TRENDnet TBW-107UB Manuel utilisateur



TBW‐107UB

UserGuide

MicroBluetooth®USBAdapter



1. Introduction



Perfectforyourhomeorofficewiththisdongleswhichallowsyoutoconnect

withyourentireBluetoothdevicesuchasphones,PCs,PDA,Printer,Laptop,web

pad…andsoon.Eliminateproprietarycables,andallowmobileusertoconnect

tomobileoperatingdeviceswirelesslyandeffortlessly.



ThedongleisfullycompliantwiththeBluetoothv2.1specificationand

backward‐compatiblewithBluetoothversion1.1or1.2standards.Moreover,it

supportsthenewBluetoothEnhancedDataRate(EDR),providingrawbandwidth

of3Mbpsforwirelessapplications.



Features



CompliantwithBluetoothv2.1specificationwithEDR(EnhancedDataRate)

support

BackwardcompatiblewithBluetoothv1.1andv1.2devices

Upto3MbpsAccessDataRateandLowPowerconsumption

CompatiblewithWindows2000/XP/Vista/7operatingsystems

Built‐in128‐bitencryptionofsecureddatacommunications

EnablecomputerstoconnectBluetooth‐enableddevicessuchasprinters,

headset,audio/video,basicimages,PDAs,andmobilephone

CompliantwithClass1(TBW‐106UB)orClass2(TBW‐107UB)Bluetooth

operations

Trouble‐freePlug&Playinstallation

SupportOHCIandUHCIhostinterface

Portable,lightweightandminisize



PackageContents



TBW‐106UBorTBW‐107UB

Multi‐LanguageQuickInstallationGuide

Driver&UtilityCD‐ROM



2. installation

1. SystemRequirements

Atlease500MBoffreedisk.

Windows7/VistaorWindowsXP.

2.InstallingBlueSoleil

2.1Beforeinstalling

UninstalltheearlierversionofBlueSoleilyouinstalledonyourcomputer:ClickStart

‐>ControlPaneltoopenControlPanel,andthenchooseUninstallaprogram.Select

BlueSoleilintheprogramlistanduninstallit.

Note:Bluetoothadaptercanberemainedpluggedorunpluggedduringthe

installation.

2.2InstallingBlueSoleil

2.2.1.InsertBlueSoleilinstallationCDintotheCD‐ROM.

2.2.2.Double‐clicksetup.exetostartinstallation.

 

2.2.3.Choosethesetuplanguage.

 

2.2.4.Followtheinstructionsonthescreen.

 

2.2.5.Restartyourcomputer.

 

Note:Ifyoudonotrestart,someoperationsmaybeabnormal.

3.UninstallingBlueSoleil

BlueSoleilcanonlyberemovedfromControlPanel.Fordetailedinstructions,please

referto"step3.1beforeinstalling"inthisguide.

4.GettingStarted

4.1StartingBlueSoleil

Doubleclick"BluetoothPlaces"icononthedesktoporright‐clicktheBluetooth

iconinthesystemtrayandselect"ExploreBluetoothPlaces".

4.2SearchremoteBluetoothDevices

Makethedevicesdiscoverablefirst.Double‐clickSearchDevicesiconandthen

Bluetoothdeviceswillappearinthewindow.

4.3SearchServices

Double‐clickthedeviceicontoenterthedevice'ssubfolder.Servicessupportedby

thedevicewillappearinthewindowautomatically.Ifnot,double‐clickSearch

Servicesicontorefresh.

4.4Establishaconnection

Doubleclickaserviceicontoinitiateaconnection.

Youmightbepromptedtoenterapasskeytoauthenticate.Enterthesamepasskey

onbothsides,orenterthespecificoneprovidedbythedevicemanufactureonyour

computersideonly.OnBlueSoleilside,thedialogboxasshowninthefollowing

picturewillpopupforyoutoenterapasskey.

 

4.5Terminateaconnection

Right‐clicktheconnectingremoteserviceicon,andselectDisconnect.

 



3. UserGuides



LocalBluetoothDevice

TheLocalBluetoothenableddevice,knownas"MyDevice",representstheuser's

computerthatisrunningBlueSoleil.



Icon:



Operations:

•HovermousetodisplaythelocalBluetoothdevice'snameoraddress(if

withoutname).

•ClickontheredballtostartorstopsearchingforBluetoothdevicesinrange.

•Right‐clickontheredballtodisplayapop‐upmenuofrelatedoperations(e.g.,

GeneralInquiry,MyServices,Security,etc.).

RemoteBluetoothDevices

RemotedevicesareotherBluetoothenableddevicesthatareintheBluetoothradio

rangeofyourlocaldevice.BlueSoleilusesdifferenticonstoindicateddifferenttypes

ofremotedevices..

Icons

DevicesIconDevicesIcon

Personal

Computer

Laptop



Modem



Mobile



PDA



LANAccess

Point

Keyboard

Mouse



Microphone



HiFiAudio



LoudSpeaker



Headset



Printer



Scanner



FAX



Camera



Gamebar



Server



Unknown

device



IconMeanings

Remotedevicescanbeinanyofthreestates,whichBlueSoleilindicateswith

differentcolors.

•White‐Idle.Thenormalstateofthedevice.

•Yellow‐Selected.Youhaveselectedthedevice.

•Green‐Connected.Thedeviceisconnectedtoyourcomputer.

Operations

•Single‐clickontheicontoselect.

•Double‐clickontheicontosearchfortheservicessupportsbytheremote

Bluetoothdevice.

•Right‐clickontheicontodisplayapop‐upmenuofrelatedoperations(e.g.

RefreshServices,PairDevices,Connect,etc.).

BluetoothServiceButtonsofRemoteDevice

ServicebuttonsatthetopoftheMainWindowrepresentarangeofBluetooth

servicespotentiallysupportedbyRemoteDevices.

ServicesButtonImageServicesButtonImage

PAN



DUN



SPP



Advanced

Audio

FTP



SYNC



OPP



HCRP



HID



FAX



BIP



Headset



IconMeanings

Thereare3statesfortheserviceicons,indicatedbydifferentcolors.

•White‐Idle.Thenormalstate.

•Yellow‐Available.TheBluetoothserviceisavailableontheselectedremote

device.

•Green‐Connected.TheBluetoothserviceisactiveinaconnectionwiththe

remotedevice.

Operations

•Hoveryourmouseovertheserviceicontodisplaythenameoftheservice.

•Single‐clickontheserviceicontoconnect.

•Right‐clickontheserviceicontodisplayapop‐upmenuofrelatedoperations.



LocalServiceStatus

ThelocalservicestatuscanbeviewedfromtheLocalServiceStatusdialogbox.

RightclickwhicheverlocalserviceiconinservicewindowandselecttheStatus...on

thepop‐upmenu.

TheLocalServiceStatusdialogwillbedisplayed.



Figure1:LocalServiceStatus(e.g.SerialPortAservice)



Connection:

 Status:Whetherthelocalserviceisconnected.

 DeviceAddress:DisplaytheBluetoothaddressofremotedevicewhichconnectto

theservice.

 Duration:Thetimeelapsedsincetheconnectionwassetup.

 COMPort:ThevirtualBluetoothCOMportsconnectedbyremotedevice. 

PANServiceStatusdialogisdifferentfromothers.



Figure2:LocalServiceStatus(PAN)

Connection:

 Status:Whetherthelocalserviceisconnected.

 DeviceName:Displaythenameofremotedevicewhichconnectstotheservice.

 Duration:Thetimeelapsedsincetheconnectionwassetup.

ConnectionList:

 DisplaythenamesandaddressesofremotedeviceswhichconnecttothePAN

Service.

LocalServiceList

TheLocalServiceListdisplaysalltheBluetoothservicessupportedbythelocal

computer.Usethisscreentostart/stopservices.

ServicesIconsServicesIcons

PANSPP

OPPFTP

SYNCBIP

AudioSink 

IconMeanings

Thereare3statesforthelocalBluetoothservices,indicatedbydifferenticoncolors.

•White‐Idle.Theservicehasnotbeenstarted.

•Yellow‐Started.ThelocalBluetoothservicehasbeenstarted.

•Green‐Connected.Someremotedevicehasconnectedtotheservice.

Operations
