TP-Link Auranet EAP220 Manuel utilisateur

7106506404 REV1.0.0

Specifications are subject to change without notice. TP-LINK is a registered

trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product

names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any

means or used to make any derivative such as translation, transformation,

or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

www.tp-link.com

›English

› Български

› Čeština

› Қазақша

› Lietuvių

› Magyar

›Polski

› Русский язык

› Română

› Slovenčina

› Srpski jezik

› Українська мова

Ceiling Mount Access Point

Installation Guide

CONTENTS

English..................................................................................................1

Български ............................................................................................7

Čeština ...............................................................................................13

Қазақша .............................................................................................19

Lietuvių ...............................................................................................25

Magyar................................................................................................31

Polski..................................................................................................37

Русский язык .....................................................................................43

Română..............................................................................................49

Slovenčina..........................................................................................55

Srpski jezik .........................................................................................61

Українська мова ................................................................................67

English

Note: The image may differ from the actual product.

Network Topology

A typical network topology for the EAP is shown below.

EAP Controller

A DHCP server (typically a router) is required to assign IP addresses to the EAPs

and clients in your local network. A computer running the EAP Controller software,

which can be in the same or different subnet with the EAPs, is used to centrally

manage the EAPs.

You can get the EAP Controller software from our website http://www.tp-link.com.

Hardware Installation

■Option1：

Ceiling Rail Mounting

Follow the steps below to install the EAP with the provided accessories:

1Position the Ceiling T-rail Clip and push the

movable part toward the rail base.

Ceiling T-rail Clip M3×6 Pan-head Screws (Qty.5)

Controller

Host

Router Switch

Internet

Clients

EAP

English

2Use an M3×6 pan-head screw to secure the T-rail

Clip onto the ceiling rail.

3Attach the mounting bracket to the Ceiling T-rail

Clip using four M3x6 pan-head screws.

4Attach the EAP to the mounting bracket by

aligning ARROW 1 (on the EAP) with ARROW 2

(on the mounting bracket), then rotate the EAP

clockwise until it locks into place.

5Connect the Ethernet cable to the ETHERNET

port.

English

■Option2：

Ceiling Mounting

Follow the steps below to install the EAP with the provided accessories:

1Remove the ceiling tile.

2Place the mounting bracket in the center

of the ceiling tile. Mark the three positions

of the screw holes and a 10mm hole for

the Ethernet cable to feed through. Drill

three 4mm holes and a 10mm hole for the

Ethernet cable.

3Secure the mounting bracket to the ceiling

tile using three M3x30 pan-head screws,

washers and wing nuts.

Washers

(Qty.3)

M3×30 Pan-head Screws

(Qty.3)

Wing Nuts

(Qty.3)

Hole for Ethernet cable

English

4Attach the EAP to the mounting bracket

by aligning ARROW 1 (on the EAP) with

ARROW 2 (on the mounting bracket), then

rotate the EAP clockwise until it locks into

place.

5Feed the Ethernet cable through the hole and

set the ceiling tile back into place. Connect

the Ethernet cable to the ETHERNET port.

■Option3：

Wall Mounting

Follow the steps below to install the EAP with the provided accessories:

1Attach the EAP to the mounting bracket by

aligning ARROW 1 (on the EAP) with ARROW

2 (on the mounting bracket), then rotate the

EAP clockwise until it locks into place.

2Make two small pencil marks on the wall. Make

sure the two marks are level and should be

98.6mm apart. Drill two 6mm holes through

the center of your marks.

98.6mm

M3×28 Plastic Wall Anchors

(Qty.4)

M3×20 Self-tapping Screws

(Qty.4)

English

3Insert the plastic wall anchors into the 6mm

holes and drive the self-tapping screws into

the anchors. Do not drive the screws all the

way in and leave enough clearance to hang

the EAP.

4Hang the EAP on the screws. Make sure the

EAP is firmly seated against the wall.

5Connect the Ethernet cable to the ETHERNET

port on the EAP.

English

Power Supply

■Power via PSE Device or Power Adapter

If the product is provided with a power adapter, power the device via a PSE device

(such as a PoE switch) or the power adapter.

Via PoE Switch

ON/OFF

Via Power Adapter

ON/OFF

■Power via POE Adapter

If the product is provided with a POE adapter, power the device via the POE

adapter.

PoE LAN

PoE Switch

PoE Adapter

(Up to 100m)

Switch

Български

Забележка: Изображението може да се различава от реалния продукт.

Мрежова топология

Типична мрежова топология за EAP (точки за достъп с протокол за

разширена автентификация) е показана по-долу.

EAP Controller

Необходим е един DHCP сървър (в типичния случай - рутер) за задаване

на IP адреси на EAP устройствата и клиентите във вашата локална мрежа.

Един компютър, на който върви софтуера EAP Controller, който може да

бъде в същата или различна подмрежа с EAP устройствата, се използва за

централно управление на EAP устройствата.

Можете да получите софтуера EAP Controller от нашия уебсайт

http://www.tp-link.com.

Инсталация на хардуера

■Опция 1: Монтаж на релса на тавана

Следвайте стъпките, описани по-долу, за да инсталирате EAP с доставените

в комплекта аксесоари:

1Позиционирайте стягата за релса на тавана

и натиснете движещата се част към основата

на релсата.

Стяга за Т-образна

релса на тавана

M3×6 винтове с глава тип звезда

(5 бр.)

Контролер

хост

Рутер Суич

Интернет

Клиенти

EAP

Български

2Използвайте един M3×6 винт звезда, за да

закрепите стягата към релсата на тавана.

3Закрепете монтажната скоба към стягата на

релсата на тавана с четири M3x6 винтове с

глава тип звезда.

4Закрепете EAP към монтажната скоба,

като подравните СТРЕЛКА 1 (на EAP) със

СТРЕЛКА 2 (на монтажната скоба), след

това завъртете EAP устройството в посока

на часовниковата стрелка, докато щракне на

място.

5Свържете Ethernet кабел към ETHERNET

порта.
