TRENDnet TEG-PCITXRL Manuel utilisateur
TEG-PCITXR
TEG-PCITXRL
3.02
Quick Installation Guide
Table of Contents
Version 03.18.2010
English 1
1. Before You Start
2. How to Install 2
1
Troubleshooting 5
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
1. Before You Start
1
Package Contents
?
?CD-ROM (Driver)
?Multi-Language Quick Installation Guide
TEG-PCITXR/TEG-PCITXRL
System Requirements
?
?CD-ROM Drive
?CPU: 1GHz or above (Windows 7) / 800MHz or above (Windows Vista) /
300Mhz or above (Windows XP/2000/ME/98)
?Memory: 1GB RAM or above (Windows 7) / 512MB RAM or above
(Windows Vista) / 256MB RAM or above (Windows XP/2000/ME/98)
?Windows 7(32/64-bit) / Vista(32/64-bit) / XP(32/64-bit) / 2000/ME/98
?A RJ-45 Ethernet cable
32-bit PCI 2.1 slot
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
2. How to Install
2
4. Follow the InstallShield Wizard instructions
(Windows Vista/XP/2000).
Note:
1．For Windows 98SE and Me driver installation, refer to the user guide on the Driver
CD-ROM.
2．Do not insert the TEG-PCITXR/TEG-PCITXRL until instructed to do so.
1. Insert the Driver CD-ROM into your computer's
CD-ROM Drive (Windows Vista/XP/2000).
3. Click Install Driver (Windows Vista/XP/2000).
5. Click Yes (Windows 2000 only)
2. Click Run autorun.exe (Windows Vista only)
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
3
6. Click Finish (Windows Vista/XP/2000).
7. Shutdown your computer and then open your
computer's Case.
8. Insert PCI Card firmly into an available PCI slot,
and then turn ON the computer and wait until
the Windows desktop appears.
9. Drivers will install automatically.
10. Click Yes (Windows 2000 only).
ENGLISHFRANÇAISDEUTSCHESPAÑOL
ÐÓÑÑÊÈÉ
4
Your Installation is complete
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
For detailed information regarding the TEG-PCITXR/ L’s configuration and
advanced settings, please refer to the Troubleshooting section, User's Guide on the Utility
CD-ROM, or TRENDnet's website at http://www.trendnet.com.
TEG-PCITXR
11. Connect a RJ-45 network cable from the
computer to an available Ethernet port on
your router or switch.
Troubleshooting
5
1.
1.
1.
I inserted the Driver CD-ROM into my computer's CD-ROM drive and the
installation menu does not appear automatically. What should I do?
For Windows Vista, if the installation menu does not appear automatically, click
Start, click the Start Search box, and type D:\autorun.exe where "D" in
"D:\autorun.exe" is the letter assigned to your CD-ROM Drive, and then press
the ENTER key on your keyboard.
2. For Windows 2000/XP, if the installation menu does not appear automatically,
click Start, click Run, and type D:\autorun where "D" in "D:\autorun.exe" is the
letter assigned to your CD-ROM Drive, and then press the ENTER key on your
keyboard.
2. Windows doesn't recognize my new hardware. What should I do?
Verify that your computer meets the system requirements as specified in
Section 1.
2. Access your device manager to make sure the adapter is installed properly. If
you see a networking device with a yellow question mark or exclamation point,
you will need to reinstall the device and/or the drivers. To access the device
manager on Windows 2000/XP, right-click My Computer, click Properties, click
the Hardware tab, and then click Device Manager. To access the device
manager on Windows 7/Vista, right-click Computer, click Properties and then
click Device Manager .
3. If the device manager fails to recognize the presence of a new networking
adapter, verify that the network adapter is firmly seated in the PCI slot.
4. Plug the adapter into another PCI slot on your computer.
3. Windows recognizes my new hardware, but I'm unable to connect to my
network. What should I do?
1. Verify that the RJ-45 Ethernet Cable is securely connected from your switch or
router to your network adapter.
2. Verify that the LEDs on your network card are lit.
Verify that the TCP/IP settings are set to Obtain an IP address automatically
(see the steps below).
Windows 7
1. Go into the Control Panel, click Network and
Internet, click Network and Sharing Center,
click Change Adapter Settings and then
right-click the Local Area Connection icon and
then click Properties.
6
2. Click Internet Protocol Version 4(TCP/IPv4)
and then click Properties. Then click on
Obtain an IP address automatically.
1. Go into the Control Panel, click Network and
Internet, click Network and Sharing Center,
click Manage Network Connections and then
right-click the Local Area Connection icon
and then click Properties.
Windows Vista
2. Click Internet Protocol Version 4(TCP/IPv4)
and then click Properties. Then click on
Obtain an IP address automatically.
1. Go into the Control Panel, double-click the
Network Connections icon and then right-click
the Local Area Connection icon and then click
Properties.
Windows XP/2000/2003Server
2. Click Internet Protocol (TCP/IP) and then click
Properties. Then click on Obtain an IP
address automatically.
7
4. How do I install the drivers on Windows 98 or ME?
Please refer to the User's Guide included on the Driver CD-ROM.
5. Why am I only getting a network connection speed of 100Mbps instead of
1000Mbps?
1. Check the Ethernet Cable. Make sure you are using CAT-5e or CAT-6 Ethernet
Cables. Some CAT-5 cables are not rated to run in Gigabit.
2. Make sure you are connected to a 1000Mbps switch
If you still encounter problems or have any questions regarding the
TEG-PCITXR/TEG-PCITXRL, please refer to the User's Guide included on the Driver
CD-ROM or contact Trendnet's Technical Support Department.
.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
