

Modem features:

Compliant with ADSL, ADSL2, and ADSL2+ (Annex A, L, and M) standards

Up to 24Mbps downstream and 1.2Mbps upstream Annex M is up to 3Mbps upstream

Compliant with PPPoE, PPPoA, and IPoA connection types

Router features:

Supports up to 8 PVCs

Compliant with SNMP v1 and v2c standards and Supports IGMP v1 and v2, port forwarding, and DMZ controls

Supports RIP, Static routing, and Dynamic DNS service

Advanced Firewall protection with Network Address Translation (NAT) and Stateful Packet Inspection (SPI)

Internet Access Control (MAC Address, Domain, URL, and IP Filtering) support

Supports IP Quality of Service (QoS)

Easy configuration and remote management with a Web browser (HTTP), and CLI

Universal Plug and Play (UPnP) and Application Level Gateway support for Internet applications such as email, FTP,

gaming, remote desktop, Net Meeting, telnet and more

3-year limited warranty

TDM-C500

rev:11.22.2010

The ADSL 2/2+ Modem Router, model TDM-C500, provides a modem for

Internet access and a high speed router to allow multiple connections to

the internet.

It supports all Internet service providers with ADSL 2, ADSL 2+, Annex A,

Annex L, or Annex M networks. Installation is a breeze with a step-by-step

setup wizard; status LEDs convey devices status; and a convenient on/off

power button protects hardware when powering down.

Protect your data with a dual NAT and SPI firewall. Manage access to the

Internet with IP port and MAC address filtering and URL and domain name

blocking controls. Additional features include a browser-based

management interface, SNMP v1 and v2 support, QoS data prioritization,

DMZ controls, Port Forwarding, and Dynamic DNS support.

TDM-C500(V1.0R)

ADSL 2/2+ Modem Router

wireless

SPECIFICATIONS

Protocol

Standards

Firewall

ATM

Management

WAN Port

(ADSL line Interface)

• Compliant with ADSL standards:

ANSI T1.413 Issue2

G.992.1 (G.dmt, Annex A)

G.992.2 (G.lite)

• Compliant with ADSL2 standard:

G.992.3 (G.dmt.bis, Annex L) • Compliant with ADSL2+ standard:

G.992.5 Annex A and M

• TCP/IP,NAT, HTTP, DHCP Server/Relay/Client, DDNS, DNS Proxy, UPNP

• Network Address Translation (NAT) • Stateful Packet Inspection (SPI)

• IEEE 802.3u 10/100Base TX Fast Ethernet

• OAM F4/F5 loop-back

• SNMP v1 and v2c

• PPP over ATM (RFC2364) • PPP over Ethernet (RFC2516) • ATM Traffic Shaping QoS(UBR, CBR, rt-VBR, nrt-VBR)

• VC and LLC Multiplexing • Bridged/Routed Ethernet over ATM (RFC1483/2684)

• Web based Configuration (HTTP) • IGMP v1 and v2 • SW upgrade

• 1 x 10/100Mbps Auto-MDIX RJ-45 port

Hardware

• Type B male port, supporting USB 2.0 and backwards compatible with 1.0 (optional LAN port)

LAN Port

• Reset to factory default

• Power, LAN: Link/ACT, USB, ADSL, Internet, USB

• 90 x 107 x 28 mm (3.5 x 4.2 x 1.1 in)

• Operating: 0°~ 40°C (32°~ 104°F)

• A: 9V, 1A external power adapter • EU : 9V, 0.5A external power adapter

• 4.3 Watts

• 221 g (7.8 oz)

• Max. 90% (non-condensation)

• Storage: -10°~ 70°C (-14°~ 158°F)

• CE, FCC

• 1 x RJ-11 port

• Power on/off button

• Packet Filtering – IP, MAC, Domain, Keyword • Management Access Control for LAN

• Command Line Interface (CLI) via Telnet

LED

Dimensions

Power

Weight

Humidity

Certifications

Power Consumption

Temperature

USB

Reset Button

On/Off Power Button

• Multi-Language Quick Installation Guide

• Power adapter

• RJ-11 telephone cable (1.8 m / 6 ft.)

RELATED PRODUCTS

PACKAGE CONTENTSNETWORKING SOLUTIONS

• TDM-C500

• CD-ROM (User's Guide)

• Cat. 5 Ethernet cable (1.5 m / 5 ft.)

TEW-635RBM

TE100-S50g

300Mbps Wireless N ADSL 2/2+ Modem Router

5-Port 10/100Mbps GREENnet Switch

TEG-PCITXR Gigabit PCI Adapter

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

1-888-326-6061

www.trendnet.com

TDM-C500(V1.0R)

ADSL 2/2+ Modem Router
