Transystem PLC100 Manuel utilisateur
M
MM
MD
DS
S
Transmitter
Operation Manual
Copyright 2007, TRANSYSTEM, INC.
All rights reserved
TRANSYSTEM INC.
No.1-2 Li-Hsin Rd.I Science-Based
Industrial Park, Hsinchu, Taiwan
Tel:+886-3-5780393 Fax:+886-3-5784111
e-mail:sales@transystem.com.tw
website: www.transystem.com.tw
8029607101A
2
*Contact Us:
The Headquarter
Tel : + 886-3-578-0393
Fax: + 886-3-578-4111
Website: http://www.transystem.com.tw
Address: NO. 1-2, LI-HSIN RD.I, SCIENCE-BASED INDUSTRIAL PARK, HSINCHU,
TAIWAN
3
TABLE OF CONTENTS
Chapter 1. General Information 4
1.1 Module Features and Specifications 4
Chapter 2. Installation 5
2.1 Step by Step Installation 5
2.2 Connection to the Power Inserter and Cable Modem 8
2.3 Waterproofing Connections 10
Chapter 3. Accessories 12
3.1 MMDS Antenna 12
4
Chapter 1. General Information
1.1 Module Features and Specifications
PLC100 PLC200
Input Frequency 22~34 MHz 12~42 MHz
Output
Frequency
2170~2182MHz
2500~2530MHz
Output 1 dB
Compression
Point
24dBm Typ. 24dBm Typ.
Output
Transmitting
Gain
24±2dB 24±2dB
Output
Transmitting
Noise
-122dBm/Hz Max -116dBm/Hz Max
Output Spurious
(+22dBm TX Out) -60dBc Max -60dBc Max
Output Power
Blanking
Threshold
-40dBm±1dB -40dBm±1dB
TX Switching
Latency <1.2uS <1.2uS
LO Stability ±10kHz ±10kHz
Phase Noise <- 65 dBc/Hz @100Hz
-85 dBc/Hz @lKHz
-90 dBc/Hz@10kHz
-95 dBc/Hz@100kHz
<- 65 dBc/Hz @100Hz
-85 dBc/Hz @lKHz
-90 dBc/Hz@10kHz
-95 dBc/Hz@100kHz
Input and Output
Return Loss 6.0dB min 6.0dB min
Input Impedance F-type 75 ohms F-type 75 ohms
Output
Impedance Dipole or N-type 50
ohms Dipole or N-type 50
ohms
Supply Voltage +15VDC to +24VDC +15VDC to +24VDC
Supply Current 350 mA max 350 mA max
Temperature -10 ~ +70℃ -10 ~ +70℃
Humidity 100% weatherproof 100% weatherproof
Lightning &
Surge Protection Meets IEEE
specifications Meets IEEE
specifications
Note: Typical value @25℃, unless otherwise specified. Technical specifications are
subject to change without prior notice.
5
Chapter 2. Installation
2.1 Step by Step Installation
2.1.1 Mounting BracketAssembly Suite
The following hardwares are suggested for mounting the Transmitter to
the pole. A set of mounting bracket includes ONE 2511 mounting bracket,
ONE bracket 3, ONE bracket 2, TWO screws 4013, and FOUR hex flange
nuts. Please contact TSI sales department for this accessory.
6
2.1.2 Step by Step Installation
Step 1 – Attach sequence
Left to right: Bracket 3, Bracket 2, and 2511 Mounting Bracket.
Step 2 – How toAttach
The concave of Bracket 2 is for holding onto the pole.
7
Step 3 – Tighten the bracket against pole
Step 4 – Installation Complete
Loosen Screws A & B for left-and-right and up-and-down angle adjustments.
Tighten up Screws A& B after fixing the directions.
8
2.2 Connection to the Power Inserter and Cable Modem
Connections to the Transmitter are shown in diagram 2.2. Please note:
① The power inserter normally has 3 ports:
DC Connect to wall adapter with RG-59 cable
ANT Connect to the Transmitter
TV Connect to Cable modem
VERY IMPORTANT NOTICE!
a. The power inserter should be correctly connected, or the Transmitter
will not operate.
b. Ensure that all wires and cables are hooked up before plugging into
the AC adapter/power supply (i.e. you must hook up the power supply
last).
9
② After connection, the F connector of Transmitter must be sealed with an
asphalt sealing tape. (For details, please refer to Section 2.3 Waterproofing
Connections)
Diagram 2.2: Connection to Cable modem & Power Inserter
