TP-Link Archer A6 Manuel utilisateur

REV2.2.1 1910012745

User Guide

AC1200 Wireless MU-MIMO Gigabit Router

Archer A6/Archer C6

Contents

About This Guide.........................................................................................................1

Chapter 1. Get to Know About Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . .3

1. 1. Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1. 2. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1. 2. 1.The Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1. 2. 2.The Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2. Connect the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2. 1. Position Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2. 2. Connect Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 3. Log In to Your Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 4. Set Up Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4. 1. Use Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. 2. Manually Set up Your Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4. 3. Set Up an IPv6 Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4. 4. Configure the Router in Access Point Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Chapter 5. TP-Link Cloud Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5. 1. Register a TP-Link ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5. 2. Change Your TP-Link ID Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5. 3. Manage the User TP-Link IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5. 3. 1.Add TP-Link ID to Manage the Router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5. 3. 2.Remove TP-Link ID(s) from Managing the Router . . . . . . . . . . . . . . . . . . . . . . 26

5. 4. Manage the Router via the TP-Link Tether App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 6. OneMeshTM with Seamless Roaming. . . . . . . . . . . . . . . . . . . . . 28

6. 1. Set Up a OneMeshTM Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

6. 2. Manage Devices in the OneMeshTM Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 7. Guest Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

7. 1. Create a Network for Guests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7. 2. Customize Guest Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 8. Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

8. 1. Set Up Access Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

8. 2. Monitor Internet Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Chapter 9. QoS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Chapter 10.Network Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

10. 1. Protect the Network from Cyber Attacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

10. 2. Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

10. 3. IP & MAC Binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Chapter 11.NAT Forwarding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

11. 1. Translate Address and Port by ALG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

11. 2. Share Local Resources on the Internet by Virtual Servers. . . . . . . . . . . . . . . . . . . . 51

11. 3. Open Ports Dynamically by Port Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

11. 4. Make Applications Free from Port Restriction by DMZ . . . . . . . . . . . . . . . . . . . . . . . 53

11. 5. Make Xbox Online Games Run Smoothly by UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Chapter 12.VPN Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

12. 1. Use OpenVPN to Access Your Home Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

12. 1. 1.Step1. Set up OpenVPN Server on Your Router . . . . . . . . . . . . . . . . . . . . . . 57

12. 1. 2.Step 2. Configure OpenVPN Connection on Your Remote Device . . . . 58

12. 2. Use PPTP VPN to Access Your Home Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

12. 2. 1.Step 1. Set up PPTP VPN Server on Your Router . . . . . . . . . . . . . . . . . . . . . 59

12. 2. 2.Step 2. Configure PPTP VPN Connection on Your Remote Device. . . . 60

Chapter 13.Customize Your Network Settings. . . . . . . . . . . . . . . . . . . . . . . 64

13. 1. Change the LAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

13. 2. Configure to Support IPTV Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

13. 3. Specify DHCP Server Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

13. 4. Set Up a Dynamic DNS Service Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

13. 5. Create Static Routes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

13. 6. Specify Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

13. 7. Use WPS for Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

13. 7. 1.Set the Router’s PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

13. 7. 2.Use the WPS Wizard for Wi-Fi Connections. . . . . . . . . . . . . . . . . . . . . . . . . . 75

13. 8. Schedule Your Wireless Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

13. 9. TxBF, MU-MIMO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Chapter 14.Manage the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

14. 1. Set Up System Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

14. 2. Control LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

14. 3. Test the Network Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

14. 4. Upgrade the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

14. 5. Backup and Restore Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

14. 6. Set the Router to Reboot Regularly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

14. 7. Change the Login Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

14. 8. Password Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

14. 9. Local Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

14. 10. Remote Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

14. 11. System Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

14. 12. Monitor the Internet Traffic Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

14. 13. Configure the System Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

14. 13. 1.Wireless Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

14. 13. 2.WDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

14. 13. 3.WPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

14. 13. 4.NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

14. 13. 5.DoS Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

14. 13. 6.Duplex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Chapter 15.Work with Alexa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

FAQ ................................................................................................................................99

About This Guide

This guide is a complement of Quick Installation Guide. The Quick Installation Guide

instructs you on quick Internet setup, and this guide provides details of each function

and shows you the way to configure these functions appropriate to your needs.

Note: Features available in the router may vary by model and software version. Router

availability may also vary by region or ISP. All images, steps, and descriptions in this

guide are only examples and may not reflect your actual router experience.

Conventions

In this guide the following conventions are used:

Convention Description

Underlined Underlined words or phrases are hyperlinks. You can click to redirect to a

website or a specific section.

Teal Contents to be emphasized and texts on the web page are in teal, including the

menus, items, buttons, etc.

The menu structures to show the path to load the corresponding page.

For example, Advanced > Wireless > MAC Filtering means the MAC Filtering

function page is under the Wireless menu that is located in the Advanced tab.

Note: Ignoring this type of note might result in a malfunction or damage to the device.

Tips: Indicates important information that helps you make better use of your device.

Symbols on the web

page

• Click to edit the corresponding entry.

• Click to delete the corresponding entry.

• Click to enable or disable the corresponding entry.

• Click to view more information about items on the page.

*Maximum wireless signal rates are the physical rates derived from IEEE Standard

802.11 specifications. Actual wireless data throughput and wireless coverage are

not guaranteed and will vary as a result of 1) environmental factors, including building

materials, physical objects, and obstacles, 2) network conditions, including local

interference, volume and density of traffic, product location, network complexity, and

network overhead, and 3) client limitations, including rated performance, location,

connection, quality, and client condition.

*Use of MU-MIMO requires clients to also support MU-MIMO.

More Info

The latest software, management app and utility can be found at Download Center at

https://www.tp-link.com/support.

Specifications can be found on the product page at https://www.tp-link.com.

TP-Link Community is provided for you to discuss our products and share knowledge at

https://community.tp-link.com/.

Our Technical Support contact information can be found at the Contact Technical

Support page at https://www.tp-link.com/support.

Chapter 1

Get to Know About Your

Router

This chapter introduces what the router can do and shows its appearance.

It contains the following sections:

• Product Overview

• Appearance

Chapter 1 Get to Know About Your Router

1. 1. Product Overview

The TP-Link router is designed to fully meet the need of Small Office/Home Office

(SOHO) networks and users demanding higher networking performance. The powerful

antennas ensure continuous Wi-Fi signal to all your devices while boosting widespread

coverage throughout your home, and the built-in Ethernet ports supply high-speed

connection to your wired devices. The OneMeshTM function allows you to enjoy one

unified network with seamless roaming.

Moreover, it is simple and convenient to set up and use the TP-Link router due to its

intuitive web interface and the powerful Tether app.

1. 2. Appearance

1. 2. 1. The Front Panel

The router’s LEDs (view from left to right) are located on the front panel. You can check

the router’s working status by following the LED Explanation table.

Chapter 1 Get to Know About Your Router

LED Explanation

Name Status Indication

(Power)

On The system has started up successfully.

Flashing The system is starting up or the firmware is being upgraded. Do

not disconnect or power off your router.

Off Power is off.

(2.4GHz Wireless)

On The 2.4GHz wireless band is enabled.

Off The 2.4GHz wireless band is disabled.

(5GHz Wireless)

On The 5GHz wireless band is enabled.

Off The 5GHz wireless band is disabled.

(Ethernet)

On At least one Ethernet port is connected to a powered-on device.

Off No powered-on device is connected to the router’s corresponding

Ethernet port.

(Internet)

Green On Internet service is available.

Orange On The router’s Internet port is connected, but the internet service

is not available.

Off The router’s Internet port is unplugged.

(WPS)

On/Off This light remains on for 5 minutes when a WPS connection is

established, then turns off.

Flashing WPS connection is in progress. This may take up to 2 minutes.

1. 2. 2. The Back Panel

Chapter 1 Get to Know About Your Router

The router’s ports (view from left to right) are located on the rear panel.

Item Description

Power Port For connecting the router to a power socket via the provided power adapter.

Power On/Off Button Press this button to power on or off the router.

Reset Button Press and hold this button for more than 2 seconds to reset the router to its

factory default settings.

WPS/Wi-Fi On/Off

Press this button, and immediately press the WPS button on your device. The

WPS LED of the router should change from flashing to solid on, indicating

successful WPS connection.

Press and hold the Wi-Fi button for about 3 seconds to turn on or off the

wireless function of your router.

Internet Port For connecting to a DSL/Cable modem, or an Ethernet jack.

Ethernet Ports (1/2/3/4) For connecting your PC or other Ethernet network devices to the router.

Antennas Used for wireless operation and data transmit. Upright them for the best

Wi-Fi performance.

Autres manuels pour Archer A6

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels TP-Link Routeur réseau

TP-Link

TP-Link SafeStream TL-R600VPN Manuel utilisateur

TP-Link

TP-Link ARCHER MR200 Manuel utilisateur

TP-Link

TP-Link EX1110 Manuel utilisateur

TP-Link

TP-Link Deco X25 Manuel utilisateur

TP-Link

TP-Link ER706W-4G Manuel utilisateur

TP-Link

TP-Link Archer C7 AC1750 Manuel utilisateur

TP-Link

TP-Link Archer C3200 Manuel utilisateur

TP-Link

TP-Link Archer C7 AC1750 Manuel utilisateur

TP-Link

TP-Link TW-MR3220 Manuel utilisateur

TP-Link

TP-Link TL-SG2424 Manuel utilisateur

TP-Link

TP-Link WR740N Guide de configuration

TP-Link

TP-Link ARCHER C60 Manuel utilisateur

TP-Link

TP-Link Archer C5400X Manuel utilisateur

TP-Link

TP-Link TL-WA860RE Manuel utilisateur

TP-Link

TP-Link Archer C20 Manuel utilisateur

TP-Link

TP-Link Archer C5400X Manuel utilisateur

TP-Link

TP-Link ADSL2/2+ Manuel utilisateur

TP-Link

TP-Link Archer MR500 Manuel utilisateur

TP-Link

TP-Link TD-W8901G - VERSION 1.0.4 Manuel utilisateur

TP-Link

TP-Link TL-MR3040 Manuel utilisateur

TP-Link

TP-Link Archer VR600 Manuel utilisateur

TP-Link

TP-Link TD-W8900G Manuel utilisateur

TP-Link

TP-Link Archer AX20 Manuel utilisateur

TP-Link

TP-Link Archer BE550 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
