The TW-H6W1IR is a multi-function ISDN router that has 6

built-in Ethernet hub ports, which provides small and home

office users an all-in-one solution for Internet connection. The

built-in hub feature saves users the time and trouble of

purchasing and installing a separate hub by allowing 6

separate workstations to directly connect to the ISDN router.

The password protection for the system management

terminal, PAP, CHAP, and MS-CHAP protocols are supported

for remote access users. Also, the TW-H6W1IR is concen-

trated on easy-of-use, Internet/WAN security, and the cost-

effective use of ISDN services. Local and remote Telnet

allows simple setup and troubleshooting.

TW-H6W1IR

ISDN Ethernet Router with S/T Interface with Built-in 6-port 10Mbps Hub

BENEFITSFEATURES

Performance:

Flexibility:

Security:

Cost-Effectiveness:

Designed to easily integrate into any

Ethernet network.

Saves router costs, on-line charges,

and less expensive than owning a

class C IP address.

Can be used in either LAN or WAN

and 10Base-2 or 10Base-T

environments.

Built-in firewall and secure gateway

for LAN users.

6 Ethernet LAN ports (1 ISDN port + 2 RJ-11 ports)

128Kbps BRI ISDN TA support over a single ISDN line

Bandwidth-on-demand with BAP/BACP

PAP/CHAP/RADIUS, Caller ID, NAT, TCP/IP, DHCP

support

Internet access with single ISP account

Dial-on-demand to place a call to the remote site

automatically

Network Address Translator enables simultaneous use of

one IP address

Firewall protection, PPP/MP security

LAN-to-LAN enterprise connections

Remote dial-in server support

Control local and remote console via Telnet

SNMP manageable

ISDN S/T interface support

Flash memory for firmware upgrade

Setup utility for easy configuration

5 Year Warranty

TW-H6W1IR (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TW-H6W1IR

ISDN Ethernet Router with S/T

Interface/Built-in 6-port 10Mbps Hub

NETWORKING SOLUTIONS

SPECIFICATIONS

TW-H6W1IR

ISDN Ethernet Router with S/T Interface with Built-in 6-port 10Mbps Hub

TW-H6W1IR

ISDN Ethernet Router with S/T Interface with Built-in 6-port 10Mbps Hub

LAN Standard:

• IEEE 802.3 10Base-T Ethernet

LAN Protocol:

• CSMA/CD

LAN Speed:

• 10Mbps (half-duplex)

LAN Ports:

• 6 UTP/STP RJ-45 10Base-T

Ethernet ports

Communication Ports:

• ISDN port: 1 x S/T Interface

• Analog phone port: 2 x RJ-11

• Console Port: 1 x DB-9 RS-232

DCE port

Network Cables:

• 2-pair UTP CAT 3, 4, 5, (100m) for

10Base-T, EIA/TIA-568 100-ohm

Screened Twisted Pair (STP)

LEDs:

• Power, Test, ISDN (LINK, B1/B2),

Ethernet (Link/Act, Col), and Phone 1, 2

ISDN Speed:

• ISDN BRI up to 128Kbps

ISDN Protocol:

• PPP/Multi-link PPP

Power Supply:

• 18V/750mA through external

DC power adapter

Power Consumption:

• 8.5 W max.

Dimensions:

• 220 x 166 x 45 mm

(8.7 x 6.5 x 1.8 inches)

Weight:

• 739 g (1.6 lbs.)

Temperature:

• Operating: 0° to 50° C (32° to 122° F)

• Storage: -25° to 55° C ( -13° to 131° F)

Humidity:

• 5 % to 95 % non-condensing

Certifications:

• FCC, VCCI, CE 0682 X, UL, CSA

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
