TRENDnet TE-16PNP Manuel utilisateur

The TE-16PnP Series is a new Plug-n-Play (PnP) Ethernet

adapters built on the technology of TRENDware's best selling

TE-16XP Ethernet adapter. The TE-16PnP Series incorporate

new Plug-n-Play technology which allows PnP systems to

automatically configure installed devices without users'

intervention. This Plug-n-Play technology is revolutionary in

that it eliminates the guess-work involved in upgrading PCs.

TE-16PnP

High Performance Plug-n-Play Ethernet Adapters

Complies with IEEE 802.3 10Base-T, 10Base-2 and

10Base-5 Ethernet standards

Full-duplex operation at 10Base-T connection

Compliant with Plug and Play ISA specification version

1.0a

Simply insert the card and it will be automatically

configured in a PnP system

Setup program provided for non-PnP system, no jumpers

or switches on board

NE2000 Compatible

8/16-bit ISA Bus Auto-sensing

Auto-sensing connector in use

On-board socket for optional Boot ROM

External LED Indicators for troubleshooting (LINK and

TRAFFIC)

10Mbps(Half duplex)/20Mbps(Full duplex) Transfer Rate

5 Year Warranty

FEATURES

TE-16PNP (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

SPECIFICATIONS

Standards:

IEEE 802.3 10Base-2, 10Base-T, and 10Base-T

On-board Connector:

RJ-45, BNC, and AUI

Data Bus Supported:

8 or 16 bits ISA bus, Auto-sensing

IRQ’s Supported:

2(9), 3, 4, 5, 10, 11, 12, 15

I/O Base Address:

220, 240, 260, 280, 2A0, 2C0, 2E0, 300, 320,

340, 360, 380, 3A0, 3C0, 3E0

Boot ROM Address:

C800h, CC00h, D000h, D400h, D800h, DC00h

RAM Buffer:

16Kb

•

Dimensions:

6.20" x 2.95" (T/C/CT model),

6.20" x 3.92" (CAT model)

Emission Compliance:

FCC Part 15 Class B, EN 55022 Class B, CISPR

22 Class B

Immunity Compliance:

IEC 801-2 (Electrostatic Discharge), IEC 801-3

(Radiated Immunity), IEC 801-4 (Electrical Fast

Transient/Burst)

Power Consumption:

80mA at 5V, 180mA at 12V

Operating Temperature:

0° to 55°C

Operating Humidity:

10 to 90%, non-condensing

•

TE-16PnP

High Performance Plug-n-Play Ethernet Adapters

TE-16PnP

High Performance Plug-n-Play Ethernet Adapters

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE-16PT: ISA Plug-n-Play Ethernet

Adapter with RJ-45 Connector

TE-16PT/50: 50-Pack TE-16PT

TE-16PCT: ISA Plug-n-Play Ethernet

Adapter with BNC + RJ-45 Connectors

TE-16PCT/50: 50-Pack TE-16PCT

TE-16PCAT: ISA Plug-n-Play Ethernet

Adapter with BNC + RJ-45 + AUI

Connectors

TE-16PnP: Boot ROM for Novell Netware

and Microsoft Windows NT

ORDERING INFORMATIONORDERING INFORMATION

TRENDnet

TRENDware, USA

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
