TP-Link T2500G-10MPS Manuel utilisateur

Business Networking Solution

Installation Guide

JetStream Gigabit L2 Managed Switch

T2500G-10TS (TL-SG3210)

T2500G-10MPS

Related Document

Contents

Chapter 1 Introduction ——————————— 01

1.1 Product Overview......................................................01

1.2 Appearance .................................................................01

Chapter 2 Installation———————————— 07

2.1 Package Contents.....................................................07

2.2 Safety Precautions....................................................07

2.3 Installation Tools ........................................................09

2.4 Product Installation...................................................09

Chapter 3 Lightning Protection ——————— 11

3.1 Cabling Reasonably ..................................................11

3.2 Connect to Ground ..................................................13

Chapter 4 Connection ——————————— 16

4.1 Ethernet Port...............................................................16

4.2 SFP Port ........................................................................16

4.3 Console Port................................................................16

4.4 Verify Installation .......................................................17

4.5 Power On .....................................................................18

4.6 Initialization ..................................................................18

Chapter 5 Conguration —————————— 19

5.1 Congure the Switch via GUI.................................19

5.2 Congure the Switch Using CLI ...........................20

Appendix A Troubleshooting ———————— 23

Appendix B Hardware Specications ————— 25

Gigabit L2 Managed Switch

Introduction

Chapter 1 Introduction

1.1 Product Overview

TP-Link JetStream Gigabit L2 Managed Switch, designed for workgroups and

departments, provides wire-speed performance and abundant layer 2 management

features. It provides a variety of service features and multiple powerful functions

with high security.

The EIA-standardized framework and smart configuration capacity can provide

flexible solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP

Inspection provide robust security strategies. QoS and IGMP snooping/filtering

optimize voice and video application. Link aggregation (LACP) increases aggregated

bandwidth, optimizing the transport of business critical data. SNMP, RMON, WEB

and CLI Log-in bring abundant management policies. TP-Link JetStream Gigabit L2

Managed Switch integrates multiple functions with excellent performance, and is

friendly to manage, which can fully meet the need of the users demanding higher

networking performance.

T2500G-10MPS L2 Managed PoE+ Switch is also a Power Sourcing Equipment (PSE*).

All the RJ45 ports on the switch support Power over Ethernet (PoE*) function, which

can automatically detect and supply power with those powered devices (PDs*)

complying with IEEE 802.3af and IEEE 802.3at.

*PSE: a device (switch or hub for instance) that provides power through an Ethernet

cable.

*PoE: This technology describes a system to transmit electrical power, along with

data, to remote devices over standard twisted-pair cable in an Ethernet.

*PD: a device powered by a PSE and thus consumes energy. Examples include

powering network cameras, wireless LAN access points, IP telephones, network

hubs, embedded computers etc.

1.2 Appearance

■Front Panel

The front panel of T2500G-10TS is shown as the following figure.

Figure 1-1 Front Panel of T2500G-10TS

LEDs

Console Port (USB)

SFP Port

10/100/1000Mbps RJ45 Port

Console Port (RJ-45)

Gigabit L2 Managed Switch

Introduction

LEDs

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

10/100/1000M

Green A 1000Mbps device is linked to the corresponding

port, but no activity

Yellow A 10/100Mbps device is linked to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off Not linked

SFP1, SFP2

On A 1000Mbps device is linked to the corresponding

port, but no activity

Flashing Data is being transmitted or received

Off Not linked

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and

configuring the switch. The switch has an RJ-45 console port and a micro-USB

console port available. Console input is active on only one console port at a

time. By default, the micro-USB connector takes precedence over the RJ-45

connector.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps

or 1000Mbps. Each 10/100/1000Mbps RJ45 port has a corresponding

10/100/1000M LED.

SFP Port

Designed to install the SFP module. T2500G-10TS features 2 individual SFP ports

and supports 1000M SFP module connection only.

Gigabit L2 Managed Switch

Introduction

The front panel of T2500G-10MPS is shown as the following figure.

Figure 1-2 Front Panel of T2500G-10MPS

LEDs

Console Port (USB)

SFP Port

10/100/1000Mbps RJ45 Port

Console Port (RJ-45)

LED Mode Switch Button

LEDs

T250 0 G -10 M PS has an LED mode switch button which is for switching the LED

status indication. When the Speed LED is on, the port LED is indicating the data

transmission status. When the PoE LED is on, the port LED is indicating the power

supply status. By default, the Speed LED is on. Pressing the mode switch button,

the Speed LED will turn off and the PoE LED will light up. Then the PoE LED will

turn off after being on for 60 seconds and the Speed LED will light up again.

When the Speed LED is on, the port LED is indicating the data transmission

status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN

Green All the fans work properly

Yellow Not all the fans work properly

Off The switch works improperly

PoE MAX

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this

LED is on for 2 minutes

Off The remaining PoE power>7W

Speed or PoE

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 10/100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Gigabit L2 Managed Switch

Introduction

LED Status Indication

SFP1, SFP2

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

When the PoE LED is on, the port LED is indicating the power supply status.

LED Status Indication

PWR

On The switch is powered on

Off The switch is powered off or power supply is

abnormal

Flashing Power supply is abnormal

SYS Flashing The switch works properly

On/Off The switch works improperly

FAN

Green All the fans work properly

Yellow Not all the fans work properly

Off The switch works improperly

PoE MAX

On The remaining PoE power≤7W

Flashing The remaining PoE power keeps ≤7W after this

LED is on for 2 minutes

Off The remaining PoE power>7W

Speed or PoE

Green

On The port is supplying power normally

Flashing The supply power exceeds the corresponding

port's maximum power

Yellow On Overload or short circuit is detected

Flashing Power-on self-test has failed

Off No PoE power supply is provided on the port

SFP1, SFP2

Green On A 1000Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Yellow On A 100Mbps device is connected to the

corresponding port, but no activity

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and

configuring the switch. The switch has an RJ-45 console port and a micro-USB

console port available. Console input is active on only one console port at a

time. By default, the micro-USB connector takes precedence over the RJ-45

connector.

Gigabit L2 Managed Switch

Introduction

10/100/1000Mbps RJ45 Port and PoE Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding Speed or PoE LED.

SFP Port

Designed to install the SFP module. T2500G-10 MP S features 2 SFP transceiver

ports.

■Rear Panel

The rear panel of T2500G-10TS is shown as the following figure.

Figure 1-3 Rear Panel of T2500G-10TS

Grounding Terminal

Power Socket

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from

being stolen.

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also

ground the switch through the PE (Protecting Earth) cable of AC cord or with

Ground Cable. For detailed information, please refer to Chapter 3 Lightning

Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

The rear panel of T2500G-10MPS is shown as the following figure.

Figure 1-4 Rear Panel of T2500G-10MPS

Power Socket

Grounding Terminal

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from

being stolen.

Gigabit L2 Managed Switch

Introduction

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also

ground the switch through the PE (Protecting Earth) cable of AC cord or with

Ground Cable. For detailed information, please refer to Chapter 3 Lightning

Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

Caution: Please use the provided power cord.

Autres manuels pour T2500G-10MPS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TP-Link Changer

TP-Link

TP-Link T3700G-28TQ Manuel utilisateur

TP-Link

TP-Link TL-SG1005D - 5 PORT GIGABIT DESKTOP SWITCH Manuel utilisateur

TP-Link

TP-Link JetStream T2700G-28TQ Mode d’emploi

TP-Link

TP-Link TL-SG116E Manuel utilisateur

TP-Link

TP-Link TL-SG2424P Manuel utilisateur

TP-Link

TP-Link TL-SF1005P Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG2210P Manuel utilisateur

TP-Link

TP-Link T3700G-28TQ Manuel utilisateur

TP-Link

TP-Link TL-SF1008D - 10/100M FAST ETHERNET SWITCH Manuel utilisateur

TP-Link

TP-Link P1200-08 Manuel d'utilisation

TP-Link

TP-Link DS108GE Manuel utilisateur

TP-Link

TP-Link TL-SF1008P Manuel utilisateur

TP-Link

TP-Link TL-SG105E Manuel utilisateur

TP-Link

TP-Link TL-SG1016D Manuel utilisateur

TP-Link

TP-Link TL-SG105 Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG3424 Manuel utilisateur

TP-Link

TP-Link JetStream L2 Manuel utilisateur

TP-Link

TP-Link UH720 Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG5412F Mode d’emploi

TP-Link

TP-Link JetStream TL-SL3428 Mode d’emploi

TP-Link

TP-Link Omada DS1008X Manuel utilisateur

TP-Link

TP-Link TL-SG105PP-M2 Manuel utilisateur

TP-Link

TP-Link TL-POE150S Manuel utilisateur

TP-Link

TP-Link JetStream TL-SG2210P Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
