TRENDnet TEW-641PC Manuel utilisateur

Quick Installation Guide

TEW-641PC

TEW-643PI

1.03

English 1

1. Before You Start

2. How to Install 2

3. Using the Wireless Adapter 7

Troubleshooting 9

Wireless Tip 10

Table of Contents

Version 01.27.2010

1. Before You Start

?32-bit PCI 2.2 slot (TEW-643PI)

?CD-ROM Drive

?CPU: 1GHz or above (Windows 7) / 800MHz or above (Windows Vista) / 300Mhz

or above (Windows XP/2000)

?Memory: 1GB RAM or above (Windows 7) / 512MB RAM or above

(Windows Vista) / 256MB RAM or above (Windows XP/2000)

?Windows 7(32/64-bit) / Vista (32/64-bit) / XP (32/64-bit) / 2000

32-bit CardBus Type II Card slot (TEW-641PC)

Package Contents

?CD-ROM (Utility and Driver)

?Multi-Language Quick Installation Guide

?2 x 2dbi Detachable Antennas

(TEW-643PI only)

TEW-641PC/TEW-643PI

System Requirements

2. How to Installation

1. Insert the Utility & Driver CD-ROM into your

computer's CD-ROM Drive .

Important! DO NOT install the TEW-641PC/TEW-643PI in the computer until instructed

to do so.

2. Click Run autorun.exe

(Windows 7/ Vista only).

3. Click Install Utility.

4. Follow the InstallShield Wizard instructions.

Then click Next.

5. Click Install this driver software anyway

(Windows 7/Vista).

6. Click Continue Anyway (Windows XP).

7. Click Yes (Windows 2000).

10. Insert PC Card firmly into an available PC

Card slot of the notebook PC and then turn ON

the computer and wait until the Windows

desktop appears.

9. Shutdown your computer.

TEW-641PC

Note: Please refer to your computer's user manual regarding hardware installation.

Then proceed to the appropriate section below.

8. Click Finish.

TEW-641PC

Windows 7/Vista

12. Shutdown your computer.

13. Open your computer's case.

14. Insert PCI Card firmly into an available PCI

Card slot of the desktop PC, attach the

included antenna, and then turn ON the

computer and wait until the Windows desktop

appears.

15. For Windows XP, proceed to step 17. For

Windows 2000, proceed to step 15. For

Windows 7/Vista, continue on to step 16.

16. Windows 7/Vista will automatically detect and

install the appropriate drivers.

11. Go to Step 15.

Windows XP

17. The Found New Hardware Wizard appears.

Select No, not this time and then click Next.

18. Click Install the software automatically

(Recommended) and then click Next.

19. Click Continue Anyway.

20. Click Finish.

Windows 2000

Your installation is now complete

21. Click Yes.

3. Using the Wireless Adapter

Note:

1. Windows XP Wireless Zero Configuration utility must first be disabled as

shown in step 1 and 2. If it is already disabled, then go to Step 3.

2. For Windows 7/Vista/2000, proceed to Step 3.

1. Go into the Control Panel and double-click

Network Connections icon. Right-click

Wireless Network Connection icon and click

Properties.

2. Click the Wireless Networks tab, uncheck Use

Windows to configure my wireless network

settings, and then click OK.

3. Double-click the Wireless N Client Utility icon

in your system tray.

Wireless Configuration is complete

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

For detailed information regarding the TEW-641PC/TEW-643PI configuration and advanced

settings, please refer to the Troubleshooting section, User's Guide on the Utility CD-ROM, or

TRENDnet's website at http://www.trendnet.com.

4. Click Site Survey, select the SSID and then

click Connect.

5. If encryption is enabled on your wireless

network, the proper Authentication type and

Encryption type will be selected automatically.

Enter the encryption key and click Apply.
