User Guide

TL-SF1005D

TL-SF1008D

TL-SF1016D

10/100Mbps Desktop Switch

Rev:2.0.1

7106503708

FCC STATEMENT

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1）This device may not cause harmful interference.

2）This device must accept any interference received,

including interference that may cause undesired

operation.

Any changes or modifications not expressly approved by

the party responsible for compliance could void the user’s

authority to operate the equipment.

CE Mark Warning

This is a class B product. In a domestic environment, this

product may cause radio interference, in which case the

user may be required to take adequate measures.

Package Contents

The following items should be found in your box:

¾One TL-SF1005D/TL-SF1008D/TL-SF1016D Switch

¾One Power Adapter

¾This User Guide

Note:

The wall-mounting screws are not provided. Please

contact your distributor if any of the listed items are

damaged or missing.

The Switch mentioned in this User Guide stands

for TL-SF1005D/TL-SF1008D/TL-SF1016D 10/100Mbps

Desktop Switch without any explanation. For Simplicity, we

will take TL-SF1016D for example throughout this Guide.

Refer to the steps below to mount the Switch on a Wall.

1. Drill two holes into the wall. Insert a screw into each

hole and leave a part of its head exposed.

2. Place the two wall-mounting slots over the screws and

slide the Switch down to fasten it.

Note: Without slots on the bottom, TL-SF1005D cannot

be mounted on a wall.

The Switch's LEDs are located on the front panel:

LED Status Indication

On The switch is powered on.Power

Off No Power Source.

*Please check if the power cord

is connected to the Switch

properly, and make sure the

power is ON.

On The corresponding ethernet port

is connected to a network device.

Flashing

Data is being transmitted or received.

Ethernet

LED

Off No device is connected to the

corresponding port.

*Please check if the cable

connectors are firmly plugged

into the switch and the device,

and verify the connected device

is turned on and working well.

is a registered trademark of TP-LINK

TECHNOLOGIES CO., LTD. Other brands and product

names are trademarks or registered trademarks of their

respective holders.

http://www.tp-link.com
