Gigafast EE101-AEX Manuel utilisateur

PCMCIA Fast Ethernet card user’s manual

PCMCIA

10/100M Fast Ethernet Card

User’s Manual

Rev 2.0

PCMCIA Fast Ethernet card user’s manual

Regulatory compliance

This equipment has been tested and found to comply with the limits for

a Class B digital device pursuant to Part 15 of the FCC Rules. This

equipment also complies with CE EN55022 Class B and VCCI V3 Class

B specifications. These limits are designed to provide reasonable pro-

tection against harmful interference when the equipment is operated in a

commercial environment.

This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful interferen-

ce in which case the user will be required to correct the interference at

his own expense.

Changes or modifications not expressly approved by the parties respon-

sible for compliance could void the user’s authority to operate the

equipment.

About this manual

This user’s manual describes how to install and operate your Ethernet

card. Please read this manual before you install the product.

This manual includes the following topics:

ØProduct description, features and specifications.

ØHardware installation procedure.

ØSoftware installation procedure.

ØTrouble shooting procedures

PCMCIA Fast Ethernet card user’s manual

Table of contents

Regulatory compliance..........................................................................i

About this manual .................................................................................i

Table of contents..................................................................................ii

CHAPTER 1 1

Introduction 1

Features (for dongle-less PC Card).............................................................. 1

Features (for dongle type PC Card).............................................................. 2

Technology overview................................................................................... 2

CHAPTER 2 4

Hardware installation (for Dongle-less PC Card) 4

What’s in the package................................................................................. 4

Hardware description.................................................................................. 4

Inserting the Ethernet card .......................................................................... 5

Connecting to a LAN................................................................................... 6

Status LEDs................................................................................................ 6

Ejecting the Ethernet card ........................................................................... 7

Hardware installation (for Dongle Type PC Card) 8

What’s in the package................................................................................. 8

Hardware description.................................................................................. 8

Inserting the Ethernet card .......................................................................... 9

Media Coupler LEDs .................................................................................11

Disconnecting the Ethernet Card ................................................................11

CHAPTER 3 15

Driver installation for Win 95/98/ME/2000/NT 15

Driver installation for Windows 95.....................................................15

Before Installation......................................................................................15

Driver Installation for Windows 95 OSR2 ..................................................16

Driver Installation on the Windows 95 Retail Version ................................20

Driver installation for Windows 98.....................................................21

Driver installation for Windows ME...................................................25

Driver installation for Windows 2000.................................................27

Driver installation for Windows NT 4.0..............................................31

CHAPTER 4 35

Driver installation for DOS environments 35

System Requirements.................................................................................35

Driver installation..............................................................................35

PCMCIA Fast Ethernet card user’s manual

iii

Driver installation program ........................................................................35

Quick installation.......................................................................................36

The Install program............................................................................37

Using the Install program...........................................................................37

Auto configuration .....................................................................................39

Custom configuration.................................................................................40

Manual installation............................................................................42

Enablers.....................................................................................................43

Driver installation..............................................................................45

Microsoft Windows NT 3.51......................................................................45

Microsoft Windows for Workgroups 3.11...................................................46

Netware 3.X/4.X client ..............................................................................47

Microsoft LAN Manager ............................................................................47

Artisoft LANtastic version 6.0....................................................................48

CHAPTER 5 49

Installation for Linux 49

System Requirements.................................................................................49

Installing the driver for Linux.....................................................................50

APPENDIX A 53

Troubleshooting 53

Q&A for Windows environments.........................................................53

Windows 95/98..........................................................................................53

Windows 2000...........................................................................................54

APPENDIX B 55

Enabler program error messages 55

CARDGO.EXE..........................................................................................55

PCMCIA Fast Ethernet card user’s manual

Chapter 1

Introduction

Thank you for purchasing the Ethernet card. This high-speed Eth-

ernet card complies with the PCMCIA standard and uses a female

RJ-45 connector to connect to the network.

The Ethernet card is switchless and software configurable.

Features (for dongle-less PC Card)

•Dongle-less design that integrates RJ-45 connector onto the

PC card

•No moving parts to break and no media coupler to lose

•Complies with IEEE 802.3u 100Base-TX and IEEE 802.3

10Base-T

•PCMCIA 2.1 and JEIDA 4.2compliant and later

•PC Card standard 68-pin 16-bit PCMCIA interface

•Support all popular Network Operating Systems

•Supports hot swap card insertion and removal

•10/100Mbps auto-sensing

•Full/half-duplex auto-negotiation for both 10Base-T and

100Base-TX

•Switchless configuration setting

PCMCIA Fast Ethernet card user’s manual

Features (for dongle type PC Card)

•Type II credit-card size (5.0 mm)

•Complies with IEEE 802.3u 100Base-TX and 802.3

10Base-T protocols.

•PCMCIA 2.1 and JEIDA 4.2compliant and later

•PC Card standard 68-pin 16-bit PCMCIA interface

•Supports all popular operating systems

•Supports hot swap card insertion and removal

•10/100Mbps auto-sensing

•Full/half-duplex auto-negotiation for both 10Base-T and

100Base-TX

•Switchless configuration setting

Technology overview

LAN

LAN (Local Area Network) is a communications network that

serves users within a confined geographical area. It is made up of

servers, workstations, a network operating system, and a communi-

cations link.

Ethernet

Ethernet is the most widely-used LAN access method, which is de-

fined by the IEEE 802.3 standard. Ethernet is normally a shared

media LAN. All stations on the segment share the total bandwidth,

which is 10 Mbps (Ethernet), 100 Mbps (Fast Ethernet), or 1000

Mbps (Gigabit Ethernet). With switched Ethernet, each sender and

receiver pair has the full bandwidth.

PCMCIA Fast Ethernet card user’s manual

Fast Ethernet

Also called 100BaseT, it is a high-speed version of Ethernet (IEEE

802.3u standard). 100BaseT transmits at 100 Mbps rather than 10

Mbps. Like regular Ethernet, Fast Ethernet is a shared media LAN.

All nodes share the 100 Mbps bandwidth. 100BaseT uses the same

CSMA/CD access method as regular Ethernet with some modifica-

tion. Three cabling variations are provided. 100BaseTX uses two

pairs of Category 5 UTP, 100BaseT4 uses four pairs of Category 3,

and 100BaseFX uses multi-mode optical fibers and is primarily in-

tended for backbone use.

This concludes the first chapter. The next chapter deals with the

hardware installation of the Ethernet card.

PCMCIA Fast Ethernet card user’s manual

Chapter 2

Hardware installation

(for Dongle-less PC Card)

This section covers inserting your Ethernet card in the notebook’s

PCMCIA slot, and connecting the card to a network.

What’s in the package

Please ensure that the following items are included in your package.

If any items are missing, contact your dealer.

•PCMCIA 10/100Mbps Ethernet card

•CD-ROM (includes device drivers and this user’s manual)

•Quick Installation Guide

•Hard Case

Hardware description

The Ethernet card is encased in a stainless compact frame and has a

68-pin connector for attaching to the notebook’s PCMCIA slot, and

an RJ-45 connector for use with 10BaseT Ethernet or 100BaseTx

Fast Ethernet networks.
