TP-Link UH720 Manuel utilisateur

For more information, please visit:

www.tp-link.com

♦ Keep this device away from water, fire, humidity or hot environments.

♦

Do not heavily drop or impact this device.

♦Do not attempt to disassemble, modify or fix this device by yourself. You run the risk of electric

shock and voiding the limited warranty. If you need service, please contact us.

♦Cut off the power supply before cleaning the device. Do not use liquid cleaning method.

♦

Use the power cord and power adapter provided with your device.

For best performance, the connected devices should not exceed a combined current of 6.55A.

♦

TP-LINK will not be held responsible for any damage to disk or hard disk data caused by

improper use.

Attention

Specifications are subject to change without notice. TP-LINK is a registered trademark of

TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are registered

trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to

make any derivative such as translation, transformation, or adaptation without permission

http://www.tp-link.com

FCC & CE

FCC STATEMENT

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including cause undesired

operation.

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

7106506230 REV2.0.2

User Guide

USB 3.0 Hub

Model No. UH720

Use only power supplies which are provided by manufacturer and in the original

packing of this product.

All manuals and user guides at all-guides.com

all-guides.com

Connect the devices as follows. The power LED will light up and the hub

is ready to use.

Charging

Transferring Data

Mobile Hard DiskUSB Flash DiskSmartphone

Usage Tips:

Hardware Connection

Using the Hub

Usage Tips:

Smartphone Pad

USB Mouse

This hub provides your computer with 7 additional USB 3.0 ports for

super-speed USB 3.0 data transfer.

This hub provides two charging ports with a maximum current of 2.4A to

quickly charge all kinds of mobile devices such as Android, Apple and

Windows products.

1. The USB 3.0 ports are also compatible with USB 2.0 and USB

1.1 specifications.

2. The USB 3.0 ports transfer data at a rate up to 5Gbps, but the

actual rate is limited by the USB transfer rate of the connected

devices.

3. The performance of 2.4GHz wireless devices (wireless

keyboards, mouses, etc.) may be affected when they are

working too close to USB 3.0 devices.

1. If your device’s current is less than 2.4A, the charging port can

automatically adjust its current supplied to your device to avoid

damage.

2. The charging ports are for charging your mobile devices only with

no data transfer.

1. The TP-LINK USB 3.0 hub is plug-and-play and requires no

driver for Windows, Mac OS X or Linux systems.

2. The hub is automatically turned on every time you plug the power

adapter into a power outlet.

3. The hub can transfer data even when the power adapter is

unplugged. In this mode, the power button will not work as a

power switch any more.

4. To prevent possible data loss or corruption, avoid unplugging or

plugging the power adapter when transferring data or charging.
