About This Guide

This guide is a complementation of Quick Installation Guide. The Quick Installation

Guide instructs you on quick Internet setup, and this guide provides details of each

function and shows you the way to configure these functions appropriate to your

needs.

When using this guide, please notice that features of the router may vary slightly

depending on the model and software version you have, and on your location, language,

and Internet service provider. All screenshots, images, parameters and descriptions

documented in this guide are used for demonstration only.

Conventions

In this guide, the following conventions are used:

Convention Description

Blue Italic Hyperlinks are in blue italic. You can click to redirect to a website or a specific

section.

Blue Contents to be emphasized and texts on the web page are in blue, including the

menus, items, buttons, etc.

The menu structures to show the path to load the corresponding page. For

example, Advanced > Wireless > MAC Filtering means the MAC Filtering function

page is under the Wireless menu that is located in the Advanced tab.

Note: Ignoring this type of note might result in a malfunction or damage to the device.

Tips: Indicates important information that helps you make better use of your device.

symbols on the

web page

• click to edit the corresponding entry.

• click to delete the corresponding entry.

• click to enable or disable the corresponding entry.

• click to view more information about items on the page.

More Info

• The latest firmware and management app can be found at Download Center at http://

www.tp-link.com/support.

• The Quick Installation Guide (QIG) can be found where you find this guide or inside

the package of the router.

• Specifications can be found on the product page at http://www.tp-link.com.

• A Technical Support Forum is provided for you to discuss our products at

http://forum.tp-link.com.

• Our Technical Support contact information can be found at the Contact Technical

Support page at http://www.tp-link.com/support.

Chapter 1

Get to Know About Your

Router

This chapter introduces what the router can do and

shows its main features and appearance.

This chapter contains the following sections:

• Product Overview

• Main Features

• Panel Layout

Chapter 1 Get to Know About Your Router

1. 1. Product Overview

What This Product Does

TP-LINK’s AC3150 Wireless MU-MIMO Gigabit Router integrates 4-port Switch, Firewall,

NAT-router and Wireless AP. Powered by 4x4 MIMO technology, this router delivers

exceptional range and speed, which can fully meet the need of office/home networks

and the users demanding higher networking performance. Your wireless connections

are radio band selectable to avoid interference in your area, and the four built-in Gigabit

ports supply high-speed connection to your wired devices.

Making Incredible Speed a Reality

With combined speeds of up to 3150Mbps, the Archer C3150 easily handles demanding

activities at the same time. The router uses the latest innovations in Wi-Fi technology to

create a faster, stronger, more reliable wireless network for your home. With the Archer

C3150, lag, dropped connections, and dead zones will become a thing of the past.

NitroQAM and 4-Stream for Maximum Wi-Fi Speed

The Archer C3150 boasts a powerful combination of advanced Broadcom® NitroQAM™

technology and 4-Stream technology, which boosts wireless speeds up by 25%.

This provides the speed and elite performance that you need to support your most

demanding online applications, including simultaneous 4K streaming and online

gaming.

More Connections and More Speed for Everyone

The Archer C3150 does more than just create faster Wi-Fi, it helps your devices achieve

optimal performance by making communication more efficient. With MU-MIMO

technology, the Archer C3150 can provide four simultaneous data streams, allowing all

connected devices to achieve speeds up to 4X faster than standard AC routers.

Moreover, dynamic Smart Connect technology automatically selects the best available

band for each device.

Extraordinary Home Entertainment

Archer C3150 can support many devices when you invite friends to your large house

to entertain. It can maintain multiple simultaneous HD streaming, online gaming and

other content consumption without lag. The Archer C3150 can provide a maximized

coverage and enable your devices to stay covered, near or far as it. Don’t let your mobile

lifestyle stop the streaming and enjoy your home party.

The Power at the Heart of Your Router

Unlike normal routers, which usually have single core processors, the Archer C3150

features a powerful 1.4GHz dual core processor.

Chapter 1 Get to Know About Your Router

This unlocks the full potential of MU-MIMO and 4-Stream technologies, helping your

dual band router maximize its performance potential.

Coverage for Your Entire Home

Four high-performance dual band antennas and high-powered amplifiers help create

a strong, far-reaching network for your home. Beamforming technology focuses the

Wi-Fi transmission in the direction of your connected devices, concentrating the signal

where you need it the most. This allows you to enjoy fast, stable Wi-Fi in every part of

your home, as well as on the patio, by the pool, and even in the yard.

A Router You Can Show Off

An elegant, minimalist design allows the Archer C3150 to be integrated seamlessly into

the decor of any room. The LED indicators can be switched off to prevent distraction at

night when placed in bedrooms or common spaces.

Plug Into Sharing, Plug Into Stability

You can quickly and easily share photos, music, and other files with family and friends.

Just connect an external hard drive to the Archer C3150’s USB 3.0 port or USB 2.0 port

and immediately start enjoying lightning-fast transfers. To help your wired devices

reach peak performance for smooth gaming and streaming, you can also create fast,

stable wired connections using the four Gigabit Ethernet ports, which transfer data at

speeds up to 10x higher than standard Ethernet ports.

Easy Setup and Use

Whether you prefer the powerful Tether App or the intuitive web interface, you can

set up your Archer C3150 in minutes. The Tether App allows you to manage network

settings, including parental controls and media sharing preferences, from any Android

or iOS device.

1. 2. Main Features

Wireless and Wired Performance

• Complies with IEEE 802.11ac.

• One 10/100/1000M Auto-Negotiation RJ45 Internet port, four 10/100/1000M Auto-

Negotiation RJ45 Ethernet ports, supporting Auto MDI/MDIX.

• Provides a USB 3.0 port and a USB 2.0 port supporting file sharing and print server.

• Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption

security.

• Shares data and Internet access for users, supporting Dynamic IP/Static IP/PPPoE/

PPTP/ L2TP Internet access.

Chapter 1 Get to Know About Your Router

• Supports simultaneous 2.4GHz and 5GHz connections for 3165Mbps of total available

bandwidth.

• Supports Virtual Server, Special Application and DMZ host.

• Supports UPnP, Dynamic DNS, Static Routing.

• Provides Automatic-connection and Scheduled Connection on certain time to the

Internet.

• Built-in NAT and DHCP server supporting static IP address distributing.

• Supports Parental Controls and Access Control.

• Connects Internet on demand and disconnects from the Internet when idle for PPPoE.

• Provides WEP encryption security and wireless LAN ACL (Access Control List).

• Supports Flow Statistics.

• Supports IPv6.

• Supports firmware upgrade and Web management.

• Supports OpenVPN server, PPTP VPN server.

• Supports beamforming technology.

• Supports Airtime Fairness technology.

• Supports MU-MIMO technology.

Note:

Future firmware upgrade is required to enable MU-MIMO technology.

1. 3. Panel Layout

1. 3. 1. Front Panel

Chapter 1 Get to Know About Your Router

The router’s LEDs are located on the top panel (view from top to bottom).You can check

the router’s working status by following the LED Explanation table.

LED Explanation

Name Status Indication

(LED)

On All LEDs work normally.

Off All LEDs are off without affecting the router’s performance.

(Power)

On System initialization completes.

Flashing System initialization or firmware upgrade is in process. Do not

disconnect or power off the router.

Off Power is off. Please ensure that the power adapter is connected

correctly.

(Wireless 2.4GHz)

On The wireless 2.4GHz band is working properly.

Off The wireless 2.4 GHz band is disabled.

(Wireless 5GHz)

On The wireless 5GHz band is working properly.

Off The wireless 5GHz band is disabled.

(Internet)

White The router is connected to the Internet.

Orange The WAN port is connected, but there is no Internet connection.

Off The WAN port is not connected.

(LAN)

On At least one LAN port is connected.

Off No LAN port is connected.

(WPS)

On A wireless device has been successfully added to the network by

WPS function.

Flashing

WPS handshaking is in process and will continue for about 2 minutes.

Please press the WPS button on other wireless devices that you want

to add to the network while the LED is flashing.

Off The router is not in the WPS process.

(USB1)

On The USB 3.0 device is identified and ready to use.

Flashing The USB 3.0 device is being identified.

Off No USB 3.0 device is plugged into the USB port or the USB device is

not identified or USB device has been safely ejected.

(USB2)

On The USB 2.0 device is identified and ready to use.

Flashing The USB 2.0 device is being identified.

Off No USB 2.0 device is plugged into the USB port or the USB device is

not identified or USB device has been safely ejected.

Note:

After a device is successfully added to the network by WPS function, the WPS LED will keep on for about 5 minutes

and then turn off.

Autres manuels pour ARCHER C3150

Table des matières

Autres manuels TP-Link Routeur réseau

TP-Link

TP-Link ER706W-4G Manuel utilisateur

TP-Link

TP-Link Archer A5 Manuel utilisateur

TP-Link

TP-Link TL-ER7206 Manuel utilisateur

TP-Link

TP-Link TL-R470T+ Manuel utilisateur

TP-Link

TP-Link TL-WR1043ND - Ultimate Wireless N Gigabit... Manuel utilisateur

TP-Link

TP-Link EC231-G1u Manuel utilisateur

TP-Link

TP-Link TD-W8961NB Manuel utilisateur

TP-Link

TP-Link ARCHER C3150 Manuel utilisateur

TP-Link

TP-Link Archer C50 Manuel utilisateur

TP-Link

TP-Link Archer AX75 Manuel utilisateur

TP-Link

TP-Link TD-W8961ND Manuel utilisateur

TP-Link

TP-Link WR740N Guide de configuration

TP-Link

TP-Link Archer C2600 Manuel utilisateur

TP-Link

TP-Link Archer C3200 Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

TP-Link

TP-Link TD-W8961NB Manuel utilisateur

TP-Link

TP-Link ARCHER C3150 Manuel utilisateur

TP-Link

TP-Link Archer VR900 Manuel utilisateur

TP-Link

TP-Link Deco WE10800 Manuel utilisateur

TP-Link

TP-Link archer VR900V Manuel utilisateur

TP-Link

TP-Link CR1900 Manuel utilisateur

TP-Link

TP-Link Archer C7 AC1750 Manuel utilisateur

TP-Link

TP-Link SafeStream TL-R600VPN Manuel utilisateur

TP-Link

TP-Link Touch P5 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
