TRENDnet TBW-105UB Manuel utilisateur

TBW-105UB

H/W: A1.0R

Quick Installation Guide

Table of Contents

Version 06.12.2008

English ...................................................................................................... 1

1. Before You Start

2. How to Install .....................................................................................

3. Configuring the Bluetooth Adapter ....................................................

................................................................................

Troubleshooting ........................................................................................ 9

System Requirements

1. Before You Start

English

Package Contents

Application

* Backwards compatible with USB 1.1 at 12Mbps

PDA

Bluetooth

Headset Printer

(TBW-105UB)

Compact Bluetooth USB 2.0 Adapter

Cell Phone

TBW-105UB

Quick Installation Guide

Utility & Driver CD-ROM?

?Computer With An Available USB 1.1 or 2.0 Port

?CPU: Pentium 300MHz or Above/ 800MHz or Above

?Hard Drive Space: 50MB or Above

?Windows Vista/XP/2000/ME/98SE

(Windows Vista)

Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)

D-ROM drive

Note: Do not insert the TBW-105UB USB adapter until instructed to do so.

Note: For Windows XP/2000/ME/98SE proceed to step 7.

2. How to Install

English

1. Insert the Utility & Driver

CD-ROM into your CD-ROM drive

and click Install Utility.

Windows Vista

2. When you reach this screen,

connect the TBW-105UB into the

computer's USB port.

3. Click Next.

5. Click Finish.

6. Proceed to Section 3.

English

4. Select I accept the terms in the

license agreement. Click Next

Windows XP/2000/ME/98SE

7. Click Next.

8. Select I accept the terms in the

license agreement. Click Next.

9. Insert your Windows 98SE CD and

then click OK (Windows 98SE

only).

11. Click Finish.

12. Click Yes to restart the computer

Windows 2000, ME and 98SE

only).

10. When you reach this screen,

connect the TBW-105UB into the

computer's USB port. Then click

OK.

Your installation is now complete.

English

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

English

3. Configuring the Bluetooth Adapter

Windows Vista

Note: Make sure your Bluetooth device is powered on and in pairing mode.

1. Double-click the Bluetooth icon in

the system tray.

2. Click Add.

3. Click Next.

English

5. Type in a Bluetooth security

code (for example: 0000. Please

consult your Bluetooth device's

manual for more information) and

then click Next. Then put in the

same Bluetooth security code on

your Bluetooth device.

6. Click Finish.

4. Select your Bluetooth device and

then click Next.

1. The Initial Bluetooth

Configuration Wizard may appear

automatically. If the Initial

Bluetooth Configuration Wizard

does not appear automatically,

double click on the Bluetooth icon

in the system tray.

Windows XP/2000/ME/98SE

2. Click Next.

3. Click Next.

5. Click Finish.

4. When you reach this screen, click

Skip.

English

6. My Bluetooth Places window

may appear automatically. If the

My Bluetooth Places window

doesn't appear automatically,

double-click the My Bluetooth

Places icon.

7. Click Bluetooth -> Search For

Devices.

8. Right click on your Bluetooth

device and then click Pair.

9. Type in a Bluetooth security

code (for example: 0000. Please

consult your Bluetooth device's

manual for more information) and

then click OK. Then put in the

same Bluetooth security code on

your Bluetooth device.

10. Double left-click on your

Bluetooth device to show the

available services.

Your configuration is now complete.

For detailed information regarding the TBW-105UB configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com
